ISL88002IE17Z-TK by Renesas Electronics Corporation is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Price & Stock for ISL88002IE17Z-TK

Part # Distributor Description Stock Price Buy
DISTI # ISL88002IE17Z-TK
Avnet Americas Volt Supervisor Monitor 1.8V to 2.75V 3-Pin SC-70 T/R - Tape and Reel (Alt: ISL88002IE17Z-TK) RoHS: Compliant Min Qty: 2000 Package Multiple: 1000 Lead time: 24 Weeks, 0 Days Container: Reel 0
  • 1 $1.4400
$1.4400 Buy Now
DISTI # ISL88002IE17Z-TK
Avnet Silica Volt Supervisor Monitor 18V to 275V 3Pin SC70 TR (Alt: ISL88002IE17Z-TK) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 26 Weeks, 0 Days Silica - 0
Buy Now

Part Details for ISL88002IE17Z-TK

ISL88002IE17Z-TK CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

ISL88002IE17Z-TK Part Data Attributes

Parametric Data
ISL88002IE17Z-TK Renesas Electronics Corporation
Buy Now Datasheet
Compare Parts:
ISL88002IE17Z-TK Renesas Electronics Corporation Ultra Low Power 3 Ld Voltage Supervisors in SC-70 and SOT-23 Packages, SC70, /Reel
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer RENESAS ELECTRONICS CORP
Part Package Code SC70
Package Description SC-70, 3 PIN
Pin Count 3
Manufacturer Package Code P3.049
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Factory Lead Time 24 Weeks
Samacsys Manufacturer Renesas Electronics
Additional Feature THRESHOLD VOLTAGE IS 1.670V
Adjustable Threshold NO
Analog IC - Other Type VOLTAGE SUPERVISOR
JESD-30 Code R-PDSO-G3
Length 2 mm
Moisture Sensitivity Level 3
Number of Channels 1
Number of Functions 1
Number of Terminals 3
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
Package Body Material PLASTIC/EPOXY
Package Code TSSOP
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Cel) 260
Seated Height-Max 1.1 mm
Supply Voltage-Max (Vsup) 2.75 V
Supply Voltage-Min (Vsup) 1.8 V
Supply Voltage-Nom (Vsup) 2.5 V
Surface Mount YES
Temperature Grade INDUSTRIAL
Terminal Finish Pure Matte Tin (Sn) - annealed
Terminal Form GULL WING
Terminal Pitch 0.65 mm
Terminal Position DUAL
Threshold Voltage-Nom +1.670V
Time@Peak Reflow Temperature-Max (s) 30
Width 1.25 mm
