Resistors / Fixed Resistors / RMCF0805FG732R
Datasheets
RMCF0805FG732R by: SEI Stackpole Electronics Inc

Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 150V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP

Part Details for RMCF0805FG732R by SEI Stackpole Electronics Inc

Results Overview of RMCF0805FG732R by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

RMCF0805FG732R Information

RMCF0805FG732R by SEI Stackpole Electronics Inc is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RMCF0805FG732R

Part # Distributor Description Stock Price Buy
DISTI # RMCF0805FG732R
Avnet Americas - Tape and Reel (Alt: RMCF0805FG732R) COO: Taiwan (Province of China) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 17 Weeks, 0 Days Container: Reel 0
  • 10,000 $0.0034
  • 20,000 $0.0034
  • 40,000 $0.0034
  • 60,000 $0.0034
  • 80,000 $0.0034
$0.0034 Buy Now
NAC RESISTOR, 0805, 10K 732 ohm, 1%, 0.125W - Thick film - General Purpose RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 0
  • 10,000 $0.0050
  • 50,000 $0.0030
  • 250,000 $0.0026
$0.0026 / $0.0050 Buy Now

US Tariff Estimator: RMCF0805FG732R by SEI Stackpole Electronics Inc

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

RMCF0805FG732R
SEI Stackpole Electronics Inc
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for RMCF0805FG732R

RMCF0805FG732R Part Data Attributes

Parametric Data
RMCF0805FG732R SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RMCF0805FG732R SEI Stackpole Electronics Inc Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 150V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer STACKPOLE ELECTRONICS INC
Package Description CHIP
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8533.21.00.30
Factory Lead Time 17 Weeks
Samacsys Manufacturer Stackpole Electronics, Inc.
Construction Rectangular
JESD-609 Code e3
Mounting Feature SURFACE MOUNT
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.5 mm
Package Length 2 mm
Package Shape RECTANGULAR PACKAGE
Package Style SMT
Package Width 1.25 mm
Packing Method TR, PAPER, 10 INCH
Rated Power Dissipation (P) 0.125 W
Rated Temperature 70 °C
Reference Standard AEC-Q200
Resistance 732 Ω
Resistor Type FIXED RESISTOR
Size Code 0805
Surface Mount YES
Technology METAL GLAZE/THICK FILM
Temperature Coefficient 100 ppm/°C
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal Shape WRAPAROUND
Tolerance 1%
Working Voltage 150 V

Alternate Parts for RMCF0805FG732R

This table gives cross-reference parts and alternative options found for RMCF0805FG732R. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of RMCF0805FG732R, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
RMF10FT7320 TA-I Technology Co Ltd Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP RMCF0805FG732R vs RMF10FT7320
RMEF0805FT732R SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 150V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP RMCF0805FG732R vs RMEF0805FT732R
RTT057320FP2 Ralec Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 150V, 1% +/-Tol, -100,100ppm/Cel, 0805, RMCF0805FG732R vs RTT057320FP2
WR08X7320FTLJ Walsin Technology Corporation Check for Price Fixed Resistor, 0.125W, 732ohm, 150V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP, ROHS COMPLIANT RMCF0805FG732R vs WR08X7320FTLJ
CRCW0805732RFKEA Vishay Intertechnologies Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 150V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP, HALOGEN FREE AND ROHS COMPLIANT RMCF0805FG732R vs CRCW0805732RFKEA
TFA0805R7320F-T5 Thin Film Technology Corp (TFT) Check for Price Fixed Resistor, Metal Glaze/thick Film; Thin Film, 0.125W, 732ohm, 150V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP RMCF0805FG732R vs TFA0805R7320F-T5
9C08052A7320FKPF4 YAGEO Corporation Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 150V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP, LEAD FREE RMCF0805FG732R vs 9C08052A7320FKPF4
CR0805AFX-7320ELF Bourns Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 150V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP RMCF0805FG732R vs CR0805AFX-7320ELF
RAT057320FP4 Ralec Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 150V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP RMCF0805FG732R vs RAT057320FP4
NRCL10F7320TR10F NIC Components Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.125W, 732ohm, 150V, 1% +/-Tol, -100,100ppm/Cel, 0805 RMCF0805FG732R vs NRCL10F7320TR10F
