Part Details for LM2574MX-5.0/NOPB by Texas Instruments

Overview of LM2574MX-5.0/NOPB by Texas Instruments

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Education and Research Internet of Things (IoT) Computing and Data Storage Aerospace and Defense Healthcare Telecommunications Automotive

Price & Stock for LM2574MX-5.0/NOPB

Part # Distributor Description Stock Price Buy
DISTI # 33AH4075
Newark Dc/Dc Conv, Buck, 5V, 52Khz, Soic-14, Topology:Buck (Step Down), Input Voltage Min:4V, Input Voltage Max:40V, Dc/Dc Converter Ic Case:Soic, No. Of Pins:14Pins, Output Current:500Ma, Output Voltage Nom.:5V, Switching Rohs Compliant: Yes |TEXAS INSTRUMENTS LM2574MX-5.0/NOPB Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 0
  • 1 $3.5800
  • 10 $3.4300
  • 25 $3.2500
  • 50 $3.1100
  • 100 $2.9800
  • 250 $2.8800
  • 500 $2.8100
$2.8100 / $3.5800 Buy Now
DISTI # LM2574MX-5.0/NOPBTR-ND
DigiKey IC REG BUCK 5V 500MA 14SOIC Min Qty: 1000 Container: Reel 2000
Tape & Reel
  • 1,000 $1.4239
  • 2,000 $1.3527
  • 5,000 $1.3018
$1.3018 / $1.4239 Buy Now
DISTI # LM2574MX-5.0/NOPBCT-ND
DigiKey IC REG BUCK 5V 500MA 14SOIC Min Qty: 1 Container: Cut Tape 945
Cut Tape
  • 1 $2.7000
  • 10 $2.4210
  • 25 $2.2884
  • 100 $1.9833
  • 250 $1.8816
  • 500 $1.6883
$1.6883 / $2.7000 Buy Now
DISTI # LM2574MX-5.0/NOPBDKR-ND
DigiKey IC REG BUCK 5V 500MA 14SOIC Min Qty: 1 Container: Digi-Reel 0
Digi-Reel®
  • 1 $2.7000
  • 10 $2.4210
  • 25 $2.2884
  • 100 $1.9833
  • 250 $1.8816
  • 500 $1.6883
$1.6883 / $2.7000 Buy Now
Chip 1 Exchange INSTOCK 2678
RFQ
Win Source Electronics IC REG BUCK 5V 0.5A 14-SOIC 16011
  • 35 $1.6250
  • 75 $1.3340
  • 120 $1.2920
  • 160 $1.2500
  • 210 $1.2090
  • 280 $1.0840
$1.0840 / $1.6250 Buy Now

Part Details for LM2574MX-5.0/NOPB

LM2574MX-5.0/NOPB CAD Models

LM2574MX-5.0/NOPB Part Data Attributes

LM2574MX-5.0/NOPB Texas Instruments
Buy Now Datasheet
Compare Parts:
LM2574MX-5.0/NOPB Texas Instruments 8V to 40V, 500mA SIMPLE SWITCHER® buck converter with 4 external components 14-SOIC -40 to 125
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer TEXAS INSTRUMENTS INC
Part Package Code SOIC
Package Description 0.300 INCH, GREEN, PLASTIC, SOP-14
Pin Count 14
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Samacsys Manufacturer Texas Instruments
Analog IC - Other Type SWITCHING REGULATOR
Control Mode VOLTAGE-MODE
Control Technique PULSE WIDTH MODULATION
Input Voltage-Max 40 V
Input Voltage-Min 4 V
Input Voltage-Nom 12 V
JESD-30 Code R-PDSO-G14
JESD-609 Code e3
Length 9 mm
Moisture Sensitivity Level 3
Number of Functions 1
Number of Outputs 1
Number of Terminals 14
Operating Temperature-Max 125 °C
Operating Temperature-Min -40 °C
Output Current-Max 0.5 A
Output Voltage-Max 37 V
Output Voltage-Min 3.3 V
Output Voltage-Nom 5 V
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Seated Height-Max 2.65 mm
Surface Mount YES
Switcher Configuration BUCK
Switching Frequency-Max 52 kHz
Temperature Grade AUTOMOTIVE
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Width 7.5 mm
