LTM4638IY#PBF Information
LTM4638IY#PBF by Analog Devices Inc is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LTM4638IY#PBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
50AK4339
|
Newark | Dc-Dc Converter, 0.6V-5.5V, 15A, Power Supply Applications:Ite, Industrial & Medical, Dc/Dc Converter Type:Bga-49, Micro Module, Output Power Max:-, Output Voltage Min:600Mv, Output Voltage Max:5.5V, Output Current Max:15A Rohs Compliant: Yes |Analog Devices LTM4638IY#PBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 266 |
|
$27.4800 / $29.3900 | Buy Now |
|
|
Analog Devices Inc | 20V, 15A Step-Down DC/DC ?M Re Package Multiple: 260 | 60 |
|
$17.8700 / $30.5200 | Buy Now |
|
|
Vyrian | Other Function Semiconductors | 321 |
|
RFQ | |
|
|
Win Source Electronics | DC DC CONVERTER 0.6-5.5V | 780 |
|
$145.9792 / $168.4376 | Buy Now |
Part Details for LTM4638IY#PBF
LTM4638IY#PBF CAD Models
LTM4638IY#PBF Part Data Attributes
|
|
LTM4638IY#PBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LTM4638IY#PBF
Analog Devices Inc
20VIN, 15A Step-Down DC/DC µModule Regulator
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Pin Count | 49 | |
| Manufacturer Package Code | 05-08-1574 | |
| Reach Compliance Code | compliant | |
| Date Of Intro | 2018-12-10 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog IC - Other Type | SWITCHING REGULATOR | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 20 V | |
| Input Voltage-Min | 3.1 V | |
| Input Voltage-Nom | 12 V | |
| JESD-30 Code | S-PBGA-B49 | |
| JESD-609 Code | e1 | |
| Length | 6.25 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 49 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Voltage-Max | 5.5 V | |
| Output Voltage-Min | 0.6 V | |
| Output Voltage-Nom | 1.5 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | FBGA | |
| Package Equivalence Code | BGA49,7X7,32 | |
| Package Shape | SQUARE | |
| Package Style | GRID ARRAY, FINE PITCH | |
| Peak Reflow Temperature (Cel) | 245 | |
| Seated Height-Max | 5.36 mm | |
| Supply Voltage-Nom (Vsup) | 12 V | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK | |
| Switching Frequency-Max | 600 kHz | |
| Technology | HYBRID | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Tin/Silver/Copper (Sn/Ag/Cu) | |
| Terminal Form | BALL | |
| Terminal Pitch | 0.8 mm | |
| Terminal Position | BOTTOM | |
| Width | 6.25 mm |
