M50-3302542 by: Harwin

Board Connector, 100 Contact(s), 2 Row(s), Female, 0.05 inch Pitch, IDC Terminal, Locking,

Part Details for M50-3302542 by Harwin

Results Overview of M50-3302542 by Harwin

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Internet of Things (IoT) Environmental Monitoring Financial Technology (Fintech) Energy and Power Systems Telecommunications Renewable Energy Automotive

M50-3302542 Information

M50-3302542 by Harwin is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.

Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.

Price & Stock for M50-3302542

Part # Distributor Description Stock Price Buy
DISTI # 69W6618
Newark Connector, Rcpt, 50Pos, 2Row, 1.27Mm, Idc Connector Type:Idc Receptacle, Contact Gender:Female, Pitch Spacing:1.27Mm, No. Of Rows:2 Row, No. Of Contacts:50Contacts, Connector Mounting:Cable Mount, Contact Material:Phosphor Bronze Rohs Compliant: Yes |Harwin M50-3302542 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk 529
  • 1 $5.4100
  • 10 $4.9800
  • 25 $4.5600
  • 50 $4.3700
  • 100 $4.1900
  • 250 $4.0500
  • 500 $3.8600
  • 1,000 $3.7000
$3.7000 / $5.4100 Buy Now
DISTI # M50-3302542
TME PIN: 50, female, IDC, straight, 1.27mm Min Qty: 1 2000
  • 1 $4.6400
  • 10 $3.8900
  • 16 $3.7800
  • 32 $3.6200
  • 64 $3.4900
  • 112 $3.3600
  • 256 $3.2200
  • 512 $3.0600
$3.0600 / $4.6400 Buy Now
Powell Electronics Headers & Wire Housings Min Qty: 1 21
  • 1 $7.4500
  • 176 $5.2200
$5.2200 / $7.4500 Buy Now
DISTI # M50-3302542
Avnet Abacus 127mm 005 Pitch DIL Female IDC Ribbon Cable Connector selective gold tin 2525 contacts (Alt: M50-3302542) RoHS: Compliant Min Qty: 16 Package Multiple: 16 Lead time: 13 Weeks, 0 Days Abacus - 0
Buy Now

US Tariff Estimator: M50-3302542 by Harwin

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

M50-3302542
Harwin
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for M50-3302542

M50-3302542 Part Data Attributes

Parametric Data
M50-3302542 Harwin
Buy Now Datasheet
Compare Parts:
M50-3302542 Harwin Board Connector, 100 Contact(s), 2 Row(s), Female, 0.05 inch Pitch, IDC Terminal, Locking,
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer HARWIN PLC
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8536.69.40.40
Schedule B Code 8536.69.40.40
CAGE Code K0536, 06EX9
UNSPSC 31163100
Samacsys Description 1.27mm (0.05") Pitch DIL Female IDC Ribbon Cable Connector, selective gold + tin, 25+25 contacts
Samacsys Manufacturer Harwin
Samacsys Modified On 2025-07-02 10:58:48
Category CO2 Kg 3.7
Compliance Temperature Grade Industrial: -40C to +105C
EU RoHS Version RoHS 2 (2015/863/EU)
Candidate List Date 2025-06-25
Conflict Mineral Status DRC Conflict Free
Conflict Mineral Status Source CMRT V6.40
Body Breadth 0.159 inch
Body Depth 0.125 inch
Body Length 1.415 inch
Connector Type BOARD CONNECTOR
Contact Design PREASSEM CONN
Contact Finish Mating NOT APPLICABLE
Contact Finish Termination Tin (Sn) - with Nickel (Ni) barrier
Contact Gender FEMALE
Contact Material PHOSPHOR BRONZE
Contact Pattern RECTANGULAR
Contact Resistance 30 mΩ
Contact Style SQ PIN-SKT
Durability 100 Cycles
Filter Feature NO
Insertion Force-Max 1.0008 N
Insulation Resistance 1000000000 Ω
Insulator Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
JESD-609 Code e3
Mating Contact Pitch 0.05 inch
Mating Contact Row Spacing 0.05 inch
Mixed Contacts NO
Mounting Option 1 LOCKING
Mounting Type CABLE
Number Of Connectors ONE
Number of Rows Loaded 2
Operating Temperature-Max 105 °C
Operating Temperature-Min -40 °C
Rated Current (Signal) 1 A
Reference Standard UL
Termination Type IDC
Total Number of Contacts 100
Withdrawl Force-Min .15012 N
