PDTC144EU - 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ@en-us SC-70 3-Pin

Part Details for PDTC144EU,115 by Nexperia

Results Overview of PDTC144EU,115 by Nexperia

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Audio and Video Systems

PDTC144EU,115 Information

PDTC144EU,115 by Nexperia is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for PDTC144EU,115

Part # Distributor Description Stock Price Buy
DISTI # 05W5688
Newark Transistor, Npn, 50V, W/Res, Sot323, Transistor Polarity:Single Npn, Collector Emitter Voltage Max Npn:50V, Collector Emitter Voltage Max Pnp:-, Continuous Collector Current:100Ma, Base Input Resistor R1:47Kohm, No. Of Pins:3 Pin Rohs Compliant: Yes |Nexperia PDTC144EU,115 RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape 0
  • 1 $0.1890
  • 10 $0.1160
  • 25 $0.1010
  • 50 $0.0860
  • 100 $0.0720
  • 250 $0.0620
  • 500 $0.0530
  • 1,000 $0.0450
$0.0450 / $0.1890 Buy Now
DISTI # 97W2498
Newark Bipolar Pre-Biased/Digital Transistor, Brt, 50 V, 100 Ma, 47 Kohm, 47 Kohm, 1, Sot-323 Rohs Compliant: Yes |Nexperia PDTC144EU,115 RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 1 Container: Reel 0
  • 3,000 $0.0280
  • 6,000 $0.0270
  • 12,000 $0.0230
$0.0230 / $0.0280 Buy Now
DISTI # PDTC144EU,115
Avnet Americas - Tape and Reel (Alt: PDTC144EU,115) COO: Malaysia RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 8 Weeks, 0 Days Container: Reel 0
  • 3,000 $0.0217
  • 6,000 $0.0212
  • 12,000 $0.0209
  • 24,000 $0.0206
  • 48,000 $0.0203
$0.0203 / $0.0217 Buy Now
Rochester Electronics Small Signal Bipolar Transistor, 0.1A I(C), 50V V(BR)CEO, 1-Element, NPN, Silicon RoHS: Compliant Status: Active Min Qty: 1 820
  • 100 $0.0324
  • 500 $0.0292
  • 1,000 $0.0269
  • 10,000 $0.0240
  • 100,000 $0.0201
$0.0201 / $0.0324 Buy Now
DISTI # PDTC144EU.115
TME Transistor: NPN, bipolar, BRT, 50V, 0.1A, 200mW, SC70,SOT323 Min Qty: 1 1382
  • 1 $0.2300
  • 10 $0.1760
  • 50 $0.1210
$0.1210 / $0.2300 Buy Now
Ameya Holding Limited PDTC144EU Series 50 V 100 mA SMT NPN Resistor-Equipped Transistor - SOT-323 20000
RFQ
DISTI # PDTC144EU,115
Avnet Asia (Alt: PDTC144EU,115) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 8 Weeks, 0 Days 6000
  • 3,000 $0.0217
  • 9,000 $0.0184
  • 15,000 $0.0152
  • 30,000 $0.0144
  • 75,000 $0.0140
  • 150,000 $0.0136
  • 300,000 $0.0132
$0.0132 / $0.0217 Buy Now
DISTI # PDTC144EU,115
Chip One Stop Semiconductors RoHS: Compliant Min Qty: 1 Lead time: 0 Weeks, 1 Days Container: Cut Tape 14245
  • 1 $0.1390
  • 300,000,000 $0.0113
$0.0113 / $0.1390 Buy Now
Chip Stock TransDigitalBJTNPN50V100mA200mWAutomotive3-PinSC-70T/R 133000
RFQ

Part Details for PDTC144EU,115

PDTC144EU,115 Part Data Attributes

Parametric Data
PDTC144EU,115 Nexperia
Buy Now Datasheet
Compare Parts:
PDTC144EU,115 Nexperia PDTC144EU - 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ@en-us SC-70 3-Pin
Rohs Code Yes
Part Life Cycle Code Active
Part Package Code SC-70
Package Description Sc-70, 3 Pin
Pin Count 3
Manufacturer Package Code SOT323
Reach Compliance Code Compliant
ECCN Code EAR99
Factory Lead Time 8 Weeks
Date Of Intro 1997-09-01
Additional Feature Built In Bias Resistance Ratio Is 1
Collector Current-Max (IC) 0.1 A
Collector-Emitter Voltage-Max 50 V
Configuration Single With Built-In Resistor
DC Current Gain-Min (hFE) 80
JESD-30 Code R-PDSO-G3
JESD-609 Code e3
Moisture Sensitivity Level 1
Number of Elements 1
Number of Terminals 3
Operating Temperature-Max 150 °C
Package Body Material Plastic/Epoxy
Package Shape Rectangular
Package Style Small Outline
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type Npn
Qualification Status Not Qualified
Surface Mount Yes
Terminal Finish Tin
Terminal Form Gull Wing
Terminal Position Dual
Time@Peak Reflow Temperature-Max (s) 30
Transistor Application Switching
Transistor Element Material Silicon

Alternate Parts for PDTC144EU,115

This table gives cross-reference parts and alternative options found for PDTC144EU,115. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of PDTC144EU,115, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
PDTC144EU/ZL Nexperia Check for Price Small Signal Bipolar Transistor PDTC144EU,115 vs PDTC144EU/ZL
PDTC144EU Philips Semiconductors Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 1-Element, NPN, Silicon PDTC144EU,115 vs PDTC144EU
PDTC144EUT/R NXP Semiconductors Check for Price TRANSISTOR 100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, PLASTIC, SC-70, 3 PIN, BIP General Purpose Small Signal PDTC144EU,115 vs PDTC144EUT/R
Part Number Manufacturer Composite Price Description Compare
PDTC144EUT/R Nexperia Check for Price Small Signal Bipolar Transistor PDTC144EU,115 vs PDTC144EUT/R
PDTC144EU-T Nexperia Check for Price Small Signal Bipolar Transistor PDTC144EU,115 vs PDTC144EU-T
PDTC144EU/ZLF Nexperia Check for Price PDTC144EU - 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ@en-us SC-70 3-Pin PDTC144EU,115 vs PDTC144EU/ZLF
PDTC144EU,135 Nexperia Check for Price PDTC144EU - 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ@en-us SC-70 3-Pin PDTC144EU,115 vs PDTC144EU,135
PDTC144EU-Q Nexperia Check for Price Small Signal Bipolar Transistor PDTC144EU,115 vs PDTC144EU-Q
PDTC144EU NXP Semiconductors Check for Price TRANSISTOR 100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, PLASTIC, SC-70, 3 PIN, BIP General Purpose Small Signal PDTC144EU,115 vs PDTC144EU
PDTC144EU/ZLX Nexperia Check for Price PDTC144EU - 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ@en-us SC-70 3-Pin PDTC144EU,115 vs PDTC144EU/ZLX
934044100135 Nexperia Check for Price Small Signal Bipolar Transistor PDTC144EU,115 vs 934044100135
