3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for BC327.25 by SPC Multicomp
Results Overview of BC327.25 by SPC Multicomp
- Distributor Offerings: (1 listing)
- Number of FFF Equivalents: (0 replacements)
- Tariff Estimator: (Not Available)
- Number of Functional Equivalents: (3 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
BC327.25 Information
BC327.25 by SPC Multicomp is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for BC327.25
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
08N6214
|
Newark | Bipolar Transistor, Pnp, -45V To-92, Transistor Polarity:Pnp, Collector Emitter Voltage Max:45V, Continuous Collector Current:800Ma, Power Dissipation:625Mw, Transistor Mounting:Through Hole, No. Of Pins:3Pins, Qualification:- Rohs Compliant: Yes |Multicomp Pro BC327.25 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 29107 |
|
$0.0570 / $0.2540 | Buy Now |
Part Details for BC327.25
BC327.25 CAD Models
BC327.25 Part Data Attributes
|
|
BC327.25
SPC Multicomp
Buy Now
Datasheet
|
Compare Parts:
BC327.25
SPC Multicomp
Small Signal Bipolar Transistor,
|
| Part Life Cycle Code | Active | |
| Reach Compliance Code | Unknown | |
| ECCN Code | EAR99 | |
| Collector Current-Max (IC) | 0.8 A | |
| Collector-Emitter Voltage-Max | 45 V | |
| Configuration | Single | |
| DC Current Gain-Min (hFE) | 160 | |
| JEDEC-95 Code | TO-92 | |
| JESD-30 Code | O-PBCY-W3 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -65 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Shape | Round | |
| Package Style | Cylindrical | |
| Polarity/Channel Type | Pnp | |
| Surface Mount | No | |
| Terminal Form | Wire | |
| Terminal Position | Bottom | |
| Transistor Application | Amplifier | |
| Transistor Element Material | Silicon | |
| Transition Frequency-Nom (fT) | 100 Mhz |
Alternate Parts for BC327.25
This table gives cross-reference parts and alternative options found for BC327.25. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of BC327.25, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| BC327G-25-T92-B | Unisonic Technologies Co Ltd | Check for Price | Small Signal Bipolar Transistor, | BC327.25 vs BC327G-25-T92-B |
| BC327L-25-T92-B | Unisonic Technologies Co Ltd | Check for Price | Small Signal Bipolar Transistor, | BC327.25 vs BC327L-25-T92-B |
| BC327L-25-T92-K | Unisonic Technologies Co Ltd | Check for Price | Small Signal Bipolar Transistor, | BC327.25 vs BC327L-25-T92-K |
BC327.25 Frequently Asked Questions (FAQ)
-
The maximum operating temperature range for the BC327.25 is -55°C to 150°C.
-
The BC327.25 is not suitable for high-frequency applications due to its relatively low transition frequency (ft) of 100 MHz.
-
Yes, the BC327.25 can be used as a switch, but it's not ideal due to its relatively high saturation voltage (Vce(sat)) of 0.7V.
-
To ensure reliability, follow proper PCB design guidelines, ensure adequate heat sinking, and operate the transistor within its recommended specifications.
-
Yes, the BC327.25 is compatible with lead-free soldering, but ensure that the soldering process follows the recommended temperature profile.
