Results Overview of 5CEFA7F27I7N by Intel Corporation

Distributor Offerings: (2 listings)
Number of FFF Equivalents: (1 replacement)
CAD Models: (Available)
Number of Functional Equivalents: (0 options)
Part Data Attributes: (Available)
Reference Designs: (Not Available)

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Education and Research Industrial Automation Electronic Manufacturing

5CEFA7F27I7N Information

5CEFA7F27I7N by Intel Corporation is a Field Programmable Gate Array.
Field Programmable Gate Arrays are under the broader part category of Programmable Logic Devices.

Programmable Logic Devices (PLDs) are reconfigurable digital components that can be customized for different applications, offering flexibility and improved performance over fixed logic devices. Read more about Programmable Logic Devices on our Programmable Logic part category page.

Part #	Distributor	Description	Stock	Price	Buy
5CEFA7F27I7N	Vyrian	Programmable ICs	42			RFQ
5CEFA7F27I7N	Win Source Electronics	IC FPGA 336 I/O 672FBGA	1023	1 $150.0000 2 $145.0000 3 $130.0000	$130.0000 / $150.0000	Buy Now

Part Details for 5CEFA7F27I7N

5CEFA7F27I7N CAD Models

Part Symbol
Footprint
3D Model

Available Download Formats

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

5CEFA7F27I7N Part Data Attributes

Parametric Data

Show differences only	5CEFA7F27I7N Intel Corporation Buy Now Datasheet	Buy Now	Compare Parts: 5CEFA7F27I7N Intel Corporation Field Programmable Gate Array, 149500-Cell, CMOS, PBGA672, ROHS COMPLIANT, FBGA-672

Rohs Code	Yes
Part Life Cycle Code	Active
Ihs Manufacturer	INTEL CORP
Package Description	ROHS COMPLIANT, FBGA-672
Reach Compliance Code	compliant
ECCN Code	3A991
HTS Code	8542.39.00.01
Samacsys Manufacturer	Intel
JESD-30 Code	S-PBGA-B672
Length	27 mm
Number of Inputs	336
Number of Logic Cells	149500
Number of Outputs	336
Number of Terminals	672
Operating Temperature-Max	100 °C
Operating Temperature-Min	-40 °C
Organization	5648 CLBS
Package Body Material	PLASTIC/EPOXY
Package Code	BGA
Package Equivalence Code	BGA672,26X26,40
Package Shape	SQUARE
Package Style	GRID ARRAY
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Programmable Logic Type	FIELD PROGRAMMABLE GATE ARRAY
Qualification Status	Not Qualified
Seated Height-Max	2 mm
Supply Voltage-Max	1.13 V
Supply Voltage-Min	1.07 V
Supply Voltage-Nom	1.1 V
Surface Mount	YES
Technology	CMOS
Terminal Form	BALL
Terminal Pitch	1 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	27 mm

Alternate Parts for 5CEFA7F27I7N

This table gives cross-reference parts and alternative options found for 5CEFA7F27I7N. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 5CEFA7F27I7N, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number	Manufacturer	Composite Price	Description	Compare
5CEFA7F27I7N	Altera Corporation	Check for Price	Field Programmable Gate Array, 149500-Cell, CMOS, PBGA672, ROHS COMPLIANT, FBGA-672	5CEFA7F27I7N vs 5CEFA7F27I7N

5CEFA7F27I7N Frequently Asked Questions (FAQ)

The recommended operating temperature range for the 5CEFA7F27I7N is -40°C to 125°C, but this may vary depending on the specific application and use case.
To prevent damage, handle the 5CEFA7F27I7N by the body, avoid touching the pins, and store it in an anti-static bag or container in a cool, dry place.
The power sequencing requirements for the 5CEFA7F27I7N typically involve applying power to the core voltage (VCC) before the input/output voltage (VIO), but consult the datasheet for specific requirements.
To troubleshoot issues with the 5CEFA7F27I7N, start by checking the power supply, clock signals, and input/output connections. Consult the datasheet and application notes for specific troubleshooting guidelines.
Yes, the datasheet and application notes provide specific guidelines for layout and routing the 5CEFA7F27I7N to ensure optimal performance and minimize signal integrity issues.
