Part Details for SKY13330-397LF by Skyworks Solutions Inc
Results Overview of SKY13330-397LF by Skyworks Solutions Inc
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
SKY13330-397LF Information
SKY13330-397LF by Skyworks Solutions Inc is an RF/Microwave Switch.
RF/Microwave Switches are under the broader part category of RF and Microwave Components.
RF and Microwave Engineering focuses on the design and operation of devices that transmit or receive radio waves. The main distinction between RF and microwave engineering is their wavelength, which influences how energy is transmitted and used in various applications. Read more about RF and Microwave Components on our RF and Microwave part category page.
Price & Stock for SKY13330-397LF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Bristol Electronics | Min Qty: 5 | 1480 |
|
$0.2925 / $1.1250 | Buy Now |
|
|
Rochester Electronics | Diversity Switch, 100MHz Min, 6000MHz Max, 0.65dB Insertion Loss-Max RoHS: Compliant Status: Active Min Qty: 1 | 4765 |
|
$0.3162 / $0.5100 | Buy Now |
|
DISTI #
SKY13330-397LF
|
Richardson RFPD | RF AND MICROWAVE SWITCH RoHS: Compliant Min Qty: 3000 | 0 |
|
$0.3700 / $0.3900 | Buy Now |
|
DISTI #
SKY13330-397LFB
|
Richardson RFPD | RF AND MICROWAVE SWITCH RoHS: Compliant Min Qty: 1 | 0 |
|
RFQ | |
|
|
Vyrian | RF & Microwave | 55062 |
|
RFQ | |
|
|
Win Source Electronics | IC SWITCH SP2T | 31260 |
|
$0.4538 / $0.6805 | Buy Now |
Part Details for SKY13330-397LF
SKY13330-397LF CAD Models
SKY13330-397LF Part Data Attributes
|
|
SKY13330-397LF
Skyworks Solutions Inc
Buy Now
Datasheet
|
Compare Parts:
SKY13330-397LF
Skyworks Solutions Inc
Diversity Switch, 100MHz Min, 6000MHz Max, 0.65dB Insertion Loss-Max, 2 X 2 MM, GREEN, QFN-12
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | SKYWORKS SOLUTIONS INC | |
| Package Description | 2 X 2 MM, GREEN, QFN-12 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8536.50.70.00 | |
| Samacsys Manufacturer | Skyworks | |
| Additional Feature | HIGH ISOLATION | |
| Characteristic Impedance | 50 Ω | |
| Construction | COMPONENT | |
| Input Power-Max (CW) | 40 dBm | |
| Insertion Loss-Max | 0.65 dB | |
| JESD-609 Code | e3 | |
| Operating Frequency-Max | 6000 MHz | |
| Operating Frequency-Min | 100 MHz | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -20 °C | |
| RF/Microwave Device Type | DIVERSITY SWITCH | |
| Terminal Finish | TIN | |
| VSWR-Max | 1.22 |
SKY13330-397LF Frequently Asked Questions (FAQ)
-
The recommended PCB layout and land pattern can be found in the Skyworks Solutions application note AN302A, which provides guidelines for optimal performance and minimizes parasitic effects.
-
Skyworks Solutions provides a comprehensive evaluation board and design guide for the SKY13330-397LF, which includes recommended biasing and configuration settings for various applications. Additionally, engineers can consult with Skyworks' technical support team for customized guidance.
-
The SKY13330-397LF has a maximum junction temperature of 150°C. To prevent overheating, ensure proper heat sinking, use a thermal interface material, and follow the recommended PCB layout guidelines. Skyworks Solutions also provides thermal management guidelines in their application notes.
-
Yes, the SKY13330-397LF is a sensitive device and requires proper ESD protection during handling and assembly. Follow standard ESD precautions, such as using an ESD wrist strap, mat, or workstation, and ensure that all equipment and tools are properly grounded.
-
Skyworks Solutions provides reliability and quality metrics for the SKY13330-397LF, including MTBF, FIT rates, and environmental testing data. The device meets various industry standards, such as RoHS, REACH, and AEC-Q100. Engineers can consult with Skyworks' technical support team for specific compliance information.
