Part Details for UCC38083D by Texas Instruments
Results Overview of UCC38083D by Texas Instruments
- Distributor Offerings: (3 listings)
- Number of FFF Equivalents: (1 replacement)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (6 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
UCC38083D Information
UCC38083D by Texas Instruments is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| UCC38083D | Texas Instruments | Current Mode Push-Pull PWM With Programmable Slope Compensation 8-SOIC 0 to 70 | |
| UCC38083DR | Texas Instruments | Current Mode Push-Pull PWM With Programmable Slope Compensation 8-SOIC 0 to 70 |
Price & Stock for UCC38083D
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Rochester Electronics | UCC38083 Current Mode Push-Pull PWM With Programmable Slope Compensation RoHS: Compliant Status: Obsolete Min Qty: 1 | 4730 |
|
$1.9100 / $2.3900 | Buy Now |
|
|
Ameya Holding Limited | UCC38083D, 双 PWM 电流模式控制器, 1 A, 升压/降压、推挽式, 1000 kHz, 8针 SOIC封装 | 4016 |
|
RFQ | |
|
|
ComSIT USA | 8-PIN CURRENT MODE PUSH-PULL PWM CONTROLLER WITH PROGRAMMABLE SLOPE COMPENSATION Switching Controller, Current-mode, 1A, 1000kHz Switching Freq-Max, BICMOS, PDSO8 ECCN: EAR99 RoHS: Compliant |
|
|
RFQ |
US Tariff Estimator: UCC38083D by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
Part Details for UCC38083D
UCC38083D CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
UCC38083D Part Data Attributes
|
|
UCC38083D
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
UCC38083D
Texas Instruments
Current mode push-pull PWM with prog. slope comp, 3.5ms soft start, 12.5/8.3 UVLO, 0°C to 70°C 8-SOIC 0 to 70
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Part Package Code | SOIC | |
| Package Description | Sop, Sop8,.25 | |
| Pin Count | 8 | |
| Reach Compliance Code | Compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.60 | |
| Analog IC - Other Type | Switching Controller | |
| Control Mode | Current-Mode | |
| Control Technique | Pulse Width Modulation | |
| Input Voltage-Max | 15 V | |
| Input Voltage-Min | 9.3 V | |
| Input Voltage-Nom | 10 V | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e4 | |
| Length | 4.9 Mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Output Current-Max | 1 A | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | SOP | |
| Package Equivalence Code | SOP8,.25 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 Mm | |
| Supply Current-Max (Isup) | 2.5 Ma | |
| Supply Voltage-Max (Vsup) | 15 V | |
| Supply Voltage-Min (Vsup) | 12.5 V | |
| Surface Mount | Yes | |
| Switcher Configuration | Push-Pull | |
| Switching Frequency-Max | 1000 Khz | |
| Technology | Bicmos | |
| Temperature Grade | Commercial | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 1.27 Mm | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.9 Mm |
Alternate Parts for UCC38083D
This table gives cross-reference parts and alternative options found for UCC38083D. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of UCC38083D, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| UCC38083DRG4 | Texas Instruments | Check for Price | Current Mode Push-Pull PWM With Programmable Slope Compensation 8-SOIC 0 to 70 | UCC38083D vs UCC38083DRG4 |
UCC38083D Frequently Asked Questions (FAQ)
-
Texas Instruments recommends a compact layout with short traces, and placing the device close to the power stage. Additionally, a solid ground plane and a separate analog ground plane can help reduce noise and EMI. A 4-layer PCB with a dedicated power plane and a dedicated ground plane is also recommended.
-
The recommended value for the VCC bypass capacitor is 1uF to 10uF, with a voltage rating of at least 10V. A higher value can help improve noise immunity, but may increase the startup time. A low-ESR ceramic capacitor is recommended.
-
The maximum allowed voltage on the VCC pin is 15V, but it's recommended to keep it below 12V to ensure reliable operation and to prevent damage to the device.
-
The switching frequency of the UCC38083D can be adjusted by changing the value of the RT resistor connected to the RT pin. A lower value of RT will result in a higher switching frequency, and vice versa.
-
The bootstrap capacitor is used to provide a voltage source for the high-side driver. The recommended value is 10nF to 100nF, with a voltage rating of at least 10V. A higher value can help improve the high-side driver's performance, but may increase the startup time.
