Transistors / Small Signal Bipolar Transistors / BC847C-TP-HF
Datasheets
BC847C-TP-HF by: Micro Commercial Components

Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon

Part Details for BC847C-TP-HF by Micro Commercial Components

Results Overview of BC847C-TP-HF by Micro Commercial Components

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Audio and Video Systems

BC847C-TP-HF Information

BC847C-TP-HF by Micro Commercial Components is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for BC847C-TP-HF

Part # Distributor Description Stock Price Buy
DISTI # 353-BC847C-TP-HF-ND
DigiKey TRANS NPN 45V 0.1A SOT-23 Lead time: 14 Weeks Container: Bulk Temporarily Out of Stock
Buy Now
DISTI # 66688856
Verical Trans GP BJT NPN 45V 0.1A 200mW 3-Pin SOT-23 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Date Code: 2307 Americas - 27000
  • 3,000 $0.0174
$0.0174 Buy Now
DISTI # BC847C-TP-HF
TME Transistor: NPN, bipolar, 45V, 0.1A, 225mW, SOT23 Min Qty: 25 2875
  • 25 $0.0399
  • 100 $0.0359
  • 500 $0.0317
  • 3,000 $0.0285
  • 12,000 $0.0266
$0.0266 / $0.0399 Buy Now

Part Details for BC847C-TP-HF

BC847C-TP-HF Part Data Attributes

Parametric Data
BC847C-TP-HF Micro Commercial Components
Buy Now Datasheet
Compare Parts:
BC847C-TP-HF Micro Commercial Components Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon
Rohs Code Yes
Part Life Cycle Code Obsolete
Reach Compliance Code Compliant
ECCN Code EAR99
Collector Current-Max (IC) 0.1 A
Collector-Emitter Voltage-Max 45 V
Configuration Single
DC Current Gain-Min (hFE) 420
JESD-30 Code R-PDSO-G3
JESD-609 Code e3
Moisture Sensitivity Level 1
Number of Elements 1
Number of Terminals 3
Package Body Material Plastic/Epoxy
Package Shape Rectangular
Package Style Small Outline
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type Npn
Surface Mount Yes
Terminal Finish Matte Tin
Terminal Form Gull Wing
Terminal Position Dual
Time@Peak Reflow Temperature-Max (s) 10
Transistor Element Material Silicon
Transition Frequency-Nom (fT) 100 Mhz

Alternate Parts for BC847C-TP-HF

This table gives cross-reference parts and alternative options found for BC847C-TP-HF. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of BC847C-TP-HF, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
BC847C-7-F Diodes Incorporated $0.0614 Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847C-7-F
BC847C-13-F Diodes Incorporated $0.0716 Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847C-13-F
BC847C KEC Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847C
BC847CE6433 Infineon Technologies AG Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847CE6433
BC847C-7 Diodes Incorporated Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847C-7
BC847C Promax-Johnton Electronic Corporation Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847C
BC847C WEITRON INTERNATIONAL CO., LTD. Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847C
BC847-C KEC Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847-C
BC847C Micro Commercial Components Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, Silicon BC847C-TP-HF vs BC847C
Part Number Manufacturer Composite Price Description Compare
BC847ALT1G onsemi $0.0071 Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon, TO-236 BC847C-TP-HF vs BC847ALT1G
BC847AWT1G onsemi $0.0588 Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847AWT1G
BC847CTRL13 YAGEO Corporation Check for Price Small Signal Bipolar Transistor, 0.2A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847CTRL13
BC847CM,315 Nexperia Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847CM,315
BC848ATRL YAGEO Corporation Check for Price Small Signal Bipolar Transistor, 0.2A I(C), 30V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC848ATRL
2PC4617RJT/R NXP Semiconductors Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 50V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs 2PC4617RJT/R
BC848A-7 Diodes Incorporated Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 30V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC848A-7
BC847AFT/R NXP Semiconductors Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon BC847C-TP-HF vs BC847AFT/R
BC847TRL NXP Semiconductors Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon, TO-236AB BC847C-TP-HF vs BC847TRL
BC848CLT3G onsemi Check for Price Small Signal Bipolar Transistor, 0.1A I(C), 30V V(BR)CEO, 1-Element, NPN, Silicon, TO-236 BC847C-TP-HF vs BC848CLT3G
