Part Details for NTGS4111PT1G by onsemi
Results Overview of NTGS4111PT1G by onsemi
- Distributor Offerings: (21 listings)
- Number of FFF Equivalents: (0 replacements)
- Tariff Estimator: (Not Available)
- Number of Functional Equivalents: (0 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Industrial Automation
NTGS4111PT1G Information
NTGS4111PT1G by onsemi is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for NTGS4111PT1G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
10N9575
|
Newark | P Channel Mosfet, -30V, 4.7A, Tsop, Channel Type:P Channel, Drain Source Voltage Vds:30V, Continuous Drain Current Id:4.7A, Transistor Mounting:Surface Mount, Rds(On) Test Voltage:10V, Gate Source Threshold Voltage Max:3V Rohs Compliant: Yes |Onsemi NTGS4111PT1G RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 6592 |
|
$0.0570 | Buy Now |
|
DISTI #
79AH5564
|
Newark | Pfet Tsop6 30V 4.7A 60Moh Rohs Compliant: Yes |Onsemi NTGS4111PT1G RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 3000 |
|
$0.2090 / $0.2380 | Buy Now |
|
DISTI #
45J2137
|
Newark | P Channel Mosfet, -30V, 4.7A, Tsop, Full Reel, Channel Type:P Channel, Drain Source Voltage Vds:30V, Continuous Drain Current Id:4.7A, Transistor Mounting:Surface Mount, Rds(On) Test Voltage:10V, Gate Source Threshold Voltage Max:3V Rohs Compliant: Yes |Onsemi NTGS4111PT1G RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.2180 / $0.2470 | Buy Now |
|
DISTI #
NTGS4111PT1G
|
Avnet Americas | - Tape and Reel (Alt: NTGS4111PT1G) COO: Malaysia RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 19 Weeks, 0 Days Container: Reel | 3000 |
|
$0.1115 / $0.1208 | Buy Now |
|
DISTI #
10N9575
|
Avnet Americas | - Product that comes on tape, but is not reeled (Alt: 10N9575) COO: Malaysia RoHS: Compliant Min Qty: 1 Package Multiple: 1 Container: Ammo Pack | 6592 Partner Stock |
|
$0.2230 / $0.4050 | Buy Now |
|
DISTI #
70341326
|
RS | NTGS4111PT1G P-CHANNEL MOSFET TRANSISTOR, 4.7 A, 30 V, 6-PIN TSOP Min Qty: 1 Package Multiple: 1 Container: Bulk | 0 |
|
$0.3200 | RFQ |
|
|
Bristol Electronics | 2418 |
|
RFQ | ||
|
|
Bristol Electronics | Min Qty: 7 | 1427 |
|
$0.1524 / $0.7620 | Buy Now |
|
DISTI #
NTGS4111PT1G
|
TME | Transistor: P-MOSFET, unipolar, -30V, -2.7A, 1.25W, TSOP6 Min Qty: 1 | 0 |
|
$0.1810 / $0.4400 | RFQ |
|
DISTI #
NTGS4111PT1G
|
IBS Electronics | NTGS4111PT1G P-CHANNEL MOSFET TRANSISTOR 4.7 A 30 V 6-PIN TSOP | ON SEMICONDUCTOR NTGS4111PT1G Min Qty: 3000 Package Multiple: 1 | 6000 |
|
$0.1890 / $0.1974 | Buy Now |
Part Details for NTGS4111PT1G
NTGS4111PT1G CAD Models
NTGS4111PT1G Part Data Attributes
|
|
NTGS4111PT1G
onsemi
Buy Now
Datasheet
|
Compare Parts:
NTGS4111PT1G
onsemi
Single P-Channel Power MOSFET -30V -4.7A 60mΩ, TSOP-6, 3000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Part Package Code | TSOP-6 | |
| Package Description | Tsop-6 | |
| Pin Count | 6 | |
| Manufacturer Package Code | 318G-02 | |
| Reach Compliance Code | Compliant | |
| ECCN Code | EAR99 | |
| Configuration | Single With Built-In Diode | |
| DS Breakdown Voltage-Min | 30 V | |
| Drain Current-Max (ID) | 2.6 A | |
| Drain-source On Resistance-Max | 0.06 Ω | |
| FET Technology | Metal-Oxide Semiconductor | |
| Feedback Cap-Max (Crss) | 105 Pf | |
| JESD-30 Code | R-PDSO-G6 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 6 | |
| Operating Mode | Enhancement Mode | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Shape | Rectangular | |
| Package Style | Small Outline | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | P-Channel | |
| Power Dissipation-Max (Abs) | 1.25 W | |
| Pulsed Drain Current-Max (IDM) | 15 A | |
| Qualification Status | Not Qualified | |
| Surface Mount | Yes | |
| Terminal Finish | Matte Tin | |
| Terminal Form | Gull Wing | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Transistor Application | Switching | |
| Transistor Element Material | Silicon | |
| Turn-off Time-Max (toff) | 106 Ns | |
| Turn-on Time-Max (ton) | 48 Ns |
