ISO7810FDWW Information
ISO7810FDWW by Texas Instruments is an Other Interface IC.
Other Interface ICs are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for ISO7810FDWW
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
ISO7810FDWW-ND
|
DigiKey | DGTL ISOLTR 5.7KV 1CH GP 16-SOIC Min Qty: 180 Container: Tube |
0 Tube |
|
$5.5101 | Buy Now |
|
DISTI #
595-ISO7810FDWW
|
Mouser Electronics | Digital Isolators Highest isolation ra ting single-channel A 595-ISO7810FDWWR RoHS: Compliant | 135 |
|
$5.2100 / $8.5400 | Buy Now |
|
DISTI #
595-ISO7810FDWW
|
Mouser Electronics | Digital Isolators Highest isolation ra ting single-channel A 595-ISO7810FDWWR RoHS: Compliant | 135 |
|
$5.2100 / $8.5400 | Buy Now |
|
|
Chip Stock | Highest isolation rating, single-channel, reinforced digital isolator 16-SOIC -55 to 125 | 2618 |
|
RFQ | |
|
|
Vyrian | Interface Circuit, CMOS, PDSO16 | 9728 |
|
RFQ |
US Tariff Estimator: ISO7810FDWW by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
Part Details for ISO7810FDWW
ISO7810FDWW CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
ISO7810FDWW Part Data Attributes
|
|
ISO7810FDWW
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
ISO7810FDWW
Texas Instruments
Interface Circuit, CMOS, PDSO16
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.90 | |
| Date Of Intro | 2016-06-15 | |
| Additional Feature | Also Require Vcc2 From 2.25 -5.5v; Also Operate With 3.3v And 5 V Supply | |
| Interface IC Type | Interface Circuit | |
| JESD-30 Code | R-PDSO-G16 | |
| JESD-609 Code | e4 | |
| Moisture Sensitivity Level | 3 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | SOP | |
| Package Shape | Rectangular | |
| Package Style | Small Outline | |
| Peak Reflow Temperature (Cel) | 260 | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 2.25 V | |
| Supply Voltage-Nom | 2.5 V | |
| Surface Mount | Yes | |
| Technology | Cmos | |
| Temperature Grade | Military | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | Gull Wing | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
