BAS40LP-7 by: Diodes Incorporated

Rectifier Diode, Schottky, 1 Element, 0.2A, 40V V(RRM), Silicon, GREEN, LEADLESS, ULTRA SMALL, PLASTIC, CASE DFN1006-2, 2 PIN

Part Details for BAS40LP-7 by Diodes Incorporated

Results Overview of BAS40LP-7 by Diodes Incorporated

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

BAS40LP-7 Information

BAS40LP-7 by Diodes Incorporated is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.

A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.

Price & Stock for BAS40LP-7

Part # Distributor Description Stock Price Buy
DISTI # 23T4523
Newark Diode, Schottky, 0.25W, 40V, 2-Dfn, Diode Configuration:Single, Repetitive Peak Reverse Voltage:40V, Average Forward Current:200Ma, Forward Voltage Max:1V, Forward Surge Current:600Ma, Operating Temperature Max:125°C, Product Range:-Rohs Compliant: Yes |Diodes Inc. BAS40LP-7 RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 0 Container: Cut Tape 10852
  • 1 $0.4140
  • 10 $0.2870
  • 25 $0.2700
  • 50 $0.2550
  • 100 $0.2380
  • 250 $0.2150
  • 500 $0.1910
  • 1,000 $0.1740
$0.1740 / $0.4140 Buy Now
DISTI # 81AC7518
Newark Schottky Diode X1-Dfn1006-2 T&r 3K Rohs Compliant: Yes |Diodes Inc. BAS40LP-7 RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel 0
Buy Now
DISTI # BAS40LP-7
Avnet Americas Diode Schottky 40V 0.2A 2-Pin DFN T/R - Tape and Reel (Alt: BAS40LP-7) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 16 Weeks, 0 Days Container: Reel 0
  • 3,000 $0.0769
  • 6,000 $0.0750
  • 12,000 $0.0732
  • 18,000 $0.0714
  • 24,000 $0.0706
$0.0706 / $0.0769 Buy Now
DISTI # 70437600
RS Diode Schottky 40V 0.2A 2Pin DFN | Diodes Inc BAS40LP-7 RoHS: Not Compliant Min Qty: 50 Package Multiple: 1 Container: Bulk 0
  • 50 $0.2770
  • 500 $0.2630
  • 2,500 $0.2490
  • 5,000 $0.2350
$0.2350 / $0.2770 RFQ
Bristol Electronics   Min Qty: 17 2980
  • 17 $0.3000
  • 51 $0.1500
  • 335 $0.0900
  • 1,668 $0.0600
$0.0600 / $0.3000 Buy Now
Bristol Electronics   1958
RFQ
Bristol Electronics   Min Qty: 17 1724
  • 17 $0.3000
  • 51 $0.1500
  • 335 $0.0900
  • 1,668 $0.0600
$0.0600 / $0.3000 Buy Now
DISTI # BAS40LP-7
TME Diode: Schottky rectifying, X1-DFN1006-2, SMD, 40V, 0.8A Min Qty: 1 100
  • 1 $0.3220
  • 10 $0.2150
  • 50 $0.1850
  • 100 $0.1460
  • 500 $0.1130
  • 600 $0.1110
  • 1,000 $0.1020
  • 9,000 $0.0890
$0.0890 / $0.3220 Buy Now
DISTI # BAS40LP-7
Avnet Asia Diode Schottky 40V 0.2A 2-Pin DFN T/R (Alt: BAS40LP-7) RoHS: Compliant Min Qty: 6000 Package Multiple: 3000 Lead time: 8 Weeks, 0 Days 0
  • 6,000 $0.0286
  • 12,000 $0.0267
  • 18,000 $0.0260
  • 30,000 $0.0253
  • 60,000 $0.0247
  • 150,000 $0.0241
  • 300,000 $0.0235
$0.0235 / $0.0286 Buy Now
DISTI # BAS40LP-7
Avnet Silica Diode Schottky 40V 02A 2Pin DFN TR (Alt: BAS40LP-7) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 10 Weeks, 0 Days Silica - 0
Buy Now
LCSC 40V 1V40mA 200mA DFN-2(0.6x1) Schottky Diodes ROHS 34580
  • 20 $0.0292
  • 200 $0.0230
  • 600 $0.0196
  • 3,000 $0.0163
  • 9,000 $0.0145
  • 21,000 $0.0135
$0.0135 / $0.0292 Buy Now
MacroQuest Electronics STOCK 120000
RFQ
New Advantage Corporation BAS40 Series 40 V 200 nA Surface Mount Schottky Barrier Diode - DFN-2 RoHS: Compliant Min Qty: 1 Package Multiple: 3000 84000
  • 3,000 $0.0881
  • 84,000 $0.0823
$0.0823 / $0.0881 Buy Now
Vyrian Diodes 82510
RFQ
Win Source Electronics DIODE SCHOTTKY 40V 200MA 2DFN 489000
  • 2,130 $0.0235
  • 5,185 $0.0193
  • 8,025 $0.0187
  • 11,050 $0.0181
  • 14,290 $0.0175
  • 19,110 $0.0157
$0.0157 / $0.0235 Buy Now

Part Details for BAS40LP-7

BAS40LP-7 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

BAS40LP-7 Part Data Attributes

Parametric Data
BAS40LP-7 Diodes Incorporated
Buy Now Datasheet
Compare Parts:
BAS40LP-7 Diodes Incorporated Rectifier Diode, Schottky, 1 Element, 0.2A, 40V V(RRM), Silicon, GREEN, LEADLESS, ULTRA SMALL, PLASTIC, CASE DFN1006-2, 2 PIN
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer DIODES INC
Part Package Code DFN
Package Description DFN1006-2, 2 PIN
Pin Count 2
Manufacturer Package Code CASE DFN1006-2
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8541.10.00.70
Factory Lead Time 16 Weeks
Samacsys Manufacturer Diodes Incorporated
Additional Feature HIGH RELIABILITY
Application GENERAL PURPOSE
Configuration SINGLE
Diode Element Material SILICON
Diode Type RECTIFIER DIODE
Forward Voltage-Max (VF) 0.38 V
JESD-30 Code R-PBCC-N2
JESD-609 Code e4
Moisture Sensitivity Level 1
Non-rep Pk Forward Current-Max 0.6 A
Number of Elements 1
Number of Phases 1
Number of Terminals 2
Operating Temperature-Max 125 °C
Operating Temperature-Min -55 °C
Output Current-Max 0.2 A
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style CHIP CARRIER
Peak Reflow Temperature (Cel) 260
Power Dissipation-Max 0.25 W
Qualification Status Not Qualified
Rep Pk Reverse Voltage-Max 40 V
Reverse Recovery Time-Max 0.005 µs
Surface Mount YES
Technology SCHOTTKY
Terminal Finish NICKEL PALLADIUM GOLD
Terminal Form NO LEAD
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) 30

Alternate Parts for BAS40LP-7

This table gives cross-reference parts and alternative options found for BAS40LP-7. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of BAS40LP-7, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
BAS40LP-7B Diodes Incorporated Check for Price Rectifier Diode, Schottky, 1 Element, 0.2A, 40V V(RRM), Silicon, X1-DFN1006-2, 2 PIN BAS40LP-7 vs BAS40LP-7B
BAS40-7-F Diodes Incorporated $0.0669 Rectifier Diode, Schottky, 1 Element, 0.2A, 40V V(RRM), Silicon, GREEN, PLASTIC PACKAGE-3 BAS40LP-7 vs BAS40-7-F
