Drivers And Interfaces
ADUM1250ARZ
Description: Hot Swappable, Dual I<sup>2</sup>C Isolators

Overview of ADUM1250ARZ by Analog Devices Inc

Note: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
  • Distributor Offerings: ( 15 listings )
  • Number of FFF Equivalents: ( 0 crosses )
  • CAD Models: ( Available )
  • Number of Functional Equivalents: ( 0 crosses )
  • Part Data Attributes ( Available )
  • Reference Designs: ( Not Available )
Where used in Applications: Aerospace and Defense Automotive

Price & Stock for ADUM1250ARZ by Analog Devices Inc

Part # Manufacturer Description Stock Price Buy
DISTI # 53AK9447
Newark Digital Isolator, 2Ch, -40 To 105Deg C, No. Of Channels:2Channels, Supply Voltage Min:3V, Supply Voltage Max:5.5V, Ic Case/Package:Nsoic, No. Of Pins:8Pins, Data Rate:1Mbps, Input Level:-, Output Level:-, Isolation Type:Magnetic Rohs Compliant: Yes |Analog Devices ADUM1250ARZ Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk 298
  • 1 $6.8500
  • 10 $6.1900
  • 25 $5.8300
  • 50 $5.4800
  • 196 $5.1200
  • 294 $5.0100
  • 588 $4.8900
$4.8900 / $6.8500 Buy Now
Analog Devices Inc DUAL-Hot-Swappable 12C Isolato Min Qty: 1 Package Multiple: 98 988
  • 1 $6.8500
  • 10 $6.1890
  • 1,000 $2.7100
$2.7100 / $6.8500 Buy Now
Bristol Electronics   4
RFQ
DISTI # ADUM1250ARZ
TME IC: interface, digital isolator, 1Mbps, iCoupler®, 3÷5.5VDC, I2C Min Qty: 1 2766
  • 1 $2.1500
  • 3 $2.0000
  • 10 $1.8000
  • 25 $1.7000
  • 98 $1.6000
  • 294 $1.5000
  • 588 $1.3500
$1.3500 / $2.1500 Buy Now
Ameya Holding Limited IC: interface, digital isolator, 1Mbps, iCoupler®, 3÷5.5VDC, I2C 1789
RFQ
NexGen Digital   54
RFQ
DISTI # ADUM1250ARZ
Richardson RFPD DIGITAL ISOLATOR RoHS: Compliant Min Qty: 1 42
  • 1 $4.2700
  • 10 $4.1500
  • 25 $3.9800
  • 98 $3.9800
$3.9800 / $4.2700 Buy Now
Chip 1 Exchange INSTOCK 1300
RFQ
DISTI # C1S103100541120
Chip1Stop Digital Isolator CMOS 4-CH 1Mbps 8-Pin SOIC N Tube RoHS: Compliant pbFree: Yes Container: Tube 96
  • 1 $6.0700
  • 10 $5.2500
  • 50 $4.7400
$4.7400 / $6.0700 Buy Now
DISTI # C1S103100267404
Chip1Stop Digital Isolator CMOS 4-CH 1Mbps 8-Pin SOIC N Tube RoHS: Compliant pbFree: Yes Container: Tube 13
  • 1 $5.8400
  • 10 $4.4500
$4.4500 / $5.8400 Buy Now
CHIPMALL.COM LIMITED Magnetic isolation 2 I2C SOIC-8 Digital Isolators ROHS 383
  • 1 $1.5366
  • 10 $1.3306
  • 30 $1.2032
  • 98 $0.9795
  • 490 $0.9202
  • 980 $0.8950
$0.8950 / $1.5366 Buy Now
DISTI # ADUM1250ARZ
IBS Electronics ANALOG DEVICES - ADUM1250ARZ - Digital Isolator, Dual, 2 Channel, 150 ns, 3 V, 5.5 V, SOIC, 8 Pins Min Qty: 1 Package Multiple: 1 0
  • 1 $4.7320
$4.7320 Buy Now
LCSC SOIC-8 I2C Isolators ROHS 383
  • 1 $1.6006
  • 10 $1.3860
  • 30 $1.2533
  • 98 $1.0203
  • 490 $0.9585
  • 980 $0.9323
$0.9323 / $1.6006 Buy Now
MacroQuest Electronics ISO 9001: 2015, ISO 14001:2015, ISO 45001:2018 2228
  • 50 $1.5200
  • 250 $1.3700
  • 500 $1.2200
$1.2200 / $1.5200 Buy Now
Win Source Electronics DGTL ISO 2.5KV 2CH I2C 8SOIC 60003
  • 45 $1.2460
  • 100 $1.0230
  • 155 $0.9910
  • 210 $0.9590
  • 270 $0.9270
  • 365 $0.8310
$0.8310 / $1.2460 Buy Now

CAD Models for ADUM1250ARZ by Analog Devices Inc
You need to Sign In or Sign Up to download CAD models.

Part Data Attributes for ADUM1250ARZ by Analog Devices Inc

ADUM1250ARZ
Analog Devices Inc
-
-
Pbfree Code
No
Rohs Code
Yes
Part Life Cycle Code
Active
Ihs Manufacturer
ANALOG DEVICES INC
Part Package Code
SOIC
Package Description
ROHS COMPLIANT, MS-012AA, SOIC-8
Pin Count
8
Manufacturer Package Code
R-8
Reach Compliance Code
compliant
ECCN Code
EAR99
HTS Code
8542.39.00.01
Samacsys Manufacturer
Analog Devices
Interface IC Type
DIGITAL ISOLATOR
JESD-30 Code
R-PDSO-G8
JESD-609 Code
e3
Length
4.9 mm
Moisture Sensitivity Level
1
Number of Functions
1
Number of Terminals
8
Operating Temperature-Max
105 °C
Operating Temperature-Min
-40 °C
Package Body Material
PLASTIC/EPOXY
Package Code
SOP
Package Equivalence Code
SOP8,.25
Package Shape
RECTANGULAR
Package Style
SMALL OUTLINE
Peak Reflow Temperature (Cel)
260
Qualification Status
Not Qualified
Seated Height-Max
1.75 mm
Supply Voltage-Max
5.5 V
Supply Voltage-Min
3 V
Supply Voltage-Nom
3.3 V
Surface Mount
YES
Technology
CMOS
Temperature Grade
INDUSTRIAL
Terminal Finish
Matte Tin (Sn) - annealed
Terminal Form
GULL WING
Terminal Pitch
1.27 mm
Terminal Position
DUAL
Time@Peak Reflow Temperature-Max (s)
30
Width
3.9 mm
