TL3116CPWR Information
TL3116CPWR by Texas Instruments is a Comparator.
Comparators are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| TL3116CPWR | Texas Instruments | Ultra-Fast Low-Power Precision Comparator 8-TSSOP 0 to 70 |
Price & Stock for TL3116CPWR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-6627-2-ND
|
DigiKey | IC COMPARATOR 1CH 8-TSSOP Container: Tape & Reel |
1088 Tape & Reel |
|
Buy Now | |
|
DISTI #
296-6627-1-ND
|
DigiKey | IC COMPARATOR 1CH 8-TSSOP Min Qty: 1 Container: Cut Tape |
1088 Cut Tape |
|
$1.7044 / $3.1100 | Buy Now |
|
DISTI #
69099989
|
Verical | Comparator Single ±5V/10V 8-Pin TSSOP T/R RoHS: Compliant Min Qty: 15 Package Multiple: 1 Date Code: 2050 | Americas - 336 |
|
$0.3937 / $0.4204 | Buy Now |
|
DISTI #
V72:2272_07373188
|
Arrow Electronics | Comparator Single ±5V/10V 8-Pin TSSOP T/R COO: Malaysia RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 99 Weeks Date Code: 2050 Container: Cut Strips | Americas - 336 |
|
$0.3937 / $0.4271 | Buy Now |
|
DISTI #
V72:2272_07373188
|
Arrow Electronics | Comparator Single ±5V/10V 8-Pin TSSOP T/R COO: Malaysia RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 99 Weeks Date Code: 2050 Container: Cut Strips | Americas - 336 |
|
$0.3937 / $0.4271 | Buy Now |
|
DISTI #
69099989
|
Verical | Comparator Single ±5V/10V 8-Pin TSSOP T/R COO: Malaysia RoHS: Compliant Min Qty: 15 Package Multiple: 1 Date Code: 2050 | Americas - 336 |
|
$0.3937 / $0.4204 | Buy Now |
|
DISTI #
69099989
|
Verical | Comparator Single ±5V/10V 8-Pin TSSOP T/R COO: Malaysia RoHS: Compliant Min Qty: 15 Package Multiple: 1 Date Code: 2050 | Americas - 336 |
|
$0.3937 / $0.4204 | Buy Now |
|
DISTI #
V72:2272_07373188
|
Arrow Electronics | Comparator Single ±5V/10V 8-Pin TSSOP T/R COO: Malaysia RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 99 Weeks Date Code: 2050 Container: Cut Strips | Americas - 336 |
|
$0.3937 / $0.4271 | Buy Now |
US Tariff Estimator: TL3116CPWR by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
TL3116CPWR CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
TL3116CPWR Part Data Attributes
|
|
TL3116CPWR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TL3116CPWR
Texas Instruments
Comparator, 1 Func, 3000uV Offset-Max, 9.9ns Response Time, BIPolar, PDSO8
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Part Package Code | SOIC | |
| Pin Count | 8 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Amplifier Type | Comparator | |
| Average Bias Current-Max (IIB) | 1.2 µA | |
| Bias Current-Max (IIB) @25C | 1.1 µA | |
| Input Offset Voltage-Max | 3000 µV | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e4 | |
| Length | 4.4 Mm | |
| Moisture Sensitivity Level | 1 | |
| Neg Supply Voltage Limit-Max | -7 V | |
| Neg Supply Voltage-Nom (Vsup) | -5 V | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Output Type | Totem Pole | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP8,.25 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Thin Profile, Shrink Pitch | |
| Packing Method | Tr | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Response Time-Nom | 9.9 Ns | |
| Seated Height-Max | 1.2 Mm | |
| Supply Current-Max | 14.7 Ma | |
| Supply Voltage Limit-Max | 7 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | Yes | |
| Technology | Bipolar | |
| Temperature Grade | Commercial | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.65 Mm | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3 Mm |
