3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for REC10-1205D/H3/M by RECOM Power GmbH
Results Overview of REC10-1205D/H3/M by RECOM Power GmbH
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (0 replacements)
- Tariff Estimator: (Not Available)
- Number of Functional Equivalents: (0 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
Transportation and Logistics
Renewable Energy
Automotive
REC10-1205D/H3/M Information
REC10-1205D/H3/M by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for REC10-1205D/H3/M
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
REC10-1205D/H3/M-ND
|
DigiKey | DC DC CONVERTER +/-5V 10W Min Qty: 10 Lead time: 17 Weeks Container: Tube | Temporarily Out of Stock |
|
$49.9110 | Buy Now |
|
DISTI #
919-REC10-1205D/H3/M
|
Mouser Electronics | DC/DC Converters - Through Hole 10W9-18VIN +/-5V THT RoHS: Compliant | 0 |
|
$48.1500 / $56.5100 | Order Now |
|
DISTI #
10015968
|
RECOM Power | 10W DC/DC-Converter 'ECONOLINE' 2"x1" 3kV reg 2:1 RoHS: Compliant | 0 |
|
$49.9100 | RFQ |
|
|
Onlinecomponents.com | Dual Regulated DC-DC Converter - 10W - Input: 9 to 18VDC - Output: (+/-) 5VDC - 3kV Isolation - Thru Hole COO: Taiwan RoHS: Compliant | 0 |
|
$41.0200 / $53.8400 | Buy Now |
|
DISTI #
10015968
|
Richardson RFPD | DC TO DC CONVERTER MODULE RoHS: Compliant Min Qty: 10 | 0 |
|
$39.0400 | Buy Now |
|
DISTI #
000000000006052122
|
Sager | Isolated DC/DC Converters - Through Hole 10W9-18VIN +/-5V THT Min Qty: 1 | 0 |
|
$44.6200 / $52.0600 | Buy Now |
Part Details for REC10-1205D/H3/M
REC10-1205D/H3/M CAD Models
REC10-1205D/H3/M Part Data Attributes
|
|
REC10-1205D/H3/M
RECOM Power GmbH
Buy Now
Datasheet
|
Compare Parts:
REC10-1205D/H3/M
RECOM Power GmbH
DC-DC Regulated Power Supply Module
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Package Description | Dma, Module,6lead,0.8 | |
| Reach Compliance Code | Compliant | |
| ECCN Code | EAR99 | |
| Analog IC - Other Type | Dc-Dc Regulated Power Supply Module | |
| Input Voltage-Max | 18 V | |
| Input Voltage-Min | 9 V | |
| Input Voltage-Nom | 12 V | |
| JESD-30 Code | R-MDMA-P6 | |
| JESD-609 Code | e3 | |
| Length | 50.8 Mm | |
| Number of Functions | 1 | |
| Number of Outputs | 2 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 81 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 1 A | |
| Output Voltage-Max | 5.05 V | |
| Output Voltage-Min | 4.95 V | |
| Output Voltage-Nom | 5 V | |
| Package Body Material | Metal | |
| Package Code | DMA | |
| Package Equivalence Code | MODULE,6LEAD,0.8 | |
| Package Shape | Rectangular | |
| Package Style | Microelectronic Assembly | |
| Peak Reflow Temperature (Cel) | Not Specified | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 10.7 Mm | |
| Surface Mount | No | |
| Temperature Grade | Other | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | Through-Hole | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | Not Specified | |
| Total Power Output-Max | 10 W | |
| Width | 25.4 Mm |
