Transistors / Small Signal Bipolar Transistors / MMBT4401
Datasheets
MMBT4401 by:

Small Signal Bipolar Transistor, 0.6A I(C), NPN,

Part Details for MMBT4401 by Diotec Semiconductor AG

Results Overview of MMBT4401 by Diotec Semiconductor AG

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Audio and Video Systems

MMBT4401 Information

MMBT4401 by Diotec Semiconductor AG is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for MMBT4401

Part # Distributor Description Stock Price Buy
DISTI # 4574498
Farnell TRANSISTOR, NPN, 40V, 0.6A, SOT-23 RoHS: Compliant Min Qty: 5 Lead time: 7 Weeks, 1 Days Container: Cut Tape 8875
  • 5 $0.1331
  • 10 $0.0748
  • 100 $0.0482
  • 500 $0.0349
  • 1,000 $0.0276
  • 5,000 $0.0205
$0.0205 / $0.1331 Buy Now
DISTI # 4574498RL
Farnell TRANSISTOR, NPN, 40V, 0.6A, SOT-23 RoHS: Compliant Min Qty: 500 Lead time: 7 Weeks, 1 Days Container: Reel 8875
  • 500 $0.0349
  • 1,000 $0.0276
  • 5,000 $0.0205
$0.0205 / $0.0349 Buy Now
Bristol Electronics   3000
RFQ
DISTI # MMBT4401-DIO
TME Transistor: NPN, bipolar, 40V, 0.6A, 300mW, SOT23 Min Qty: 25 2875
  • 25 $0.0332
  • 100 $0.0174
  • 500 $0.0156
  • 3,000 $0.0139
  • 12,000 $0.0125
$0.0125 / $0.0332 Buy Now
LCSC 40V 300mW 100150mA1V 600mA NPN SOT-23-3(TO-236-3) Bipolar (BJT) ROHS 2500
  • 20 $0.0363
  • 200 $0.0283
  • 600 $0.0239
  • 3,000 $0.0204
  • 9,000 $0.0181
  • 21,000 $0.0169
$0.0169 / $0.0363 Buy Now

Part Details for MMBT4401

MMBT4401 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

MMBT4401 Part Data Attributes

Parametric Data
MMBT4401 Diotec Semiconductor AG
Buy Now Datasheet
Compare Parts:
MMBT4401 Diotec Semiconductor AG Small Signal Bipolar Transistor, 0.6A I(C), NPN,
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer DIOTEC SEMICONDUCTOR AG
Reach Compliance Code not_compliant
ECCN Code EAR99
Samacsys Manufacturer Diotec
Collector Current-Max (IC) 0.6 A
Collector-Emitter Voltage-Max 60 V
Configuration SINGLE
DC Current Gain-Min (hFE) 100
JEDEC-95 Code TO-236
JESD-30 Code R-PDSO-G3
JESD-609 Code e3
Moisture Sensitivity Level 1
Number of Elements 1
Number of Terminals 3
Operating Temperature-Max 150 °C
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type NPN
Power Dissipation-Max (Abs) 0.225 W
Surface Mount YES
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 10
Transistor Application SWITCHING
Transistor Element Material SILICON
Transition Frequency-Nom (fT) 250 MHz

Alternate Parts for MMBT4401
