Part Details for BQ294682DRVR by Texas Instruments
Results Overview of BQ294682DRVR by Texas Instruments
- Distributor Offerings: (7 listings)
- Number of FFF Equivalents: (0 replacements)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (3 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Industrial Automation
Energy and Power Systems
Renewable Energy
BQ294682DRVR Information
BQ294682DRVR by Texas Instruments is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for BQ294682DRVR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-BQ294682DRVRTR-ND
|
DigiKey | IC BATT PROT LI-ION 1CELL 6WSON Min Qty: 3000 Container: Tape & Reel |
2464 Tape & Reel |
|
$0.2473 / $0.2659 | Buy Now |
|
DISTI #
296-BQ294682DRVRCT-ND
|
DigiKey | IC BATT PROT LI-ION 1CELL 6WSON Min Qty: 1 Container: Cut Tape |
2464 Cut Tape |
|
$0.2883 / $0.6100 | Buy Now |
|
DISTI #
595-BQ294682DRVR
|
Mouser Electronics | Battery Management Family Overvoltage P rotection Device fo A 595-BQ294682DRVT RoHS: Compliant | 4688 |
|
$0.2590 / $0.6100 | Buy Now |
|
DISTI #
86275881
|
Verical | Battery Protection Li-Ion -0.3V to 30V 6-Pin WSON EP T/R RoHS: Compliant Min Qty: 1145 Package Multiple: 1 Date Code: 1601 | Americas - 3000 |
|
$0.2448 / $0.3276 | Buy Now |
|
|
Rochester Electronics | Battery Management Battery Protection 6-SON T/R RoHS: Compliant Status: Active Min Qty: 1 | 3519 |
|
$0.1958 / $0.3158 | Buy Now |
|
DISTI #
86275881
|
Verical | Battery Protection Li-Ion -0.3V to 30V 6-Pin WSON EP T/R RoHS: Compliant Min Qty: 1145 Package Multiple: 1 Date Code: 1601 | Americas - 3000 |
|
$0.2448 / $0.3276 | Buy Now |
|
DISTI #
86275881
|
Verical | Battery Protection Li-Ion -0.3V to 30V 6-Pin WSON EP T/R RoHS: Compliant Min Qty: 1145 Package Multiple: 1 Date Code: 1601 | Americas - 3000 |
|
$0.2448 / $0.3276 | Buy Now |
US Tariff Estimator: BQ294682DRVR by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
BQ294682DRVR CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
BQ294682DRVR Part Data Attributes
|
|
BQ294682DRVR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
BQ294682DRVR
Texas Instruments
BATTERY PROTECTOR, Fixed, 1 Channel, 4.225, PDSO6
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Part Package Code | SON | |
| Pin Count | 6 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.90 | |
| Adjustable Threshold | No | |
| Analog IC - Other Type | Battery Protector | |
| Input Voltage-Max | 8 V | |
| JESD-30 Code | S-PDSO-N6 | |
| JESD-609 Code | e4 | |
| Length | 2 Mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 110 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | HVSON | |
| Package Equivalence Code | SOLCC6,.08SQ,25 | |
| Package Shape | Square | |
| Package Style | Small Outline, Heat Sink/Slug, Very Thin Profile | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 0.8 Mm | |
| Supply Current-Max (Isup) | 0.00125 Ma | |
| Supply Voltage-Max (Vsup) | 8 V | |
| Supply Voltage-Min (Vsup) | 3 V | |
| Supply Voltage-Nom (Vsup) | 4 V | |
| Surface Mount | Yes | |
| Temperature Grade | Industrial | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au); Matte Tin (Sn) | |
| Terminal Form | No Lead | |
| Terminal Pitch | 0.65 Mm | |
| Terminal Position | Dual | |
| Threshold Voltage-Nom | 4.225 | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 2 Mm |
