| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| AD8476ACPZ-WP | Analog Devices | Low Pwr, Precision,G1 Diff AMP | |
| AD8476ACPZ-RL | Analog Devices | Low Pwr, Precision,G1 Diff AMP | |
| AD8476ACPZ-R7 | Analog Devices | Low Pwr, Precision,G1 Diff AMP |
| Part # | Manufacturer | Description | Stock | Price | Buy | ||
|---|---|---|---|---|---|---|---|
|
DISTI #
AD8476ACPZ-RL-ND
|
DigiKey | IC OPAMP DIFF 1 CIRCUIT 16LFCSP Min Qty: 5000 Lead time: 10 Weeks Container: Tape & Reel (TR) | Temporarily Out of Stock |
|
$3.2250 | Buy Now | |
|
DISTI #
584-AD8476ACPZ-R
|
Mouser Electronics | Differential Amplifiers Low Pwr, Precision,G1 Diff AMP RoHS: Compliant | 0 |
|
$3.2300 | Order Now | |
| Analog Devices Inc | Low Pwr, Precision,G1 Diff AMP Min Qty: 5000 Package Multiple: 5000 | 0 |
|
$3.2250 / $8.0200 | Buy Now | ||
|
DISTI #
AD8476ACPZ-RL
|
Richardson RFPD | AMPLIFIER - SPECIAL PURPOSE RoHS: Compliant Min Qty: 5000 | 0 |
|
$3.3800 | Buy Now |
|
|
|
|---|---|
|
Pbfree Code
|
No
|
|
Rohs Code
|
Yes
|
|
Part Life Cycle Code
|
Active
|
|
Ihs Manufacturer
|
ANALOG DEVICES INC
|
|
Package Description
|
3 X 3 MM, ROHS COMPLIANT, MO-229WEEE, LFCSP-16
|
|
Pin Count
|
16
|
|
Manufacturer Package Code
|
CP-16-25
|
|
Reach Compliance Code
|
compliant
|
|
ECCN Code
|
EAR99
|
|
HTS Code
|
8542.33.00.01
|
|
Samacsys Manufacturer
|
Analog Devices
|
|
Amplifier Type
|
OPERATIONAL AMPLIFIER
|
|
Common-mode Reject Ratio-Nom
|
80 dB
|
|
Input Offset Voltage-Max
|
900 µV
|
|
JESD-30 Code
|
S-XQCC-N16
|
|
JESD-609 Code
|
e3
|
|
Length
|
3 mm
|
|
Moisture Sensitivity Level
|
3
|
|
Neg Supply Voltage Limit-Max
|
-10 V
|
|
Neg Supply Voltage-Nom (Vsup)
|
-5 V
|
|
Number of Functions
|
1
|
|
Number of Terminals
|
16
|
|
Operating Temperature-Max
|
125 °C
|
|
Operating Temperature-Min
|
-40 °C
|
|
Package Body Material
|
UNSPECIFIED
|
|
Package Code
|
HVQCCN
|
|
Package Equivalence Code
|
LCC16,.12SQ,20
|
|
Package Shape
|
SQUARE
|
|
Package Style
|
CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
|
|
Packing Method
|
TR
|
|
Peak Reflow Temperature (Cel)
|
NOT SPECIFIED
|
|
Qualification Status
|
Not Qualified
|
|
Seated Height-Max
|
0.8 mm
|
|
Slew Rate-Nom
|
10 V/us
|
|
Supply Current-Max
|
0.5 mA
|
|
Supply Voltage Limit-Max
|
10 V
|
|
Supply Voltage-Nom (Vsup)
|
5 V
|
|
Surface Mount
|
YES
|
|
Technology
|
BIPOLAR
|
|
Temperature Grade
|
AUTOMOTIVE
|
|
Terminal Finish
|
Matte Tin (Sn)
|
|
Terminal Form
|
NO LEAD
|
|
Terminal Pitch
|
0.5 mm
|
|
Terminal Position
|
QUAD
|
|
Time@Peak Reflow Temperature-Max (s)
|
NOT SPECIFIED
|
|
Width
|
3 mm
|
| Part Number | Description | Manufacturer | Compare |
|---|---|---|---|
| AD8476ACPZ-WP | Low Power, Unity Gain Fully Differential Amplifier & ADC Driver | Analog Devices Inc | AD8476ACPZ-RL vs AD8476ACPZ-WP |
| AD8476ACPZ-R7 | Low Power, Unity Gain Fully Differential Amplifier & ADC Driver | Analog Devices Inc | AD8476ACPZ-RL vs AD8476ACPZ-R7 |
