STS5N15F4 Information
STS5N15F4 by STMicroelectronics is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for STS5N15F4
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
45AC7742
|
Newark | Mosfet, N-Ch, 150V, 5A, Soic, Channel Type:N Channel, Drain Source Voltage Vds:150V, Continuous Drain Current Id:5A, Transistor Mounting:Surface Mount, Rds(On) Test Voltage:10V, Gate Source Threshold Voltage Max:4V, No. Of Pins:8Pinsrohs Compliant: Yes |Stmicroelectronics STS5N15F4 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$0.9960 / $2.0000 | Buy Now |
|
DISTI #
26AM4894
|
Newark | Lv Mosfet Trench Old |Stmicroelectronics STS5N15F4 RoHS: Not Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.6560 | Buy Now |
|
DISTI #
STS5N15F4
|
Avnet Americas | - Tape and Reel (Alt: STS5N15F4) COO: China RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 13 Weeks, 0 Days Container: Reel | 5000 |
|
$0.5983 / $0.6362 | Buy Now |
|
|
STMicroelectronics | N-channel 150 V, 0.057 Ohm, 5 A, SO-8 STripFET(TM) DeepGATE(TM) Power MOSFET COO: Singapore RoHS: Compliant Min Qty: 1 | 1031 |
|
$0.9000 / $2.5000 | Buy Now |
|
DISTI #
STS5N15F4-STM-0
|
TME | Transistor: N-MOSFET, 150V, 5A, 2.5W, SOIC8, SMT Min Qty: 2500 | 2500 |
|
$0.5054 | Buy Now |
|
DISTI #
STS5N15F4
|
IBS Electronics | N-CHANNEL 150 V 0.063 OHM SURFACE MOUNT STRIPFET™, VI DEEPGATE MOSFET - SOIC-8 Min Qty: 2500 Package Multiple: 1 | 82500 |
|
$0.5250 / $0.5390 | Buy Now |
|
DISTI #
STS5N15F4
|
Avnet Silica | (Alt: STS5N15F4) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 14 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
STS5N15F4
|
EBV Elektronik | (Alt: STS5N15F4) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 15 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for STS5N15F4
STS5N15F4 CAD Models
STS5N15F4 Part Data Attributes
|
|
STS5N15F4
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
STS5N15F4
STMicroelectronics
N-channel 150 V, 0.057 Ohm, 5 A, SO-8 STripFET(TM) DeepGATE(TM) Power MOSFET
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Part Package Code | SOT | |
| Package Description | Rohs Compliant, Sop-8 | |
| Pin Count | 8 | |
| Reach Compliance Code | Compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 13 Weeks | |
| Additional Feature | Avalanche Rated | |
| Avalanche Energy Rating (Eas) | 125 Mj | |
| Configuration | Single With Built-In Diode | |
| DS Breakdown Voltage-Min | 150 V | |
| Drain Current-Max (ID) | 5 A | |
| Drain-source On Resistance-Max | 0.063 Ω | |
| FET Technology | Metal-Oxide Semiconductor | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 8 | |
| Operating Mode | Enhancement Mode | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Shape | Rectangular | |
| Package Style | Small Outline | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | N-Channel | |
| Power Dissipation-Max (Abs) | 2.5 W | |
| Pulsed Drain Current-Max (IDM) | 20 A | |
| Qualification Status | Not Qualified | |
| Surface Mount | Yes | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | Gull Wing | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | Not Specified | |
| Transistor Application | Switching | |
| Transistor Element Material | Silicon |
