Part Details for TDA2030V by STMicroelectronics
Results Overview of TDA2030V by STMicroelectronics
- Distributor Offerings: (1 listing)
- Number of FFF Equivalents: (0 replacements)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (2 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Price & Stock for TDA2030V
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Vyrian | Audio Amplifier, 18W, 1 Channel(s), 1 Func, PZFM5 | 8193 |
|
RFQ |
US Tariff Estimator: TDA2030V by STMicroelectronics
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
TDA2030V CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
TDA2030V Part Data Attributes
|
|
TDA2030V
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
TDA2030V
STMicroelectronics
Audio Amplifier, 18W, 1 Channel(s), 1 Func, PZFM5
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Part Package Code | ZFM | |
| Package Description | Pentawatt-5 | |
| Pin Count | 5 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.33.00.01 | |
| Additional Feature | It Can Also Operate With 12v To 36v Single Supply | |
| Bandwidth-Nom | 15 Khz | |
| Consumer IC Type | Audio Amplifier | |
| Gain | 30 Db | |
| Harmonic Distortion | 10% | |
| JESD-30 Code | R-PZIP-T5 | |
| JESD-609 Code | e3 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 5 | |
| Output Power-Nom | 18 W | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | ZIP | |
| Package Equivalence Code | ZIP5,.15,.2,67TB | |
| Package Shape | Rectangular | |
| Package Style | Flange Mount | |
| Qualification Status | Not Qualified | |
| Supply Current-Max | 60 Ma | |
| Supply Voltage-Max (Vsup) | 18 V | |
| Supply Voltage-Min (Vsup) | 6 V | |
| Surface Mount | No | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | Through-Hole | |
| Terminal Pitch | 1.7 Mm | |
| Terminal Position | Zig-Zag |
Alternate Parts for TDA2030V
This table gives cross-reference parts and alternative options found for TDA2030V. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of TDA2030V, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
TDA2030V Frequently Asked Questions (FAQ)
-
The maximum power dissipation of the TDA2030V is 20W, but it can be increased to 30W with proper heat sinking.
-
The gain resistor (Rg) should be chosen based on the desired gain and input impedance. A higher Rg value will result in higher gain, but may also increase noise and distortion. A good starting point is Rg = 2.2 kΩ for a gain of 20 dB.
-
The recommended operating voltage range for the TDA2030V is ±12V to ±18V, but it can operate with a single supply voltage of 24V to 36V with proper biasing.
-
To prevent oscillations and instability, ensure that the circuit is properly bypassed, use a low-ESR capacitor for power supply decoupling, and add a Zobel network (R-C-R) to the output stage if necessary.
-
The maximum output current of the TDA2030V is 3.5 A peak, but it can be limited by the power supply and heat sinking capabilities.
