| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| ISO121BG | Texas Instruments | $104.2302 | Isolation Amplifier, 1 Func, 3500V Isolation-Min, 60MHz Band Width, BIPolar, CDIP16 | ISO103 vs ISO121BG |
| ISO120SG | Texas Instruments | $357.0411 | Isolation Amplifier, 1 Func, 2121V Isolation-Min, 60MHz Band Width, BIPolar, CDIP16 | ISO103 vs ISO120SG |
| HCPL-788J | Agilent Technologies Inc | Check for Price | Isolation Amplifier, 1 Func, 3750V Isolation-Min, 30MHz Band Width, PDSO16 | ISO103 vs HCPL-788J |
| ISO121BG-BI | Burr-Brown Corp | Check for Price | Isolation Amplifier, 1 Func, 3500V Isolation-Min, 0.06MHz Band Width, BIPolar, CDIP40 | ISO103 vs ISO121BG-BI |
| HCPL-788J#500 | Avago Technologies | Check for Price | ISOLATION AMPLIFIER, 3750 V ISOLATION-MIN, 30 kHz BAND WIDTH, PDSO16, SOP-16 | ISO103 vs HCPL-788J#500 |
| ISO175P | Texas Instruments | Check for Price | Isolation Amplifier, 1 Func, 1500V Isolation-Min, 0.06MHz Band Width, PDIP16 | ISO103 vs ISO175P |
| ISO113B/2K5 | Texas Instruments | Check for Price | Isolation Amplifier, 1 Func, 1500V Isolation-Min, 20MHz Band Width, CDIP16 | ISO103 vs ISO113B/2K5 |
| HCPL-788J-E | Avago Technologies | Check for Price | ISOLATION AMPLIFIER, 3750V ISOLATION-MIN, 30kHz BAND WIDTH, PDSO16, LEAD FREE, SOP-16 | ISO103 vs HCPL-788J-E |
| IL611-ETR7 | NVE Corporation | Check for Price | Interface Circuit | ISO103 vs IL611-ETR7 |
| HCPL-788J500 | Hewlett Packard Co | Check for Price | Isolation Amplifier, 1 Func, 3750V Isolation-Min, 30MHz Band Width, PDSO16, SO-16 | ISO103 vs HCPL-788J500 |
Part Details for ISO103 by Texas Instruments
Results Overview of ISO103 by Texas Instruments
- Distributor Offerings: (3 listings)
- Number of FFF Equivalents: (0 replacements)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (10 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
Renewable Energy
Automotive
ISO103 Information
ISO103 by Texas Instruments is an Isolation Amplifier.
Isolation Amplifiers are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for ISO103
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
ISO103-ND
|
DigiKey | IC OP AMP 1CH 16-CDIP Container: Tube |
0 Tube |
|
Buy Now | |
|
DISTI #
86115511
|
Verical | SP Amp ISOL Amp Single ±18V 16-Pin SBCDIP Tube RoHS: Compliant Min Qty: 2 Package Multiple: 1 | Americas - 15 |
|
$217.1750 / $246.7875 | Buy Now |
|
|
Rochester Electronics | Isolation Amplifier, 1 Func, 1500V Isolation-Min, 20MHz Band Width, Hybrid, CDIP16 RoHS: Compliant Status: Obsolete Min Qty: 1 | 2086 |
|
$173.7400 / $197.4300 | Buy Now |
US Tariff Estimator: ISO103 by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
ISO103 CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
ISO103 Part Data Attributes
|
|
ISO103
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
ISO103
Texas Instruments
Isolation Amplifier, 1 Func, 1500V Isolation-Min, 20MHz Band Width, Hybrid, CDIP16
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Part Package Code | DIP | |
| Package Description | 0.600 Inch, Side Brazed, Hybrid, Ceramic, Dip-24/16 | |
| Pin Count | 24 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.33.00.01 | |
| Amplifier Type | Isolation Amplifier | |
| Bandwidth (3dB)-Nom | 20 Mhz | |
| Common Mode Voltage-Max | 1500 V | |
| Isolation Voltage-Min | 1500 V | |
| JESD-30 Code | R-CDIP-T16 | |
| Length | 31.05 Mm | |
| Neg Supply Voltage Limit-Max | -18 V | |
| Neg Supply Voltage-Nom (Vsup) | -15 V | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -25 °C | |
| Package Body Material | Ceramic, Metal-Sealed Cofired | |
| Package Code | DIP | |
| Package Equivalence Code | DIP16/24,.6 | |
| Package Shape | Rectangular | |
| Package Style | In-Line | |
| Peak Reflow Temperature (Cel) | Not Specified | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 9.52 Mm | |
| Supply Current-Max | 90 Ma | |
| Supply Voltage Limit-Max | 18 V | |
| Supply Voltage-Nom (Vsup) | 15 V | |
| Surface Mount | No | |
| Technology | Hybrid | |
| Temperature Grade | Other | |
| Terminal Form | Through-Hole | |
| Terminal Pitch | 2.54 Mm | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | Not Specified | |
| Width | 15.24 Mm |
Alternate Parts for ISO103
This table gives cross-reference parts and alternative options found for ISO103. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of ISO103, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
ISO103 Frequently Asked Questions (FAQ)
-
The maximum data rate of ISO103 is 100 Mbps, but it can be limited by the capacitance of the isolation barrier and the signal transmission frequency.
-
ISO103 has a high common-mode transient immunity of 25 kV/μs, which helps to protect the device from voltage spikes and transients.
-
The maximum working voltage that can be isolated by ISO103 is 2500 Vrms for 1 minute, which is suitable for most industrial and medical applications.
-
Yes, ISO103 has an operating temperature range of -40°C to 125°C, making it suitable for use in high-temperature applications.
-
ISO103 has built-in error detection and correction mechanisms, such as 8B/10B encoding and cyclic redundancy checks (CRCs), to ensure data integrity and reliability.
