| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| THS3217IRGVT | Texas Instruments | $7.0528 | Analog Circuit, 1 Func, 1 Channel, PQCC16 | THS3217IRGVR vs THS3217IRGVT |
Part Details for THS3217IRGVR by Texas Instruments
Results Overview of THS3217IRGVR by Texas Instruments
- Distributor Offerings: (3 listings)
- Number of FFF Equivalents: (1 replacement)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (1 option)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Education and Research
Consumer Electronics
Internet of Things (IoT)
Audio and Video Systems
Computing and Data Storage
Aerospace and Defense
Healthcare
Telecommunications
Automotive
THS3217IRGVR Information
THS3217IRGVR by Texas Instruments is an Other Signal Circuit.
Other Signal Circuits are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| THS3217IRGVR | Texas Instruments | DC to 800-MHz, Differential-to-Single-Ended, DAC Output Amplifier 16-VQFN -40 to 85 |
Price & Stock for THS3217IRGVR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
595-THS3217IRGVR
|
Mouser Electronics | High Speed Operational Amplifiers DC to 800-MHz Diffe rential-to-Single-En A 595-THS3217IRGVT RoHS: Compliant | 0 |
|
$11.2600 | Order Now |
|
DISTI #
THS3217IRGVR
|
TME | IC: operational amplifier, 800MHz, Ch: 1, ±4÷7.9VDC, VQFN16, 47mV Min Qty: 1 | 0 |
|
$8.1400 / $13.4000 | RFQ |
|
|
Vyrian | Analog Circuit, 1 Func, 1 Channel, PQCC16 | 5400 |
|
RFQ |
US Tariff Estimator: THS3217IRGVR by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
THS3217IRGVR CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
THS3217IRGVR Part Data Attributes
|
|
THS3217IRGVR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
THS3217IRGVR
Texas Instruments
Analog Circuit, 1 Func, 1 Channel, PQCC16
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Package Description | Vqfn-16 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.33.00.01 | |
| Date Of Intro | 2016-03-05 | |
| Analog IC - Other Type | Analog Circuit | |
| JESD-30 Code | S-PQCC-N16 | |
| JESD-609 Code | e4 | |
| Length | 4 Mm | |
| Moisture Sensitivity Level | 1 | |
| Neg Supply Voltage-Max (Vsup) | -4 V | |
| Neg Supply Voltage-Min (Vsup) | -7.9 V | |
| Neg Supply Voltage-Nom (Vsup) | -6 V | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | HVQCCN | |
| Package Shape | Square | |
| Package Style | Chip Carrier, Heat Sink/Slug, Very Thin Profile | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1 Mm | |
| Supply Voltage-Max (Vsup) | 7.9 V | |
| Supply Voltage-Min (Vsup) | 4 V | |
| Supply Voltage-Nom (Vsup) | 6 V | |
| Surface Mount | Yes | |
| Temperature Grade | Industrial | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | No Lead | |
| Terminal Pitch | 0.65 Mm | |
| Terminal Position | Quad | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4 Mm |
