TS331IQT Information
TS331IQT by STMicroelectronics is a Comparator.
Comparators are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for TS331IQT
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
47AK7085
|
Newark | Comparator, Dfn-6, -40 To 125Deg C, |Stmicroelectronics TS331IQT RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 4388 |
|
$1.0700 / $1.5800 | Buy Now |
|
DISTI #
47AK7085RL
|
Newark | Comparator, Dfn-6, -40 To 125Deg C, |Stmicroelectronics TS331IQT RoHS: Compliant Min Qty: 100 Package Multiple: 1 Date Code: 0 Container: Tape & Reel | 4388 |
|
$1.0700 / $1.3300 | Buy Now |
|
DISTI #
79AH7542
|
Newark | Comparator, Dfn-6, -40 To 125Deg C, |Stmicroelectronics TS331IQT RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Tape & Reel | 0 |
|
$0.6520 / $0.6790 | Buy Now |
|
DISTI #
497-13508-6-ND
|
DigiKey | IC COMPARATOR 1CH Min Qty: 1 Container: Digi-Reel |
2705 Digi-Reel® |
|
$0.7364 / $1.4200 | Buy Now |
|
DISTI #
497-13508-1-ND
|
DigiKey | IC COMPARATOR 1CH Min Qty: 1 Container: Cut Tape |
2705 Cut Tape |
|
$0.7364 / $1.4200 | Buy Now |
|
DISTI #
497-13508-2-ND
|
DigiKey | IC COMPARATOR 1CH Min Qty: 3000 Container: Tape & Reel |
0 Tape & Reel |
|
$0.6593 / $0.6905 | Buy Now |
|
DISTI #
511-TS331IQT
|
Mouser Electronics | Analog Comparators 1.6V to 5V 20uA MicroPWR 2kV 210ns RoHS: Compliant | 5342 |
|
$0.6410 / $1.4200 | Buy Now |
|
DISTI #
93259898
|
Verical | Comparator Single R-R I/P ±2.5V/5V 6-Pin DFN T/R RoHS: Compliant Min Qty: 3 Package Multiple: 1 | Americas - 2480 |
|
$0.6498 | Buy Now |
|
|
STMicroelectronics | Micropower low-voltage rail-to-rail comparator COO: Taiwan Min Qty: 1 | 5342 |
|
$0.7500 / $1.4200 | Buy Now |
|
|
Future Electronics | TS331 Series 5 V 40 nA Surface Mount Single Voltage Comparator - DFN-6 RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 30 Weeks Container: Reel | 0Reel |
|
$0.6000 | Buy Now |
US Tariff Estimator: TS331IQT by STMicroelectronics
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
TS331IQT CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
TS331IQT Part Data Attributes
|
|
TS331IQT
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
TS331IQT
STMicroelectronics
Comparator, 1 Func, 6000uV Offset-Max, 420ns Response Time, PDSO6
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Package Description | Dfn-6 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.60 | |
| Amplifier Type | Comparator | |
| Average Bias Current-Max (IIB) | 0.1 µA | |
| Input Offset Voltage-Max | 6000 µV | |
| JESD-30 Code | R-PDSO-N6 | |
| JESD-609 Code | e4 | |
| Length | 1.3 Mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Type | Open-Drain | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | VSON | |
| Package Equivalence Code | SOLCC6,.05,16 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Very Thin Profile | |
| Packing Method | Tr | |
| Peak Reflow Temperature (Cel) | 260 | |
| Response Time-Nom | 420 Ns | |
| Seated Height-Max | 0.55 Mm | |
| Supply Voltage Limit-Max | 5.5 V | |
| Supply Voltage-Nom (Vsup) | 1.8 V | |
| Surface Mount | Yes | |
| Temperature Grade | Automotive | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | No Lead | |
| Terminal Pitch | 0.4 Mm | |
| Terminal Position | Dual | |
| Width | 1.2 Mm |
