Part Details for AUIRF7759L2TR by Infineon Technologies AG
Results Overview of AUIRF7759L2TR by Infineon Technologies AG
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (0 replacements)
- Tariff Estimator: (Not Available)
- Number of Functional Equivalents: (8 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Energy and Power Systems
Renewable Energy
AUIRF7759L2TR Information
AUIRF7759L2TR by Infineon Technologies AG is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for AUIRF7759L2TR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
2579960
|
Farnell | MOSFET, N-CH, 75V, 160A, DIRECTFET L8 COO: MX RoHS: Compliant Min Qty: 1 Lead time: 23 Weeks, 1 Days Container: Cut Tape | 6195 |
|
$5.1986 / $6.5542 | Buy Now |
|
DISTI #
2579960RL
|
Farnell | MOSFET, N-CH, 75V, 160A, DIRECTFET L8 COO: MX RoHS: Compliant Min Qty: 100 Lead time: 23 Weeks, 1 Days Container: Reel | 6195 |
|
$5.1986 / $5.3039 | Buy Now |
|
DISTI #
AUIRF7759L2TR
|
Avnet Americas | Trans MOSFET N-CH 75V 160A 15-Pin Direct-FET L8 T/R - Tape and Reel (Alt: AUIRF7759L2TR) COO: Mexico RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 22 Weeks, 0 Days Container: Reel | 0 |
|
$4.9942 / $5.7611 | Buy Now |
|
|
Rochester Electronics | Power Field-Effect Transistor, 26A I(D), 75V, 0.0023ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET RoHS: Compliant Status: Active Min Qty: 1 | 25859 |
|
$3.9400 / $4.9300 | Buy Now |
|
DISTI #
AUIRF7759L2TR
|
Chip One Stop | Semiconductors RoHS: Compliant pbFree: Yes Min Qty: 1 Lead time: 0 Weeks, 1 Days Container: Cut Tape | 2645 |
|
$4.2500 | Buy Now |
|
|
Chip Stock | PowerField-EffectTransistor,375AI(D),1-Element,N-Channel,Metal-oxideSemiconductorFET | 9167 |
|
RFQ | |
|
DISTI #
SP001517184
|
EBV Elektronik | Trans MOSFET NCH 75V 160A 15Pin DirectFET L8 TR (Alt: SP001517184) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 23 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
|
LCSC | 75V 160A 2.3m10V96A 125W 4V 1 N-Channel DirectFET Single FETs MOSFETs RoHS | 1 |
|
$7.7094 / $10.9380 | Buy Now |
Part Details for AUIRF7759L2TR
AUIRF7759L2TR CAD Models
AUIRF7759L2TR Part Data Attributes
|
|
AUIRF7759L2TR
Infineon Technologies AG
Buy Now
Datasheet
|
Compare Parts:
AUIRF7759L2TR
Infineon Technologies AG
Power Field-Effect Transistor, 26A I(D), 75V, 0.0023ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | INFINEON TECHNOLOGIES AG | |
| Reach Compliance Code | Compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | Infineon | |
| Avalanche Energy Rating (Eas) | 257 mJ | |
| Case Connection | DRAIN | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 75 V | |
| Drain Current-Max (ID) | 26 A | |
| Drain-source On Resistance-Max | 0.0023 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JESD-30 Code | R-XBCC-N9 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 9 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 175 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Shape | RECTANGULAR | |
| Package Style | CHIP CARRIER | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 125 W | |
| Pulsed Drain Current-Max (IDM) | 640 A | |
| Reference Standard | AEC-Q101 | |
| Surface Mount | YES | |
| Terminal Form | NO LEAD | |
| Terminal Position | BOTTOM | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
