Resistors / Fixed Resistors / RMCF0603FT330R
Datasheets
RMCF0603FT330R by: SEI Stackpole Electronics Inc

Fixed Resistor, Metal Glaze/thick Film, 0.1W, 330ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP

Part Details for RMCF0603FT330R by SEI Stackpole Electronics Inc

Results Overview of RMCF0603FT330R by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

RMCF0603FT330R Information

RMCF0603FT330R by SEI Stackpole Electronics Inc is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RMCF0603FT330R

Part # Distributor Description Stock Price Buy
DISTI # RMCF0603FT330R
Avnet Americas - Tape and Reel (Alt: RMCF0603FT330R) COO: Taiwan (Province of China) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 17 Weeks, 0 Days Container: Reel 10000
385000 Factory Stock
  • 5,000 $0.0019
  • 10,000 $0.0019
  • 20,000 $0.0019
  • 30,000 $0.0018
  • 40,000 $0.0018
$0.0018 / $0.0019 Buy Now
Bristol Electronics   4100
RFQ
NAC RESISTOR, 0603, 330 ohm, 1%, 0.1W - Thick film - General Purpose RoHS: Compliant Min Qty: 1 Package Multiple: 5000 345000
  • 5,000 $0.0040
  • 25,000 $0.0030
  • 125,000 $0.0020
$0.0020 / $0.0040 Buy Now
NexGen Digital   546
RFQ
DISTI # RMCF0603FT330R
Avnet Asia (Alt: RMCF0603FT330R) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 12 Weeks, 0 Days 0
  • 5,000 $0.0017
  • 25,000 $0.0015
  • 125,000 $0.0011
  • 250,000 $0.0011
  • 500,000 $0.0010
  • 1,000,000 $0.0010
  • 2,500,000 $0.0010
$0.0010 / $0.0017 Buy Now
LCSC 100mW 330 75V 100ppm/ Thick Film Resistor 1% 0603 Chip Resistor - Surface Mount RoHS 14100
  • 100 $0.0024
  • 1,000 $0.0023
$0.0023 / $0.0024 Buy Now

US Tariff Estimator: RMCF0603FT330R by SEI Stackpole Electronics Inc

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

RMCF0603FT330R
SEI Stackpole Electronics Inc
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for RMCF0603FT330R

RMCF0603FT330R CAD Models

  • Part Symbol

    schematic symbol

  • Footprint

    pcb footprint

  • 3D Model

    2d presentation

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

RMCF0603FT330R Part Data Attributes

Parametric Data
RMCF0603FT330R SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RMCF0603FT330R SEI Stackpole Electronics Inc Fixed Resistor, Metal Glaze/thick Film, 0.1W, 330ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer STACKPOLE ELECTRONICS INC
Package Description CHIP
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8533.21.00.30
Factory Lead Time 16 Weeks
Samacsys Manufacturer Stackpole Electronics, Inc.
Construction Rectangular
JESD-609 Code e3
Mounting Feature SURFACE MOUNT
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.45 mm
Package Length 1.55 mm
Package Shape RECTANGULAR PACKAGE
Package Style SMT
Package Width 0.8 mm
Packing Method TR, PAPER, 7 INCH
Rated Power Dissipation (P) 0.1 W
Rated Temperature 70 °C
Reference Standard AEC-Q200
Resistance 330 Ω
Resistor Type FIXED RESISTOR
Size Code 0603
Surface Mount YES
Technology METAL GLAZE/THICK FILM
Temperature Coefficient 100 ppm/°C
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal Shape WRAPAROUND
Tolerance 1%
Working Voltage 75 V

Alternate Parts for RMCF0603FT330R

This table gives cross-reference parts and alternative options found for RMCF0603FT330R. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of RMCF0603FT330R, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
WR06X3300FBL Walsin Technology Corporation Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.1W, 330ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP, LEAD FREE RMCF0603FT330R vs WR06X3300FBL
HASG03FVEX3300A Hitano Enterprise Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.1W, 330ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP RMCF0603FT330R vs HASG03FVEX3300A
RS-03K3300FT Fenghua (HK) Electronics Ltd Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.1W, 330ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP RMCF0603FT330R vs RS-03K3300FT
RMEA0603FT330R SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.1W, 330ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP RMCF0603FT330R vs RMEA0603FT330R
D11/CRCW0603100330R1%ET3E3 Vishay Intertechnologies Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.1W, 330ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, RMCF0603FT330R vs D11/CRCW0603100330R1%ET3E3
WR06X3300FGLV Walsin Technology Corporation Check for Price Fixed Resistor, 0.1W, 330ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP, ROHS COMPLIANT RMCF0603FT330R vs WR06X3300FGLV
RK73H1JGBK3300F KOA Speer Electronics Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 330ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP RMCF0603FT330R vs RK73H1JGBK3300F
D113300FP5-E3 Vishay Intertechnologies Check for Price RESISTOR, METAL GLAZE/THICK FILM, 0.1W, 1%, 100ppm, 330ohm, SURFACE MOUNT, 0603, CHIP RMCF0603FT330R vs D113300FP5-E3
AF0603FR-13330RL YAGEO Corporation Check for Price Fixed Resistor, 0.1W, 330ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP RMCF0603FT330R vs AF0603FR-13330RL
AS03FWE3300A Viking Tech Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.1W, 330ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP RMCF0603FT330R vs AS03FWE3300A
equivalents icon

RMCF0603FT330R Related Parts

RMCF0603FT330R Frequently Asked Questions (FAQ)

  • The recommended soldering temperature profile for RMCF0603FT330R is 250°C for 3-5 seconds, with a peak temperature of 260°C for 1-2 seconds.

  • Yes, RMCF0603FT330R is compatible with lead-free soldering and is RoHS compliant.

  • The MSL of RMCF0603FT330R is MSL 2, which means it can withstand exposure to moisture for up to 4 days without requiring baking.

  • Yes, RMCF0603FT330R is suitable for high-frequency applications up to 1 GHz due to its low equivalent series resistance (ESR) and high self-resonant frequency.

  • The operating temperature range of RMCF0603FT330R is -55°C to 125°C, making it suitable for a wide range of applications.
