ST3222EBPR Information
ST3222EBPR by STMicroelectronics is a Line Driver or Receiver.
Line Driver or Receivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for ST3222EBPR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
26AH0287
|
Newark | Rs232 Transceiver, -40 To 85Deg C, |Stmicroelectronics ST3222EBPR RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 2417 |
|
$1.0300 / $2.2400 | Buy Now |
|
DISTI #
497-6531-6-ND
|
DigiKey | IC TRANSCEIVER FULL 2/2 20SSOP Min Qty: 1 Container: Digi-Reel |
909 Digi-Reel® |
|
$1.1927 / $2.1700 | Buy Now |
|
DISTI #
497-6531-1-ND
|
DigiKey | IC TRANSCEIVER FULL 2/2 20SSOP Min Qty: 1 Container: Cut Tape |
909 Cut Tape |
|
$1.1927 / $2.1700 | Buy Now |
|
DISTI #
497-6531-2-ND
|
DigiKey | IC TRANSCEIVER FULL 2/2 20SSOP Min Qty: 1350 Container: Tape & Reel |
909 Tape & Reel |
|
$1.0797 / $1.1370 | Buy Now |
|
DISTI #
ST3222EBPR
|
Avnet Americas | RS232 Transceiver, 2 Drivers, 2 Receivers, 3V to 5.5V Supply, SSOP-20 - Tape and Reel (Alt: ST3222EBPR) COO: Singapore RoHS: Compliant Min Qty: 1350 Package Multiple: 1350 Lead time: 30 Weeks, 0 Days Container: Tape & Reel | 2700 |
|
$0.7344 / $0.7497 | Buy Now |
|
DISTI #
511-ST3222EBP
|
Mouser Electronics | RS-232 Interface IC Lo Power 2Drvr/2Rcvr RoHS: Compliant | 1910 |
|
$1.0100 / $2.1700 | Buy Now |
|
DISTI #
511-ST3222EBP
|
Mouser Electronics | RS-232 Interface IC Lo Power 2Drvr/2Rcvr RoHS: Compliant | 1851 |
|
$0.9980 / $2.1700 | Buy Now |
|
|
STMicroelectronics | 15kV ESD protected, 3 to 5.5V low power, up to 250Kbps, RS-232 drivers and receivers COO: Singapore RoHS: Compliant Min Qty: 1 | 1851 |
|
$1.1200 / $2.1700 | Buy Now |
|
|
Future Electronics | ST3222EB Series ±15 kV ESD 5.5 V 250 Kbps RS-232 Drivers and Receiver - SSOP-20 RoHS: Compliant pbFree: Yes Min Qty: 2700 Package Multiple: 1350 Lead time: 30 Weeks Container: Reel | 0Reel |
|
$0.7650 / $0.7900 | Buy Now |
|
|
Bristol Electronics | Dual Transmitter/Receiver RS-232 20-Pin SSOP T/R Min Qty: 1 | 271 |
|
$1.4147 / $2.8293 | Buy Now |
US Tariff Estimator: ST3222EBPR by STMicroelectronics
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
Part Details for ST3222EBPR
ST3222EBPR CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
ST3222EBPR Part Data Attributes
|
|
ST3222EBPR
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
ST3222EBPR
STMicroelectronics
Line Transceiver, 2 Func, 2 Driver, 2 Rcvr, PDSO20
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Part Package Code | SSOP | |
| Package Description | Lead Free, Ssop-20 | |
| Pin Count | 20 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.60 | |
| Factory Lead Time | 11 Weeks | |
| Differential Output | No | |
| Driver Number of Bits | 2 | |
| Input Characteristics | Schmitt Trigger | |
| Interface IC Type | Line Transceiver | |
| Interface Standard | Eia-232; Tia-232; V.24; V.28 | |
| JESD-30 Code | R-PDSO-G20 | |
| JESD-609 Code | e3 | |
| Length | 7.2 Mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 2 | |
| Number of Terminals | 20 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Out Swing-Min | 10 V | |
| Output Low Current-Max | 0.0016 A | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | SSOP | |
| Package Equivalence Code | SSOP20,.3 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Shrink Pitch | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Receiver Number of Bits | 2 | |
| Seated Height-Max | 2 Mm | |
| Supply Current-Max | 1 Ma | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 3 V | |
| Supply Voltage-Nom | 3.3 V | |
| Surface Mount | Yes | |
| Temperature Grade | Industrial | |
| Terminal Finish | Matte Tin (Sn) - Annealed | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.65 Mm | |
| Terminal Position | Dual | |
| Width | 5.3 Mm |
