XTR115UA by:

4-20-mA current loop transmitter with 2.5-V reference and 200-µA power 8-SOIC -40 to 85

Part Details for XTR115UA by Texas Instruments

Results Overview of XTR115UA by Texas Instruments

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Security and Surveillance Environmental Monitoring Internet of Things (IoT) Space Technology Smart Cities Aerospace and Defense Healthcare Agriculture Technology Virtual Reality (VR), Augmented Reality (AR), and Vision Systems Medical Imaging Robotics and Drones

XTR115UA Information

XTR115UA by Texas Instruments is an Other Signal Circuit.
Other Signal Circuits are under the broader part category of Signal Circuits.

A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.

Price & Stock for XTR115UA

Part # Distributor Description Stock Price Buy
Win Source Electronics IC 4 TO 20MA TRANSMITTER 8-SOIC 23000
  • 55 $0.9914
  • 125 $0.8135
  • 195 $0.7881
  • 265 $0.7627
  • 340 $0.7372
  • 455 $0.6610
$0.6610 / $0.9914 Buy Now

Part Details for XTR115UA

XTR115UA CAD Models

XTR115UA Part Data Attributes

XTR115UA Texas Instruments
Buy Now Datasheet
Compare Parts:
XTR115UA Texas Instruments 4-20-mA current loop transmitter with 2.5-V reference and 200-µA power 8-SOIC -40 to 85
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Obsolete
Ihs Manufacturer TEXAS INSTRUMENTS INC
Part Package Code SOIC
Pin Count 8
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Samacsys Manufacturer Texas Instruments
Analog IC - Other Type ANALOG CIRCUIT
JESD-30 Code R-PDSO-G8
JESD-609 Code e4
Length 4.9 mm
Moisture Sensitivity Level 3
Number of Channels 1
Number of Functions 1
Number of Terminals 8
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP8,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Seated Height-Max 1.75 mm
Supply Voltage-Max (Vsup) 36 V
Supply Voltage-Min (Vsup) 7.5 V
Supply Voltage-Nom (Vsup) 24 V
Surface Mount YES
Technology BIPOLAR
Temperature Grade INDUSTRIAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Width 3.9 mm
