LP2997MR Information
LP2997MR by Texas Instruments is an Other Regulator.
Other Regulators are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| LP2997MR | Texas Instruments | DDR-II Termination Regulator 8-SO PowerPAD 0 to 125 | |
| LP2997MR/NOPB | Texas Instruments | DDR-II Termination Regulator 8-SO PowerPAD 0 to 125 | |
| LP2997MRX/NOPB | Texas Instruments | DDR-II Termination Regulator 8-SO PowerPAD 0 to 125 |
