Resistors / Fixed Resistors / RNCF1206DKE1M37
Datasheets
RNCF1206DKE1M37 by: SEI Stackpole Electronics Inc

Fixed Resistor, Thin Film, 0.125W, 1370000ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP

Part Details for RNCF1206DKE1M37 by SEI Stackpole Electronics Inc

Results Overview of RNCF1206DKE1M37 by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

RNCF1206DKE1M37 Information

RNCF1206DKE1M37 by SEI Stackpole Electronics Inc is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RNCF1206DKE1M37

Part # Distributor Description Stock Price Buy
DISTI # RNCF1206DKE1M37
Avnet Americas - Tape and Reel (Alt: RNCF1206DKE1M37) COO: Taiwan (Province of China) RoHS: Compliant Min Qty: 5000 Package Multiple: 1000 Lead time: 17 Weeks, 0 Days Container: Reel 0
  • 5,000 $0.0600
  • 7,000 $0.0571
  • 12,000 $0.0568
  • 25,000 $0.0566
  • 50,000 $0.0563
$0.0563 / $0.0600 Buy Now
NAC RESISTOR PRECISION, 1.37 Mohm, 1206, 0.5%, 25 ppm - Thin Film - Precision RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 0
  • 5,000 $0.1050
  • 25,000 $0.0700
  • 125,000 $0.0600
$0.0600 / $0.1050 Buy Now

US Tariff Estimator: RNCF1206DKE1M37 by SEI Stackpole Electronics Inc

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

RNCF1206DKE1M37
SEI Stackpole Electronics Inc
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for RNCF1206DKE1M37

RNCF1206DKE1M37 Part Data Attributes

Parametric Data
RNCF1206DKE1M37 SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RNCF1206DKE1M37 SEI Stackpole Electronics Inc Fixed Resistor, Thin Film, 0.125W, 1370000ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Package Description Chip
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8533.21.00.30
Factory Lead Time 17 Weeks
Additional Feature Precision
Construction Rectangular
JESD-609 Code e3
Mounting Feature Surface Mount
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.55 Mm
Package Length 3.05 Mm
Package Shape Rectangular Package
Package Style Smt
Package Width 1.55 Mm
Packing Method Tr, Paper, 7 Inch
Rated Power Dissipation (P) 0.125 W
Rated Temperature 70 °C
Reference Standard Aec-Q200
Resistance 1370000 Ω
Resistor Type Fixed Resistor
Size Code 1206
Surface Mount Yes
Technology Thin Film
Temperature Coefficient 25 Ppm/°C
Terminal Finish Matte Tin (Sn) - With Nickel (Ni) Barrier
Terminal Shape Wraparound
Tolerance 0.5%
Working Voltage 150 V

Alternate Parts for RNCF1206DKE1M37

This table gives cross-reference parts and alternative options found for RNCF1206DKE1M37. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of RNCF1206DKE1M37, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
NTR12D1374CTR1KF NIC Components Corp Check for Price Fixed Resistor, Thin Film, 0.125W, 1370000ohm, 150V, 0.5% +/-Tol, -25,25ppm/Cel, 1206, RNCF1206DKE1M37 vs NTR12D1374CTR1KF
NTR12D1374CTRF NIC Components Corp Check for Price Fixed Resistor, Thin Film, 0.125W, 1370000ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP RNCF1206DKE1M37 vs NTR12D1374CTRF
AR06DTRC3W1374N Token Electronics Industry Co Ltd Check for Price Fixed Resistor, Thin Film, 0.125W, 1370000ohm, 150V, 0.5% +/-Tol, -25,25ppm/Cel, 1206, RNCF1206DKE1M37 vs AR06DTRC3W1374N
RNCF1206DTE1M37 SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Thin Film, 0.125W, 1370000ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP RNCF1206DKE1M37 vs RNCF1206DTE1M37
AR06DBC1374 Viking Tech Corp Check for Price Fixed Resistor, Thin Film, 0.5W, 1370000ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 2512, CHIP RNCF1206DKE1M37 vs AR06DBC1374
AR06DTC1374A Viking Tech Corp Check for Price Fixed Resistor, Thin Film, 0.125W, 1.37e+06ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP RNCF1206DKE1M37 vs AR06DTC1374A
RN73F2BB1374D MERITEK Electronics Corporation Check for Price Fixed Resistor, Thin Film, 0.125W, 1370000ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP RNCF1206DKE1M37 vs RN73F2BB1374D
AR06DBC1374NA Viking Tech Corp Check for Price Fixed Resistor, Thin Film, 0.125W, 1.37e+06ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP RNCF1206DKE1M37 vs AR06DBC1374NA
CPF1206D1M37E1 TE Connectivity Check for Price Fixed Resistor, Thin Film, 0.125W, 1370000ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 1206 RNCF1206DKE1M37 vs CPF1206D1M37E1
CPF1206D1M37E TE Connectivity Check for Price Fixed Resistor, Thin Film, 0.125W, 1370000ohm, 150V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP RNCF1206DKE1M37 vs CPF1206D1M37E
