Resistors / Fixed Resistors / RMCF0402FT4K99
Datasheets
RMCF0402FT4K99 by: SEI Stackpole Electronics Inc

Fixed Resistor, Metal Glaze/thick Film, 0.063W, 4990ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP

Part Details for RMCF0402FT4K99 by SEI Stackpole Electronics Inc

Results Overview of RMCF0402FT4K99 by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

RMCF0402FT4K99 Information

RMCF0402FT4K99 by SEI Stackpole Electronics Inc is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RMCF0402FT4K99

Part # Distributor Description Stock Price Buy
DISTI # RMCF0402FT4K99
Avnet Americas - Tape and Reel (Alt: RMCF0402FT4K99) COO: Taiwan (Province of China) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 17 Weeks, 0 Days Container: Reel 30000
3180000 Factory Stock
  • 10,000 $0.0016
  • 20,000 $0.0016
  • 40,000 $0.0016
  • 80,000 $0.0016
  • 160,000 $0.0015
$0.0015 / $0.0016 Buy Now
Bristol Electronics   27048
RFQ
Bristol Electronics   9980
RFQ
DISTI # RMCF0402FT4K99
IBS Electronics RES THICK FILM 0402 4.99K OHM 1% 0.063W &#xB1, 100PPM/&#xB0, C MOLDED SMD PAPER T/R Min Qty: 10000 Package Multiple: 1 320000
  • 10,000 $0.0015
  • 40,000 $0.0014
  • 100,000 $0.0014
  • 250,000 $0.0013
  • 400,000 $0.0013
$0.0013 / $0.0015 Buy Now
NAC RESISTOR, 0402, 4.99 Kohm, 1%, 0.0625W - Thick film - General Purpose RoHS: Compliant Min Qty: 1 Package Multiple: 10000 2750000
  • 10,000 $0.0030
  • 50,000 $0.0020
  • 250,000 $0.0017
$0.0017 / $0.0030 Buy Now
DISTI # RMCF0402FT4K99
Avnet Asia (Alt: RMCF0402FT4K99) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 12 Weeks, 0 Days 0
  • 10,000 $0.0012
  • 50,000 $0.0010
  • 250,000 $0.0008
  • 500,000 $0.0008
  • 1,000,000 $0.0007
  • 2,000,000 $0.0007
  • 5,000,000 $0.0007
$0.0007 / $0.0012 Buy Now
LCSC 62.5mW 4.99k 100ppm/ Thick Film Resistor 1% 0402 Chip Resistor - Surface Mount RoHS 18700
  • 100 $0.0017
  • 3,000 $0.0016
$0.0016 / $0.0017 Buy Now

US Tariff Estimator: RMCF0402FT4K99 by SEI Stackpole Electronics Inc

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

RMCF0402FT4K99
SEI Stackpole Electronics Inc
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for RMCF0402FT4K99

RMCF0402FT4K99 CAD Models

  • Part Symbol

    schematic symbol

  • Footprint

    pcb footprint

  • 3D Model

    2d presentation

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

RMCF0402FT4K99 Part Data Attributes

Parametric Data
RMCF0402FT4K99 SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RMCF0402FT4K99 SEI Stackpole Electronics Inc Fixed Resistor, Metal Glaze/thick Film, 0.063W, 4990ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Package Description Chip
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8533.21.00.30
Factory Lead Time 16 Weeks
Construction Rectangular
JESD-609 Code e3
Mounting Feature Surface Mount
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.3 Mm
Package Length 1 Mm
Package Shape Rectangular Package
Package Style Smt
Package Width 0.5 Mm
Packing Method Tr, Paper, 7 Inch
Rated Power Dissipation (P) 0.063 W
Rated Temperature 70 °C
Reference Standard Aec-Q200
Resistance 4990 Ω
Resistor Type Fixed Resistor
Size Code 0402
Surface Mount Yes
Technology Metal Glaze/Thick Film
Temperature Coefficient 100 Ppm/°C
Terminal Finish Matte Tin (Sn) - With Nickel (Ni) Barrier
Terminal Shape Wraparound
Tolerance 1%
Working Voltage 50 V

Alternate Parts for RMCF0402FT4K99

This table gives cross-reference parts and alternative options found for RMCF0402FT4K99. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of RMCF0402FT4K99, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
NRC04F4991HTR20F NIC Components Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 4990ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP RMCF0402FT4K99 vs NRC04F4991HTR20F
CR0402FF4991G LIZ Electronics (Kunshan) Co., Ltd Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.0625W, 4990ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP RMCF0402FT4K99 vs CR0402FF4991G
CR10-4991FK ASJ Holdings Limited Check for Price Fixed Resistor RMCF0402FT4K99 vs CR10-4991FK
CRCW0402-HP1004K991%EF4E3 Vishay Intertechnologies Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 4990ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, RMCF0402FT4K99 vs CRCW0402-HP1004K991%EF4E3
AR10-4991-FK ASJ Holdings Limited Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.0625W, 4990ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP RMCF0402FT4K99 vs AR10-4991-FK
ASAS10-4991-FK ASJ Holdings Limited Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.0625W, 4990ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP RMCF0402FT4K99 vs ASAS10-4991-FK
RAT024991FH2 Ralec Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.0625W, 4990ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP RMCF0402FT4K99 vs RAT024991FH2
AF0402FR-7D4K99L YAGEO Corporation Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.0625W, 4990ohm, 50V, 1% +/-Tol, -100,100ppm/Cel, 0402, RMCF0402FT4K99 vs AF0402FR-7D4K99L
RAT024991FH4 Ralec Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.0625W, 4990ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP RMCF0402FT4K99 vs RAT024991FH4
RM04FLN4991 TA-I Technology Co Ltd Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.0625W, 4990ohm, 50V, 1% +/-Tol, -200,200ppm/Cel, 0402, RMCF0402FT4K99 vs RM04FLN4991
equivalents icon

RMCF0402FT4K99 Related Parts

RMCF0402FT4K99 Frequently Asked Questions (FAQ)

  • The recommended land pattern for RMCF0402FT4K99 is a rectangular pad with a size of 0.5mm x 1.25mm, with a non-solder mask defined (NSMD) pad shape.

  • Yes, RMCF0402FT4K99 is rated for operation up to 150°C, making it suitable for high-temperature applications. However, derating may be necessary for prolonged exposure to high temperatures.

  • Handle the RMCF0402FT4K99 by the edges to prevent damage to the component. Avoid touching the component's terminals or body to prevent electrostatic discharge (ESD) damage.

  • The recommended soldering profile for RMCF0402FT4K99 is a peak temperature of 260°C, with a dwell time of 10-30 seconds. A soldering iron with a temperature range of 200-240°C is recommended.

  • Yes, RMCF0402FT4K99 is compatible with lead-free soldering. The component is designed to meet the requirements of the RoHS directive.
