Part Details for BQ77910ADBT by Texas Instruments
Results Overview of BQ77910ADBT by Texas Instruments
- Distributor Offerings: (4 listings)
- Number of FFF Equivalents: (1 replacement)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (5 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
BQ77910ADBT Information
BQ77910ADBT by Texas Instruments is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for BQ77910ADBT
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
595-BQ77910ADBT
|
Mouser Electronics | Battery Management 4-10 Cell Prec Prot for Li-Ion Chem A 59 A 595-BQ7693000DBT RoHS: Compliant | 0 |
|
Order Now | |
|
|
Rochester Electronics | Battery Management Multi-Function Controller 38-SOP Tube RoHS: Compliant Status: Not Recommended for New Designs Min Qty: 1 | 56 |
|
$4.0600 / $5.0800 | Buy Now |
|
DISTI #
BQ77910ADBT
|
TME | IC: PMIC, battery charging controller, 3-5 x Li-Ion / Li-Po Min Qty: 1 | 0 |
|
$5.7400 / $8.6100 | RFQ |
|
|
Vyrian | Power Supply Support Circuit, Adjustable, 1 Channel, +4.9V, PDSO38 | 6984 |
|
RFQ |
US Tariff Estimator: BQ77910ADBT by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
BQ77910ADBT CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
BQ77910ADBT Part Data Attributes
|
|
BQ77910ADBT
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
BQ77910ADBT
Texas Instruments
BATTERY PROTECTOR, Adjustable, 1 Channel, +4.9V, PDSO38
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Part Package Code | TSSOP | |
| Package Description | Tssop-38 | |
| Pin Count | 38 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.90 | |
| Adjustable Threshold | Yes | |
| Analog IC - Other Type | Battery Protector | |
| JESD-30 Code | R-PDSO-G38 | |
| JESD-609 Code | e4 | |
| Length | 9.7 Mm | |
| Moisture Sensitivity Level | 2 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 38 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP38,.25,20 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Thin Profile, Shrink Pitch | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.2 Mm | |
| Supply Current-Max (Isup) | 0.075 Ma | |
| Supply Voltage-Max (Vsup) | 43.75 V | |
| Supply Voltage-Min (Vsup) | 5.6 V | |
| Supply Voltage-Nom (Vsup) | 36 V | |
| Surface Mount | Yes | |
| Temperature Grade | Industrial | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.5 Mm | |
| Terminal Position | Dual | |
| Threshold Voltage-Nom | +4.9v | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4.4 Mm |
