ADG438FBRZ-REEL by:

High Performance, 8-Channel, Fault-Protected Analog Multiplexer

Part Details for ADG438FBRZ-REEL by Analog Devices Inc

Overview of ADG438FBRZ-REEL by Analog Devices Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Education and Research Internet of Things (IoT) Computing and Data Storage Aerospace and Defense Healthcare Telecommunications Automotive

Available Datasheets

Part # Manufacturer Description Datasheet
74AC521SC REEL Rochester Electronics LLC 74AC521 - Identity Comparator, AC Series, 8-Bit, Inverted Output, CMOS
ICL7660CBA-T Renesas Electronics Corporation CMOS Voltage Converters, SOICN, /Reel
ICL7660SCBA-T Renesas Electronics Corporation Super Voltage Converter, SOICN, /Reel

Price & Stock for ADG438FBRZ-REEL

Part # Distributor Description Stock Price Buy
Analog Devices Inc FAULT PROTECTED MULTIPLEXER I. Min Qty: 1 Package Multiple: 2500 2813
  • 1 $14.0900
  • 10 $10.0090
  • 25 $8.9596
  • 100 $7.7866
  • 250 $7.2188
  • 500 $6.8731
  • 1,000 $6.7000
  • 2,500 $6.7000
$6.7000 / $14.0900 Buy Now
Win Source Electronics IC MULTIPLEXER 8X1 16SOIC 5400
  • 5 $10.9452
  • 12 $8.9807
  • 18 $8.7001
  • 24 $8.4194
  • 31 $8.1388
  • 42 $7.2968
$7.2968 / $10.9452 Buy Now

Part Details for ADG438FBRZ-REEL

ADG438FBRZ-REEL CAD Models

There are no models available for this part yet.

Sign in to request this CAD model.

Register or Sign In

ADG438FBRZ-REEL Part Data Attributes

ADG438FBRZ-REEL Analog Devices Inc
Buy Now Datasheet
Compare Parts:
ADG438FBRZ-REEL Analog Devices Inc High Performance, 8-Channel, Fault-Protected Analog Multiplexer
Pbfree Code No
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer ANALOG DEVICES INC
Part Package Code SOIC
Package Description ROHS COMPLIANT, MS-012AC, SOIC-16
Pin Count 16
Manufacturer Package Code R-16
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Samacsys Manufacturer Analog Devices
Analog IC - Other Type SINGLE-ENDED MULTIPLEXER
JESD-30 Code R-PDSO-G16
JESD-609 Code e3
Length 9.9 mm
Moisture Sensitivity Level 1
Neg Supply Voltage-Nom (Vsup) -15 V
Number of Channels 8
Number of Functions 1
Number of Terminals 16
Off-state Isolation-Nom 93 dB
On-state Resistance Match-Nom 8.1 Ω
On-state Resistance-Max (Ron) 270 Ω
Operating Temperature-Max 125 °C
Operating Temperature-Min -40 °C
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP16,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Seated Height-Max 1.75 mm
Signal Current-Max 0.02 A
Supply Current-Max (Isup) 0.2 mA
Supply Voltage-Nom (Vsup) 15 V
Surface Mount YES
Switch-off Time-Max 173 ns
Switch-on Time-Max 345 ns
Switching BREAK-BEFORE-MAKE
Technology CMOS
Temperature Grade AUTOMOTIVE
Terminal Finish Matte Tin (Sn)
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Width 3.9 mm
