LM324DRG3
Texas Instruments
Description: Quad 30-V 1.2-MHz operational amplifier 14-SOIC 0 to 70

Overview of LM324DRG3 by Texas Instruments

Note: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Price & Stock for LM324DRG3 by Texas Instruments

Part # Manufacturer Description Stock Price Buy
DISTI # 296-LM324DRG3TR-ND
DigiKey IC OPAMP GP 4 CIRCUIT 14SOIC Min Qty: 2500 Container: Reel 7500
Tape & Reel
  • 2,500 $0.1467
  • 5,000 $0.1378
  • 12,500 $0.1289
  • 25,000 $0.1182
  • 62,500 $0.1138
$0.1138 / $0.1467 Buy Now
DISTI # 296-LM324DRG3CT-ND
DigiKey IC OPAMP GP 4 CIRCUIT 14SOIC Min Qty: 1 Container: Cut Tape 2226
Cut Tape
  • 1 $0.5200
  • 10 $0.4180
  • 25 $0.3820
  • 100 $0.2844
  • 250 $0.2578
  • 500 $0.2133
  • 1,000 $0.1600
$0.1600 / $0.5200 Buy Now
DISTI # 296-LM324DRG3DKR-ND
DigiKey IC OPAMP GP 4 CIRCUIT 14SOIC Min Qty: 1 Container: Digi-Reel 0
Digi-Reel®
  • 1 $0.5200
  • 10 $0.4180
  • 25 $0.3820
  • 100 $0.2844
  • 250 $0.2578
  • 500 $0.2133
  • 1,000 $0.1600
$0.1600 / $0.5200 Buy Now
DISTI # C1S746202001260
Chip1Stop OP Amp Quad GP ±16V/32V 14-Pin SOIC T/R RoHS: Compliant pbFree: Yes Container: Cut Tape 2430
  • 5 $0.1360
  • 50 $0.0932
  • 100 $0.0867
  • 200 $0.0865
  • 500 $0.0838
  • 1,000 $0.0821
  • 2,000 $0.0818
$0.0818 / $0.1360 Buy Now
Win Source Electronics IC OPAMP GP 1.2MHZ 14SOIC 400020
  • 545 $0.0920
  • 1,320 $0.0760
  • 2,030 $0.0740
  • 2,820 $0.0710
  • 3,625 $0.0690
  • 4,840 $0.0620
$0.0620 / $0.0920 Buy Now

CAD Models for LM324DRG3 by Texas Instruments
You need to Sign In or Sign Up to download CAD models.

Part Data Attributes for LM324DRG3 by Texas Instruments

LM324DRG3
Texas Instruments
-
-
Pbfree Code
Yes
Rohs Code
Yes
Part Life Cycle Code
Obsolete
Ihs Manufacturer
TEXAS INSTRUMENTS INC
Part Package Code
SOIC
Package Description
GREEN, PLASTIC, MS-012AB, SOIC-14
Pin Count
14
Reach Compliance Code
compliant
ECCN Code
EAR99
HTS Code
8542.33.00.01
Date Of Intro
1989-03-01
Samacsys Manufacturer
Texas Instruments
Amplifier Type
OPERATIONAL AMPLIFIER
Architecture
VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB)
0.5 µA
Bias Current-Max (IIB) @25C
0.25 µA
Common-mode Reject Ratio-Min
65 dB
Common-mode Reject Ratio-Nom
80 dB
Frequency Compensation
YES
Input Offset Current-Max (IIO)
0.15 µA
Input Offset Voltage-Max
7000 µV
JESD-30 Code
R-PDSO-G14
JESD-609 Code
e3
Length
8.65 mm
Low-Bias
YES
Low-Offset
NO
Micropower
YES
Moisture Sensitivity Level
1
Number of Functions
4
Number of Terminals
14
Operating Temperature-Max
70 °C
Operating Temperature-Min
Package Body Material
PLASTIC/EPOXY
Package Code
SOP
Package Equivalence Code
TSSOP14,.25
Package Shape
RECTANGULAR
Package Style
SMALL OUT LINE
Packing Method
TR
Peak Reflow Temperature (Cel)
260
Power
NO
Programmable Power
NO
Qualification Status
Not Qualified
Seated Height-Max
1.75 mm
Slew Rate-Nom
0.5 V/us
Supply Current-Max
3 mA
Supply Voltage Limit-Max
32 V
Supply Voltage-Nom (Vsup)
5 V
Surface Mount
YES
Technology
BIPOLAR
Temperature Grade
COMMERCIAL
Terminal Finish
Matte Tin (Sn)
Terminal Form
GULL WING
Terminal Pitch
1.27 mm
Terminal Position
DUAL
Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED
Unity Gain BW-Nom
1200
Voltage Gain-Min
25000
Wideband
NO
Width
3.9 mm
Want to compare parts?
  1. LM324DRG3
    Texas Instruments
    Quad 30-V 1.2-MHz operational amplifier 14-SOIC 0 to 70
