Part Details for TXB0102DCUR by Texas Instruments
Results Overview of TXB0102DCUR by Texas Instruments
- Distributor Offerings: (12 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (4 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Industrial Automation
Financial Technology (Fintech)
TXB0102DCUR Information
TXB0102DCUR by Texas Instruments is an Other Interface IC.
Other Interface ICs are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for TXB0102DCUR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
33AH5423
|
Newark | Ic, Volt Level Translator, Vssop-8, Logic Device Type:Voltage Level Translator, Logic Family/Base Number:-, Logic Case Style:Vssop, No. Of Pins:8Pins, Supply Voltage Min:1.2V, Supply Voltage Max:5.5V, Logic Ic Family:-, Logic Ic Rohs Compliant: Yes |Texas Instruments TXB0102DCUR RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 1661 |
|
$0.2690 / $0.5800 | Buy Now |
|
|
Bristol Electronics | 2932 |
|
RFQ | ||
|
|
Bristol Electronics | 160 |
|
RFQ | ||
|
|
Bristol Electronics | 66 |
|
RFQ | ||
|
DISTI #
TXB0102DCUR
|
TME | IC: digital, 2bit,bidirectional,logic level voltage translator Min Qty: 1 | 220 |
|
$0.3030 / $0.5130 | Buy Now |
|
|
ComSIT USA | AVAILABLE EU | 2825 |
|
RFQ | |
|
|
Greenchips | Date Code: 2235/TH | 54000 |
|
RFQ | |
|
|
Greenchips | Date Code: 2240/TH | 6000 |
|
RFQ | |
|
|
Greenchips | Date Code: 2112/TH | 431 |
|
RFQ | |
|
|
LCSC | 1.65V5.5V 1 2 1.2V3.6V 100Mbps VSSOP-8-0.5mm Translators Level Shifters ROHS | 32335 |
|
$0.1447 / $0.2799 | Buy Now |
Part Details for TXB0102DCUR
TXB0102DCUR CAD Models
TXB0102DCUR Part Data Attributes
|
|
TXB0102DCUR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TXB0102DCUR
Texas Instruments
2-Bit Bidirectional Voltage-Level Shifter with Auto Direction Sensing and +/-15-kV ESD Protect 8-VSSOP -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SOT | |
| Package Description | GREEN, PLASTIC, SOT-70, 8 PIN | |
| Pin Count | 8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Interface IC Type | INTERFACE CIRCUIT | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 2.3 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 2 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Characteristics | 3-STATE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VSSOP | |
| Package Equivalence Code | TSSOP8,.12,20 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 0.9 mm | |
| Supply Current-Max | 0.008 mA | |
| Supply Voltage-Max | 3.6 V | |
| Supply Voltage-Min | 1.2 V | |
| Supply Voltage-Nom | 1.5 V | |
| Supply Voltage1-Max | 5.5 V | |
| Supply Voltage1-Min | 1.65 V | |
| Supply Voltage1-Nom | 1.8 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 2 mm |
