Microcontrollers and Processors / Multifunction Peripherals / MCIMX27VOP4A
Datasheets
MCIMX27VOP4A by:

32-BIT, 400MHz, MICROPROCESSOR, PBGA404

Part Details for MCIMX27VOP4A by NXP Semiconductors

Results Overview of MCIMX27VOP4A by NXP Semiconductors

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

MCIMX27VOP4A Information

MCIMX27VOP4A by NXP Semiconductors is a Multifunction Peripheral.
Multifunction Peripherals are under the broader part category of Microcontrollers and Processors.

Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.

Price & Stock for MCIMX27VOP4A

Part # Distributor Description Stock Price Buy
DISTI # 69M3759
Newark I.mx27 Rev 2.1/ Tray Rohs Compliant: Yes |Nxp MCIMX27VOP4A RoHS: Compliant Min Qty: 450 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 250 $24.6000
$24.6000 Buy Now
DISTI # MCIMX27VOP4A
Avnet Americas Multimedia Processor 404-Pin MAPBGA - Trays (Alt: MCIMX27VOP4A) RoHS: Compliant Min Qty: 450 Package Multiple: 450 Lead time: 13 Weeks, 0 Days Container: Tray 0
  • 450 $22.4218
  • 900 $22.2398
  • 1,800 $22.0527
  • 2,700 $21.8792
  • 3,600 $21.5353
$21.5353 / $22.4218 Buy Now
DISTI # MCIMX27VOP4A
Avnet Silica Multimedia Processor 404-Pin MAPBGA (Alt: MCIMX27VOP4A) RoHS: Compliant Min Qty: 90 Package Multiple: 90 Lead time: 15 Weeks, 0 Days Silica - 0
Buy Now
DISTI # MCIMX27VOP4A
EBV Elektronik Multimedia Processor 404-Pin MAPBGA (Alt: MCIMX27VOP4A) RoHS: Compliant Min Qty: 90 Package Multiple: 90 Lead time: 15 Weeks, 0 Days EBV - 630
Buy Now

Part Details for MCIMX27VOP4A

MCIMX27VOP4A CAD Models

There are no models available for this part yet.

Sign in to request this CAD model.

Register or Sign In

MCIMX27VOP4A Part Data Attributes

Parametric Data
MCIMX27VOP4A NXP Semiconductors
Buy Now Datasheet
Compare Parts:
MCIMX27VOP4A NXP Semiconductors 32-BIT, 400MHz, MICROPROCESSOR, PBGA404
Rohs Code Yes
Part Life Cycle Code Not Recommended
Ihs Manufacturer NXP SEMICONDUCTORS
Package Description MAPBGA-404
Reach Compliance Code compliant
ECCN Code 5A992.C
HTS Code 8542.31.00.01
Factory Lead Time 13 Weeks
Samacsys Manufacturer NXP
Additional Feature ALSO OPERATES WITH 1.3VNOM @266MHZ
JESD-30 Code S-PBGA-B404
JESD-609 Code e1
Length 17 mm
Moisture Sensitivity Level 3
Number of Terminals 404
Operating Temperature-Max 85 °C
Operating Temperature-Min -20 °C
Package Body Material PLASTIC/EPOXY
Package Code LFBGA
Package Shape SQUARE
Package Style GRID ARRAY, LOW PROFILE, FINE PITCH
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Seated Height-Max 1.4 mm
Supply Voltage-Max 1.52 V
Supply Voltage-Min 1.38 V
Supply Voltage-Nom 1.45 V
Surface Mount YES
Technology CMOS
Temperature Grade OTHER
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Terminal Form BALL
Terminal Pitch 0.65 mm
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) 40
Width 17 mm
uPs/uCs/Peripheral ICs Type SoC

Alternate Parts for MCIMX27VOP4A

This table gives cross-reference parts and alternative options found for MCIMX27VOP4A. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of MCIMX27VOP4A, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
MCIMX27LVOP4AR2 NXP Semiconductors $18.2000 MICROPROCESSOR MCIMX27VOP4A vs MCIMX27LVOP4AR2
MCIMX27VOP4A Freescale Semiconductor Check for Price I.MX27 REV 2.1 MCIMX27VOP4A vs MCIMX27VOP4A
MCIMX27VJP4A NXP Semiconductors Check for Price 32-BIT, 400MHz, MICROPROCESSOR, PBGA404 MCIMX27VOP4A vs MCIMX27VJP4A
MCIMX27LVOP4A NXP Semiconductors $12.9394 32-BIT, 400MHz, MICROPROCESSOR, PBGA404 MCIMX27VOP4A vs MCIMX27LVOP4A
MCIMX27VOP4AR2 NXP Semiconductors Check for Price MICROPROCESSOR MCIMX27VOP4A vs MCIMX27VOP4AR2
MCIMX27VJP4A Freescale Semiconductor Check for Price I.MX27 REV 2.1 MCIMX27VOP4A vs MCIMX27VJP4A

MCIMX27VOP4A Related Parts

MCIMX27VOP4A Frequently Asked Questions (FAQ)

  • The maximum operating temperature range for the MCIMX27VOP4A is -40°C to 105°C.

  • The clock settings for the MCIMX27VOP4A can be configured using the Clock Controller (CCM) module. The CCM module allows you to configure the clock sources, dividers, and multiplexers to generate the desired clock frequencies for the processor, peripherals, and external interfaces.

  • The maximum frequency for the ARM Cortex-A7 core in the MCIMX27VOP4A is 1.0 GHz.

  • The DDR memory interface on the MCIMX27VOP4A is a 32-bit interface that supports DDR3, DDR3L, and LPDDR3 memories. To use the DDR memory interface, you need to configure the DDR controller, set the memory timings, and initialize the memory using the DDR initialization sequence.

  • The System Reset Controller (SRC) in the MCIMX27VOP4A is responsible for generating resets to the processor, peripherals, and external interfaces. The SRC can be configured to generate resets based on various events, such as power-on, watchdog timer expiration, or software-initiated resets.
