TSZ121ICT Information
TSZ121ICT by STMicroelectronics is an Operational Amplifier.
Operational Amplifiers are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for TSZ121ICT
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
07AH7206
|
Newark | Opamp, 400Khz, -40 To 125Deg C, |Stmicroelectronics TSZ121ICT RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 1092 |
|
$0.4840 / $1.0100 | Buy Now |
|
DISTI #
07AH7206RL
|
Newark | Opamp, 400Khz, -40 To 125Deg C, |Stmicroelectronics TSZ121ICT RoHS: Compliant Min Qty: 100 Package Multiple: 1 Date Code: 0 Container: Tape & Reel | 1092 |
|
$0.4840 / $0.5780 | Buy Now |
|
DISTI #
497-13509-1-ND
|
DigiKey | IC OPAMP ZERO-DRIFT 1CIRC SC70-5 Min Qty: 1 Container: Cut Tape |
3183 Cut Tape |
|
$0.5719 / $1.1300 | Buy Now |
|
DISTI #
497-13509-6-ND
|
DigiKey | IC OPAMP ZERO-DRIFT 1CIRC SC70-5 Min Qty: 1 Container: Digi-Reel |
3183 Digi-Reel® |
|
$0.5719 / $1.1300 | Buy Now |
|
DISTI #
497-13509-2-ND
|
DigiKey | IC OPAMP ZERO-DRIFT 1CIRC SC70-5 Min Qty: 3000 Container: Tape & Reel |
3000 Tape & Reel |
|
$0.5142 / $0.5397 | Buy Now |
|
DISTI #
V72:2272_06548732
|
Arrow Electronics | Op Amp Single Micropower Amplifier R-R I/O 5.5V 5-Pin SC-70 T/R COO: Malaysia RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 30 Weeks Date Code: 2313 Container: Cut Strips | Americas - 696 |
|
$0.6764 / $0.7338 | Buy Now |
|
DISTI #
511-TSZ121ICT
|
Mouser Electronics | Precision Amplifiers 20uV 5V Micro Op Amp 1.8 to 5.5V 400kHz RoHS: Compliant | 7258 |
|
$0.5380 / $1.0900 | Buy Now |
|
DISTI #
67611851
|
Verical | Op Amp Single Micropower Amplifier R-R I/O 5.5V 5-Pin SC-70 T/R RoHS: Compliant Min Qty: 9 Package Multiple: 1 Date Code: 2313 | Americas - 696 |
|
$0.6764 / $0.7223 | Buy Now |
|
|
STMicroelectronics | Very high accuracy (5 uV) zero drift 5 V CMOS Op-Amp, single, GBP=400kHz COO: France Min Qty: 1 | 7258 |
|
$0.5900 / $1.0900 | Buy Now |
|
|
Future Electronics | TSZ121 Series 5.5 V 400 kHz Rail to Rail SMT Operational Amplifier - SOT-323 RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 30 Weeks Container: Reel | 3000Reel |
|
$0.4700 / $0.4800 | Buy Now |
US Tariff Estimator: TSZ121ICT by STMicroelectronics
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
TSZ121ICT CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
TSZ121ICT Part Data Attributes
|
|
TSZ121ICT
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
TSZ121ICT
STMicroelectronics
Operational Amplifier, 5 Func, 8uV Offset-Max, CMOS, PDSO1
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Package Description | Sc-70,5 Pin | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.33.00.01 | |
| Factory Lead Time | 16 Weeks | |
| Amplifier Type | Operational Amplifier | |
| Architecture | Voltage-Feedback | |
| Average Bias Current-Max (IIB) | 0.0003 µA | |
| Bias Current-Max (IIB) @25C | 0.0002 µA | |
| Common-mode Reject Ratio-Min | 115 Db | |
| Common-mode Reject Ratio-Nom | 128 Db | |
| Frequency Compensation | Yes | |
| Input Offset Voltage-Max | 8 µV | |
| JESD-30 Code | R-PDSO-G5 | |
| JESD-609 Code | e4 | |
| Length | 2 Mm | |
| Low-Bias | Yes | |
| Low-Offset | Yes | |
| Micropower | Yes | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 5 | |
| Number of Terminals | 1 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP5/6,.08 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Thin Profile, Shrink Pitch | |
| Packing Method | Tr | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power | No | |
| Programmable Power | No | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.1 Mm | |
| Slew Rate-Nom | 0.19 V/Us | |
| Supply Current-Max | 0.04 Ma | |
| Supply Voltage Limit-Max | 6 V | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | Yes | |
| Technology | Cmos | |
| Temperature Grade | Automotive | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.65 Mm | |
| Terminal Position | Dual | |
| Unity Gain BW-Nom | 400 | |
| Voltage Gain-Min | 316227.78 | |
| Wideband | No | |
| Width | 1.25 Mm |
