High Voltage, Current Shunt Monitor

Part Details for AD8211YRJZ-R2 by Analog Devices Inc

Results Overview of AD8211YRJZ-R2 by Analog Devices Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Education and Research Internet of Things (IoT) Computing and Data Storage Aerospace and Defense Healthcare Telecommunications Automotive

AD8211YRJZ-R2 Information

AD8211YRJZ-R2 by Analog Devices Inc is an Operational Amplifier.
Operational Amplifiers are under the broader part category of Amplifier Circuits.

Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.

Price & Stock for AD8211YRJZ-R2

Part # Distributor Description Stock Price Buy
DISTI # 53AK9895
Newark Current Sense Amp, 500Khz, Sot-23, Current Sense Amplifier Type:High Side, Gain Bandwidth Product:500Khz, Ic Case/Package:Sot-23, No. Of Pins:5Pins, Operating Temperature Min:-40°C, Operating Temperature Max:125°C, Cmrr:120Db Rohs Compliant: Yes |Analog Devices AD8211YRJZ-R2 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 268
  • 1 $3.9700
  • 10 $2.7600
  • 25 $2.4200
  • 50 $2.2200
  • 100 $2.0100
  • 250 $1.7800
  • 500 $1.5600
  • 1,000 $1.5100
$1.5100 / $3.9700 Buy Now
Analog Devices Inc High Voltage Current Shunt Amp Min Qty: 1 Package Multiple: 250 33103
  • 1 $4.4500
  • 10 $2.8800
  • 25 $2.4708
  • 100 $2.0075
  • 250 $1.7801
  • 500 $1.6402
  • 1,000 $1.2100
$1.2100 / $4.4500 Buy Now
DISTI # AD8211YRJZ-R2
TME IC: instrumentation amplifier, 500kHz, Uoper: 4.5÷5.5V, SOT23-5 Min Qty: 1 0
  • 1 $4.2900
  • 3 $3.8600
  • 10 $3.6000
  • 50 $3.4700
$3.4700 / $4.2900 RFQ
DISTI # AD8211YRJZ-R2
Richardson RFPD POWER MANAGEMENT IC RoHS: Compliant Min Qty: 250 0
  • 250 $1.6400
  • 500 $1.6000
  • 1,000 $1.5800
$1.5800 / $1.6400 Buy Now
DISTI # SMC-AD8211YRJZ-R2
Sensible Micro Corporation I.C 8211 Sot-23-5 RoHS: Compliant Min Qty: 25 Lead time: 0 Weeks, 1 Days Date Code: 12+ Container: Tape & Reel 4518
  • 100 $0.6825
  • 500 $0.6650
  • 1,000 $0.6300
$0.6300 / $0.6825 RFQ
LCSC -2V65V 500kHz Single channel SOT-23-5 Current Sense Amplifiers ROHS 9
  • 1 $2.3015
  • 10 $2.2532
  • 30 $2.0187
  • 100 $1.9864
$1.9864 / $2.3015 Buy Now
Vyrian Amplifiers 8419
RFQ
Win Source Electronics IC CURRENT MONITOR 0.25% SOT23-5 18380
  • 35 $1.4638
  • 75 $1.3694
  • 115 $1.3222
  • 165 $1.2278
  • 215 $1.1805
  • 265 $1.1333
$1.1333 / $1.4638 Buy Now

Part Details for AD8211YRJZ-R2

AD8211YRJZ-R2 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

AD8211YRJZ-R2 Part Data Attributes

Parametric Data
AD8211YRJZ-R2 Analog Devices Inc
Buy Now Datasheet
Compare Parts:
AD8211YRJZ-R2 Analog Devices Inc High Voltage, Current Shunt Monitor
Pbfree Code No
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer ANALOG DEVICES INC
Part Package Code SOIC
Package Description ROHS COMPLIANT, MO-178AA, SOT-23, 5 PIN
Pin Count 5
Manufacturer Package Code RJ-5
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.33.00.01
Samacsys Manufacturer Analog Devices
Amplifier Type OPERATIONAL AMPLIFIER
JESD-30 Code R-PDSO-G5
JESD-609 Code e3
Length 2.9 mm
Moisture Sensitivity Level 1
Number of Functions 1
Number of Terminals 5
Package Body Material PLASTIC/EPOXY
Package Code LSSOP
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Seated Height-Max 1.45 mm
Surface Mount YES
Temperature Grade AUTOMOTIVE
Terminal Finish Matte Tin (Sn)
Terminal Form GULL WING
Terminal Pitch 0.95 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Width 1.6 mm

AD8211YRJZ-R2 Related Parts

AD8211YRJZ-R2 Frequently Asked Questions (FAQ)

  • A good PCB layout for the AD8211YRZ-R2 involves keeping the input and output traces separate, using a ground plane, and placing the device close to the signal source. Additionally, it's recommended to use a low-ESR capacitor for the VCC bypass and to keep the input and output capacitors close to the device.

  • To ensure accuracy, it's essential to use a high-precision shunt resistor, ensure the shunt resistor is at the same temperature as the device, and calibrate the system using a known current source. Additionally, it's recommended to use a low-noise power supply and to minimize electromagnetic interference (EMI) in the system.

  • The AD8211YRJZ-R2 can measure currents up to ±3 A, but it's recommended to limit the current to ±2 A for optimal accuracy and to prevent overheating.

  • Temperature compensation can be achieved by using a thermistor or a temperature sensor to measure the temperature and adjust the gain accordingly. Additionally, it's recommended to use a temperature-stable shunt resistor and to calibrate the system over the operating temperature range.
