Part Details for INA215CIDCKR by Texas Instruments
Results Overview of INA215CIDCKR by Texas Instruments
- Distributor Offerings: (16 listings)
- Number of FFF Equivalents: (2 replacements)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (9 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Education and Research
Internet of Things (IoT)
Computing and Data Storage
Aerospace and Defense
Healthcare
Telecommunications
Automotive
INA215CIDCKR Information
INA215CIDCKR by Texas Instruments is an Operational Amplifier.
Operational Amplifiers are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for INA215CIDCKR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
86310783
|
Verical | SP Amp Current Shunt Monitor Single 26V 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 31 Package Multiple: 1 Date Code: 2247 | Americas - 2673 |
|
$0.1902 / $0.2032 | Buy Now |
|
DISTI #
93862197
|
Verical | SP Amp Current Shunt Monitor Single 26V 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 4 Package Multiple: 1 Date Code: 2247 | Americas - 1914 |
|
$0.4736 / $0.9880 | Buy Now |
|
DISTI #
595-INA215CIDCKR
|
Mouser Electronics | Current Sense Amplifiers 26V bi-directional h igh-precision curr A 595-INA215CIDCKT RoHS: Compliant | 1651 |
|
$0.5300 / $1.1400 | Buy Now |
|
DISTI #
V72:2272_17059385
|
Arrow Electronics | SP Amp Current Shunt Monitor Single 26V 6-Pin SC-70 T/R COO: China RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2247 Container: Cut Strips | Americas - 2673 |
|
$0.1902 / $0.2096 | Buy Now |
|
DISTI #
P02:6590_15783647
|
Arrow Electronics | SP Amp Current Shunt Monitor Single 26V 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 2247 Container: Cut Strips | Asia - 1914 |
|
$0.4736 / $0.9880 | Buy Now |
|
|
Bristol Electronics | SP Amp Current Shunt Monitor Single 26V 6-Pin SC-70 T/R Min Qty: 1 | 430 |
|
$0.3000 / $0.9375 | Buy Now |
|
|
Quest Components | 344 |
|
$0.3750 / $1.2500 | Buy Now | |
|
DISTI #
V72:2272_17059385
|
Arrow Electronics | SP Amp Current Shunt Monitor Single 26V 6-Pin SC-70 T/R COO: China RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2247 Container: Cut Strips | Americas - 2673 |
|
$0.1902 / $0.2096 | Buy Now |
|
DISTI #
P02:6590_15783647
|
Arrow Electronics | SP Amp Current Shunt Monitor Single 26V 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 2247 Container: Cut Strips | Asia - 1914 |
|
$0.4736 / $0.9880 | Buy Now |
|
DISTI #
86310783
|
Verical | SP Amp Current Shunt Monitor Single 26V 6-Pin SC-70 T/R COO: China RoHS: Compliant Min Qty: 31 Package Multiple: 1 Date Code: 2247 | Americas - 2673 |
|
$0.1902 / $0.2032 | Buy Now |
US Tariff Estimator: INA215CIDCKR by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
INA215CIDCKR CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
INA215CIDCKR Part Data Attributes
|
|
INA215CIDCKR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
INA215CIDCKR
Texas Instruments
Operational Amplifier, 1 Func, 60uV Offset-Max, BIPolar, PDSO6
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Package Description | Sot-Sc70-6 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.33.00.01 | |
| Date Of Intro | 2016-11-03 | |
| Amplifier Type | Operational Amplifier | |
| Architecture | Voltage-Feedback | |
| Average Bias Current-Max (IIB) | 35 µA | |
| Bias Current-Max (IIB) @25C | 35 µA | |
| Common Mode Voltage-Max | 26 V | |
| Common-mode Reject Ratio-Min | 105 Db | |
| Common-mode Reject Ratio-Nom | 140 Db | |
| Frequency Compensation | Yes | |
| Input Offset Voltage-Max | 60 µV | |
| JESD-30 Code | R-PDSO-G6 | |
| JESD-609 Code | e4 | |
| Length | 2 Mm | |
| Low-Bias | No | |
| Low-Offset | Yes | |
| Micropower | Yes | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | TSSOP | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Thin Profile, Shrink Pitch | |
| Packing Method | Tr | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power | No | |
| Programmable Power | No | |
| Seated Height-Max | 1.1 Mm | |
| Slew Rate-Nom | 0.4 V/Us | |
| Supply Current-Max | 0.115 Ma | |
| Supply Voltage Limit-Max | 26 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | Yes | |
| Technology | Bipolar | |
| Temperature Grade | Automotive | |
| Terminal Finish | Matte Tin (Sn); Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.65 Mm | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Unity Gain BW-Nom | 40 | |
| Voltage Gain-Nom | 75 | |
| Wideband | No | |
| Width | 1.25 Mm |
