Part Details for TL431IDR by Texas Instruments
Results Overview of TL431IDR by Texas Instruments
- Distributor Offerings: (10 listings)
- Number of FFF Equivalents: (9 replacements)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (10 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Energy and Power Systems
Renewable Energy
Automotive
TL431IDR Information
TL431IDR by Texas Instruments is a Voltage Reference.
Voltage References are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for TL431IDR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Bristol Electronics | 6729 |
|
RFQ | ||
|
|
Bristol Electronics | Min Qty: 14 | 77 |
|
$0.1875 / $0.3750 | Buy Now |
|
|
Rochester Electronics | TL431 - Adjustable precision shunt regulator RoHS: Compliant Status: Active Min Qty: 1 | 13 |
|
$0.0726 / $0.1171 | Buy Now |
|
DISTI #
TL431IDR
|
TME | IC: voltage reference source, 2.495V, ±2%, SO8, reel,tape, 100mA Min Qty: 1 | 0 |
|
$0.0930 / $0.2130 | RFQ |
|
|
Ameya Holding Limited | Adjustable Precision Shunt Regulator | 843 |
|
RFQ | |
|
|
ComSIT USA | PRECISION PROGRAMMABLE REFERENCE Three Terminal Voltage Reference, 1 Output, 2.495V, Trim/Adjustable, BIPolar, PDSO8 ECCN: EAR99 RoHS: Not Compliant |
|
|
RFQ | |
|
|
Chip 1 Exchange | INSTOCK | 577 |
|
RFQ | |
|
|
Component Electronics, Inc | SMT TAPE | 94 |
|
$0.7800 / $1.1900 | Buy Now |
|
|
LCSC | 2.495V36V 2% 100mA Adjustable SOIC-8 Voltage Reference RoHS | 810 |
|
$0.0773 / $0.1730 | Buy Now |
|
|
Win Source Electronics | IC VREF SHUNT ADJ 8SOIC | 47410 |
|
$0.0625 / $0.0806 | Buy Now |
US Tariff Estimator: TL431IDR by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
Part Details for TL431IDR
TL431IDR CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
TL431IDR Part Data Attributes
|
|
TL431IDR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TL431IDR
Texas Instruments
Adjustable precision shunt regulator 8-SOIC -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SOIC | |
| Package Description | SOP, SOP8,.25 | |
| Pin Count | 8 | |
| Reach Compliance Code | Compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.60 | |
| Samacsys Manufacturer | Texas Instruments | |
| Analog IC - Other Type | TWO TERMINAL VOLTAGE REFERENCE | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e4 | |
| Length | 4.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 0.1 A | |
| Output Voltage-Max | 2.55 V | |
| Output Voltage-Min | 2.44 V | |
| Output Voltage-Nom | 2.495 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP8,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Temp Coef of Voltage-Max | 92 ppm/°C | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Trim/Adjustable Output | YES | |
| Voltage Tolerance-Max | 2.204408% | |
| Width | 3.9 mm |
Alternate Parts for TL431IDR
This table gives cross-reference parts and alternative options found for TL431IDR. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of TL431IDR, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| TL431IDT | STMicroelectronics | $0.1773 | Adjustable micropower shunt voltage reference | TL431IDR vs TL431IDT |
| TL431CD | Texas Instruments | Check for Price | Adjustable precision shunt regulator 8-SOIC 0 to 70 | TL431IDR vs TL431CD |
| TL431IDG | Rochester Electronics LLC | Check for Price | Three Terminal Voltage Reference, 1 Output, 2.495V, Trim/Adjustable, BIPolar, PDSO8, LEAD FREE, PLASTIC, SOIC-8 | TL431IDR vs TL431IDG |
| TL431CD-T | NXP Semiconductors | Check for Price | 1-OUTPUT THREE TERM VOLTAGE REFERENCE, 2.495V, PDSO8 | TL431IDR vs TL431CD-T |
| TL431IDR | Rochester Electronics LLC | Check for Price | Three Terminal Voltage Reference, 1 Output, 2.495V, Trim/Adjustable, BIPolar, PDSO8, GREEN, PLASTIC, SOIC-8 | TL431IDR vs TL431IDR |
| TL431CDR2 | Rochester Electronics LLC | Check for Price | Three Terminal Voltage Reference, 1 Output, 2.495V, Trim/Adjustable, BIPolar, PDSO8, PLASTIC, SOIC-8 | TL431IDR vs TL431CDR2 |
| TL431IYDT | STMicroelectronics | Check for Price | Adjustable micropower shunt voltage reference | TL431IDR vs TL431IYDT |
| TL431IDG4 | Texas Instruments | Check for Price | Adjustable precision shunt regulator 8-SOIC -40 to 85 | TL431IDR vs TL431IDG4 |
| TL431ID | onsemi | Check for Price | 1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.495V, PDSO8, PLASTIC, SOIC-8 | TL431IDR vs TL431ID |
TL431IDR Frequently Asked Questions (FAQ)
-
The recommended operating temperature range for TL431IDR is -40°C to 125°C.
-
To ensure stability, it's recommended to use a minimum output capacitance of 10uF and a minimum ESR of 0.1 ohms, and to place the capacitor close to the TL431IDR.
-
Yes, TL431IDR is suitable for high-temperature environments, but its voltage reference accuracy may degrade at temperatures above 100°C. It's recommended to use a voltage reference with a tighter tolerance, such as the TLV431, for high-temperature applications.
-
The output voltage of a TL431IDR-based voltage regulator can be calculated using the formula: Vout = Vref x (R1 + R2) / R2, where Vref is the reference voltage (2.5V for TL431IDR), R1 and R2 are the resistors in the voltage divider network.
-
TL431IDR is designed for low-current applications (up to 100mA). For high-current applications, it's recommended to use a more suitable device, such as the TLV431 or a dedicated voltage regulator IC.
