| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| PCM4202DBTG4 | Texas Instruments | 118dB SNR Stereo Audio ADC 28-SSOP -10 to 70 | |
| PCM4202DBT | Texas Instruments | 118dB SNR Stereo Audio ADC 28-SSOP -10 to 70 |
| Part # | Manufacturer | Description | Stock | Price | Buy | ||
|---|---|---|---|---|---|---|---|
|
DISTI #
28AH4682
|
Newark | 24Bit Adc, 2Ch Audio, Smd, Ssop28, Resolution (Bits):24Bit, Sampling Rate:216Ksps, Input Channel Type:Single Ended, Data Interface:Serial, Supply Voltage Type:Single, Supply Voltage Min:4.75V, Supply Voltage Max:5.25V, Adc/Dac Caserohs Compliant: Yes |TEXAS INSTRUMENTS PCM4202DBT RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 0 |
|
$12.3200 / $14.8200 | Buy Now | |
|
DISTI #
296-17438-1-ND
|
DigiKey | IC ADC/AUDIO 24BIT 216K 28SSOP Min Qty: 1 Lead time: 6 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
997 In Stock |
|
$7.0480 / $12.5500 | Buy Now | |
|
DISTI #
595-PCM4202DBT
|
Mouser Electronics | Audio A/D Converter ICs 24-Bit/192kHz 118dB Stereo Audio A/D RoHS: Compliant | 3071 |
|
$6.3700 / $10.7900 | Buy Now | |
|
DISTI #
SMC-PCM4202DBT
|
Sensible Micro Corporation | AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days | 1126 |
|
RFQ | ||
| Win Source Electronics | IC ADC STEREO 24BIT HP 28-SSOP | 13200 |
|
$3.8640 / $5.7960 | Buy Now |
|
|
|
|---|---|
|
Pbfree Code
|
Yes
|
|
Rohs Code
|
Yes
|
|
Part Life Cycle Code
|
Active
|
|
Ihs Manufacturer
|
TEXAS INSTRUMENTS INC
|
|
Part Package Code
|
SSOP
|
|
Package Description
|
SSOP-28
|
|
Pin Count
|
28
|
|
Reach Compliance Code
|
compliant
|
|
ECCN Code
|
EAR99
|
|
HTS Code
|
8542.39.00.01
|
|
Samacsys Manufacturer
|
Texas Instruments
|
|
Analog Input Voltage-Max
|
6 V
|
|
Analog Input Voltage-Min
|
|
|
Converter Type
|
ADC, DELTA-SIGMA
|
|
JESD-30 Code
|
R-PDSO-G28
|
|
JESD-609 Code
|
e4
|
|
Length
|
10.2 mm
|
|
Moisture Sensitivity Level
|
2
|
|
Number of Analog In Channels
|
2
|
|
Number of Bits
|
24
|
|
Number of Functions
|
1
|
|
Number of Terminals
|
28
|
|
Operating Temperature-Max
|
70 °C
|
|
Operating Temperature-Min
|
-10 °C
|
|
Output Bit Code
|
2'S COMPLEMENT BINARY
|
|
Output Format
|
SERIAL
|
|
Package Body Material
|
PLASTIC/EPOXY
|
|
Package Code
|
SSOP
|
|
Package Equivalence Code
|
SSOP28,.3
|
|
Package Shape
|
RECTANGULAR
|
|
Package Style
|
SMALL OUTLINE, SHRINK PITCH
|
|
Peak Reflow Temperature (Cel)
|
260
|
|
Qualification Status
|
Not Qualified
|
|
Sample Rate
|
0.216 MHz
|
|
Seated Height-Max
|
2 mm
|
|
Supply Current-Max
|
65 mA
|
|
Supply Voltage-Nom
|
5 V
|
|
Surface Mount
|
YES
|
|
Temperature Grade
|
COMMERCIAL
|
|
Terminal Finish
|
NICKEL PALLADIUM GOLD
|
|
Terminal Form
|
GULL WING
|
|
Terminal Pitch
|
0.65 mm
|
|
Terminal Position
|
DUAL
|
|
Time@Peak Reflow Temperature-Max (s)
|
30
|
|
Width
|
5.3 mm
|
| Part Number | Description | Manufacturer | Compare |
|---|---|---|---|
| PCM4202DB | 118dB SNR Stereo Audio ADC 28-SSOP -10 to 70 | Texas Instruments | PCM4202DBT vs PCM4202DB |
| PCM4202DBRG4 | 118dB SNR Stereo Audio ADC 28-SSOP -10 to 70 | Texas Instruments | PCM4202DBT vs PCM4202DBRG4 |
| PCM4202DBR | 118dB SNR Stereo Audio ADC 28-SSOP -10 to 70 | Texas Instruments | PCM4202DBT vs PCM4202DBR |
| PCM4202DBTG4 | 118dB SNR Stereo Audio ADC 28-SSOP -10 to 70 | Texas Instruments | PCM4202DBT vs PCM4202DBTG4 |
