Connectors / Headers and Edge Type Connectors / 102387-4
Datasheets
102387-4 by:
TE Connectivity

20 MODIV HSG COMP DR .100 POL

Part Details for 102387-4 by TE Connectivity

Results Overview of 102387-4 by TE Connectivity

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Audio and Video Systems Energy and Power Systems Medical Imaging Entertainment and Gaming Robotics and Drones

102387-4 Information

102387-4 by TE Connectivity is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.

Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.

Price & Stock for 102387-4

Part # Distributor Description Stock Price Buy
DISTI # 90F4760
Newark Connector Housing, Receptacle, 20 Position, 2Row, 2.54Mm, Product Range:Ampmodu Mod Iv Series, Gender:Receptacle, No. Of Positions:20Positions, Pitch Spacing:2.54Mm, For Use With:Ampmodu Socket Contacts, Colour:Black, No. Of Rows:2 Rohs Compliant: Yes |Amp Te Connectivity 102387-4 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk 2702
  • 1 $3.1100
  • 10 $2.9300
  • 25 $2.8500
  • 50 $2.7200
  • 100 $2.6800
$2.6800 / $3.1100 Buy Now
DISTI # 102387-4
Avnet Americas Connector Housing, AMP AMPMODU MOD IV/V Series, Receptacle, 20 Ways, 2.54 mm - Bag (Alt: 102387-4) COO: Mexico RoHS: Compliant Min Qty: 500 Package Multiple: 500 Lead time: 16 Weeks, 0 Days Container: Bag 3990
  • 500 $2.0664
  • 5,000 $1.6882
  • 10,000 $1.4424
  • 25,000 $1.3128
  • 50,000 $1.2276
$1.2276 / $2.0664 Buy Now
DISTI # 90F4760
Avnet Americas Connector Housing, AMP AMPMODU MOD IV/V Series, Receptacle, 20 Ways, 2.54 mm - Bulk (Alt: 90F4760) COO: Mexico RoHS: Compliant Min Qty: 1 Package Multiple: 1 Container: Bulk 2737 Partner Stock
  • 1 $3.1100
  • 10 $2.9300
  • 25 $2.8500
  • 50 $2.7200
  • 100 $2.6800
$2.6800 / $3.1100 Buy Now
DISTI # 70085402
RS HOUSING, DUAL 20 250 VAC, 3 A 750 V, AMPMODU MOD IV SERIES Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks, 0 Days Container: Bulk 264
  • 1 $3.5200
  • 25 $3.2400
  • 50 $3.0300
  • 100 $2.8700
  • 250 $2.7100
$2.7100 / $3.5200 Buy Now
TE Connectivity 20 MODIV HSG COMP DR .100 POL Number of Positions: 20 Connector & Housing Type: Receptacle Connector Product Type: Housing Mating Retention: With Termination Method to Wire & Cable: Crimp Standard Rectangular Connector | 20 Receptacle Housing With | Part Number: 102387-4 | Internal Number: 102387-4 | Alias Number: 2-42935-3932 | TE Connectivity RoHS: Compliant Min Qty: 1 2036
  • 1 $3.6800
  • 10 $3.5900
  • 25 $3.5000
  • 50 $3.4000
  • 100 $3.3100
  • 250 $3.2200
  • 500 $3.1300
  • 1,000 $3.0400
$3.0400 / $3.6800 Buy Now
Bisco Industries   5
Buy Now
DISTI # AMP102387-4
Heilind Electronics 20 MODIV HSG COMP DR .100 POL Americas - 21923 in Stock
  • 1 $1.6899
  • 150 $1.4818
  • 300 $1.4165
  • 550 $1.3760
  • 1,050 $1.3378
$1.3378 / $1.6899 Buy Now
Bristol Electronics   1036
RFQ
DISTI # 102387-4
TME Connector: wire-board, plug, female, PIN: 20, AMPMODU MOD IV, 2x10 Min Qty: 1 27
  • 1 $2.5400
  • 10 $2.3700
  • 25 $2.1600
  • 50 $1.9600
  • 100 $1.7700
  • 250 $1.6000
  • 500 $1.5800
$1.5800 / $2.5400 Buy Now
DISTI # AMP102387-4
Interstate Connecting Components 20 MODIV HSG COMP DR .100 POL 3581
  • 1 $1.6899
  • 150 $1.4818
  • 300 $1.4165
  • 550 $1.3760
  • 1,050 $1.3378
$1.3378 / $1.6899 Buy Now
Powell Electronics MOD IV HSG COMP Min Qty: 1 18
  • 1 $7.7490
  • 2,500 $5.4243
  • 5,000 $4.5203
  • 10,000 $3.9176
  • 25,000 $3.6162
$3.6162 / $7.7490 Buy Now
DISTI # 102387-4
Richardson RFPD RECTANGULAR CONNECTOR RoHS: Compliant Min Qty: 1 0
RFQ
DISTI # 000000000000652680
Sager Headers & Wire Housings CNTR PLRZD HG 20 DBL Min Qty: 1 1152
  • 1 $1.5700
  • 10 $1.5000
  • 25 $1.4600
  • 50 $1.4200
  • 100 $1.3600
$1.3600 / $1.5700 Buy Now
Chip 1 Exchange INSTOCK 116758
RFQ
DISTI # 102387-4
Avnet Abacus Connector Housing AMP AMPMODU MOD IVV Series Receptacle 20 Ways 254 mm (Alt: 102387-4) RoHS: Compliant Min Qty: 500 Package Multiple: 500 Lead time: 64 Weeks, 0 Days Abacus - 1500
Buy Now
DISTI # 102387-4
Avnet Abacus Connector Housing AMP AMPMODU MOD IVV Series Receptacle 20 Ways 254 mm (Alt: 102387-4) RoHS: Compliant Min Qty: 150 Package Multiple: 1 Lead time: 66 Weeks, 0 Days Abacus - 0
Buy Now
Component Electronics, Inc MISC CONN PLAS BLK 20
  • 1 $3.8500
  • 100 $2.8800
  • 1,000 $2.5000
$2.5000 / $3.8500 Buy Now
LCSC 2 -65+105 10 P2.54mm Rectangular Connector Housings RoHS 2495
  • 1 $0.9903
  • 10 $0.8049
  • 30 $0.7122
  • 100 $0.6195
  • 500 $0.5655
  • 1,000 $0.5361
$0.5361 / $0.9903 Buy Now
New Advantage Corporation Conn Housing RCP 20 POS 2.54mm Crimp ST Cable Mount RoHS: Compliant Min Qty: 1 Package Multiple: 500 1000
  • 500 $2.0400
  • 1,000 $1.8800
$1.8800 / $2.0400 Buy Now

US Tariff Estimator: 102387-4 by TE Connectivity

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

102387-4
TE Connectivity
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for 102387-4

102387-4 Part Data Attributes

Parametric Data
102387-4 TE Connectivity
Buy Now Datasheet
Compare Parts:
102387-4 TE Connectivity 20 MODIV HSG COMP DR .100 POL
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer TE CONNECTIVITY LTD
Package Description ROHS COMPLIANT
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8536.69.40.40
Samacsys Manufacturer TE Connectivity
Additional Feature POLARIZED, SHROUDED
Body Breadth 0.285 inch
Body Depth 0.285 inch
Body Length 1.18 inch
Body/Shell Style RECEPTACLE
Connector Type BOARD CONNECTOR
Contact Finish Mating NOT APPLICABLE
Contact Gender FEMALE
Contact Material NOT APPLICABLE
Contact Pattern RECTANGULAR
Contact Style SQ PIN-SKT
DIN Conformance NO
EMI Shielded NO
Empty Shell YES
Filter Feature NO
IEC Conformance NO
Insulation Resistance 5000000000 Ω
Insulator Color BLACK
Insulator Material POLYETHYLENE
MIL Conformance NO
Mains Connector Rating 3A
Mating Contact Pitch 0.1 inch
Mating Contact Row Spacing 0.1 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts NO
Mounting Type CABLE
Number Of Connectors ONE
Number of Ports 1
Number of Rows Loaded 2
Operating Temperature-Max 105 °C
Operating Temperature-Min -65 °C
Option GENERAL PURPOSE
Panel Mount NO
Polarization Key SHRD CENTER
Rated Current (Signal) 3 A
Reference Standard CSA, LR, U
Terminal Pitch 2.54 mm
Termination Type CRIMP
Total Number of Contacts 20
UL Flammability Code 94V-0
Wire Size-Max 20 AWG
Wire Size-Min 32 AWG

Alternate Parts for 102387-4

This table gives cross-reference parts and alternative options found for 102387-4. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 102387-4, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
87606-410HLF Amphenol Communications Solutions $0.8910 Dubox®, Board To Board Connector, Receptacle, Vertical, Through Hole, Double Row, Top Entry, 20 Positions, 2.54mm (0.100in) Pitch 102387-4 vs 87606-410HLF
87606-310HLF Amphenol Communications Solutions $0.8985 Dubox®, Board To Board Connector, Receptacle, Vertical, Through Hole, Double Row, Top Entry, 20 Positions, 2.54mm (0.100in) Pitch 102387-4 vs 87606-310HLF
1-925370-0 TE Connectivity $1.4685 MOD 4 REC.HSG 1X10P 102387-4 vs 1-925370-0
89898-310ALF Amphenol Communications Solutions $2.7592 Dubox®, Board to Board connector, 2.54mm (0.100in), Receptacle, Vertical, Surface Mount, Double Row, 20 positions 102387-4 vs 89898-310ALF
77317-122-20LF Amphenol FCi Check for Price Board Connector, 20 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Solder Terminal, Black Insulator 102387-4 vs 77317-122-20LF
SSW-110-22-G-D-VS-N-K-FR Samtec Inc Check for Price Board Connector, 20 Contact(s), 2 Row(s), Female, Straight, 0.1 inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Socket, 102387-4 vs SSW-110-22-G-D-VS-N-K-FR
SSW-110-22-F-D-N Samtec Inc Check for Price Board Connector, 20 Contact(s), 2 Row(s), Female, Straight, Solder Terminal, Socket, 102387-4 vs SSW-110-22-F-D-N
77317-121-20LF Amphenol FCi Check for Price Board Connector, 20 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Solder Terminal, Black Insulator, Receptacle, ROHS COMPLIANT 102387-4 vs 77317-121-20LF
89898-410B Amphenol Communications Solutions Check for Price Board Connector, 20 Contact(s), 2 Row(s), Female, Straight, 0.1 inch Pitch, Surface Mount Terminal, Locking, Gray Insulator, Receptacle, 102387-4 vs 89898-410B
87606-310HLF Amphenol FCi Check for Price Board Connector, 20 Contact(s), 2 Row(s), Female, Straight, Solder Terminal, Receptacle, LEAD FREE 102387-4 vs 87606-310HLF
equivalents icon

102387-4 Related Parts

102387-4 Frequently Asked Questions (FAQ)

  • The recommended torque value is 0.5-0.7 Nm (4.4-6.3 in-lbs) for the screw terminals.

  • Yes, the 102387-4 connector is designed to withstand high-vibration environments, but it's recommended to follow TE Connectivity's guidelines for vibration testing and to consult with a TE Connectivity representative for specific application guidance.

  • The operating temperature range for the 102387-4 connector is -40°C to 125°C (-40°F to 257°F).

  • Yes, the 102387-4 connector is suitable for outdoor use, but it's recommended to follow TE Connectivity's guidelines for environmental sealing and to consult with a TE Connectivity representative for specific application guidance.

  • It's not recommended to use the 102387-4 connector with a different wire gauge than recommended, as it may affect the connector's performance and reliability. Consult with a TE Connectivity representative for specific guidance on wire gauge selection.
