FUSB302MPX by:
onsemi

Programmable USB Type-C Controller with PD, 3000-REEL

Part Details for FUSB302MPX by onsemi

Results Overview of FUSB302MPX by onsemi

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Computing and Data Storage

FUSB302MPX Information

FUSB302MPX by onsemi is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Price & Stock for FUSB302MPX

Part # Distributor Description Stock Price Buy
DISTI # FUSB302MPX
Avnet Americas USB Type-C Port Controller 14-Pin MLP T/R - Tape and Reel (Alt: FUSB302MPX) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 18 Weeks, 0 Days Container: Reel 0
  • 3,000 $0.3085
  • 6,000 $0.3023
  • 12,000 $0.3007
  • 18,000 $0.2992
  • 24,000 $0.2976
$0.2976 / $0.3085 Buy Now
Rochester Electronics Power Supply Support Circuit, Adjustable, 2 Channel RoHS: Compliant Status: Not Recommended for New Designs Min Qty: 1 5556
  • 100 $0.6435
  • 500 $0.5791
  • 1,000 $0.5341
  • 10,000 $0.4762
  • 100,000 $0.3990
$0.3990 / $0.6435 Buy Now
DISTI # FUSB302MPX
Avnet Asia USB Type-C Port Controller 14-Pin MLP T/R (Alt: FUSB302MPX) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 18 Weeks, 0 Days 0
  • 3,000 $0.3004
  • 6,000 $0.2965
  • 9,000 $0.2927
  • 15,000 $0.2890
  • 30,000 $0.2818
  • 75,000 $0.2751
  • 150,000 $0.2686
$0.2686 / $0.3004 Buy Now
DISTI # FUSB302MPX
Avnet Silica USB TypeC Port Controller 14Pin MLP TR (Alt: FUSB302MPX) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 19 Weeks, 0 Days Silica - 0
Buy Now
DISTI # FUSB302MPX
EBV Elektronik USB TypeC Port Controller 14Pin MLP TR (Alt: FUSB302MPX) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 20 Weeks, 0 Days EBV - 0
Buy Now
LCSC Controller WFQFN-14(2.5x2.5) USB Converters ROHS 1343
  • 1 $1.0823
  • 10 $0.8976
  • 30 $0.7953
  • 100 $0.6808
  • 500 $0.5694
  • 1,000 $0.5465
$0.5465 / $1.0823 Buy Now
Vyrian Other Function Semiconductors 82371
RFQ
Win Source Electronics IC USB TYPE C CTLR PROGR 14MLP 81480
  • 90 $0.6537
  • 220 $0.5359
  • 335 $0.5198
  • 460 $0.5024
  • 595 $0.4863
  • 800 $0.4354
$0.4354 / $0.6537 Buy Now

Part Details for FUSB302MPX

FUSB302MPX CAD Models

FUSB302MPX Part Data Attributes

FUSB302MPX onsemi
Buy Now Datasheet
Compare Parts:
FUSB302MPX onsemi Programmable USB Type-C Controller with PD, 3000-REEL
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Not Recommended
Ihs Manufacturer ONSEMI
Package Description MLP-14
Manufacturer Package Code 510BR
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Factory Lead Time 18 Weeks
Samacsys Manufacturer onsemi
Adjustable Threshold YES
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
JESD-30 Code R-XQCC-N14
JESD-609 Code e4
Moisture Sensitivity Level 1
Number of Channels 2
Number of Functions 1
Number of Terminals 14
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
Package Body Material UNSPECIFIED
Package Code HQCCN
Package Shape RECTANGULAR
Package Style CHIP CARRIER, HEAT SINK/SLUG
Peak Reflow Temperature (Cel) 260
Supply Voltage-Max (Vsup) 5.5 V
Supply Voltage-Min (Vsup) 3 V
Supply Voltage-Nom (Vsup) 3.3 V
Surface Mount YES
Temperature Grade INDUSTRIAL
Terminal Finish NICKEL PALLADIUM GOLD
Terminal Form NO LEAD
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) 30

Alternate Parts for FUSB302MPX

This table gives cross-reference parts and alternative options found for FUSB302MPX. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of FUSB302MPX, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
FUSB302MPX Fairchild Semiconductor Corporation Check for Price Power Supply Support Circuit, Adjustable, 2 Channel, MLP-14 FUSB302MPX vs FUSB302MPX

FUSB302MPX Related Parts

FUSB302MPX Frequently Asked Questions (FAQ)
