ADL5513ACPZ-R7 by:

1 MHz TO 4 GHz, 80 dB Logarithmic Detector / Controller

Part Details for ADL5513ACPZ-R7 by Analog Devices Inc

Overview of ADL5513ACPZ-R7 by Analog Devices Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Aerospace and Defense

Price & Stock for ADL5513ACPZ-R7

Part # Distributor Description Stock Price Buy
DISTI # 49AK8465
Newark Logarithmic Detector, 4Ghz, Lfcsp-Ep-16, Frequency Min:1Mhz, Frequency Max:4Ghz, Input Power Min:-67Dbm, Input Power Max:8Dbm, Sensitivity:-70Dbm, Rf Ic Case Style:Lfcsp-Ep, No. Of Pins:16Pins, Supply Voltage Min:2.7V Rohs Compliant: Yes |Analog Devices ADL5513ACPZ-R7 Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 1100
  • 1 $15.7400
  • 10 $14.4600
  • 25 $13.8100
  • 50 $13.0700
  • 100 $12.3300
  • 250 $11.7300
  • 500 $10.9700
$10.9700 / $15.7400 Buy Now
Analog Devices Inc Next Gen 75 dB Log Detector Min Qty: 1 Package Multiple: 1500 644
  • 1 $15.2700
  • 10 $14.0350
  • 25 $13.4532
  • 100 $11.8534
  • 250 $11.2716
  • 500 $10.5444
  • 1,000 $6.8400
  • 1,500 $9.6718
$6.8400 / $15.2700 Buy Now
Bristol Electronics   3
RFQ
DISTI # ADL5513ACPZ-R7
Richardson RFPD DETECTOR/CONTROLLER RoHS: Compliant Min Qty: 1500 0
  • 1,500 $9.4100
$9.4100 Buy Now
DISTI # ADL5513ACPZ
Richardson RFPD DETECTOR/CONTROLLER RoHS: Compliant Min Qty: 1 328
  • 1 $10.8000
  • 10 $10.5000
  • 25 $10.0600
  • 100 $9.7900
  • 500 $9.5400
  • 1,000 $9.4100
  • 1,500 $9.4100
$9.4100 / $10.8000 Buy Now
DISTI # C1S103100790638
Chip1Stop SP Amp Log Detector/Controller Single 5.5V 16-Pin LFCSP EP T/R RoHS: Compliant pbFree: Yes Container: Cut Tape 1500
  • 1 $13.0000
  • 5 $10.9000
  • 10 $10.3000
  • 50 $9.3000
  • 100 $9.1500
  • 200 $8.9500
$8.9500 / $13.0000 Buy Now
Win Source Electronics IC LOG DETECTOR/CTRLR 16 LFCSP 12000
  • 5 $11.8700
  • 11 $9.7400
  • 16 $9.4350
  • 22 $9.1310
  • 29 $8.8270
  • 38 $7.9130
$7.9130 / $11.8700 Buy Now

Part Details for ADL5513ACPZ-R7

ADL5513ACPZ-R7 CAD Models

ADL5513ACPZ-R7 Part Data Attributes

ADL5513ACPZ-R7 Analog Devices Inc
Buy Now Datasheet
Compare Parts:
ADL5513ACPZ-R7 Analog Devices Inc 1 MHz TO 4 GHz, 80 dB Logarithmic Detector / Controller
Pbfree Code No
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer ANALOG DEVICES INC
Part Package Code QFN
Package Description LFCSP-16
Pin Count 16
Manufacturer Package Code CP-16-22
Reach Compliance Code unknown
Date Of Intro 2017-09-21
Samacsys Manufacturer Analog Devices
Analog IC - Other Type LOG OR ANTILOG AMPLIFIER
Bandwidth-Nom 4000 MHz
JESD-30 Code S-XQCC-N16
JESD-609 Code e3
Length 3 mm
Moisture Sensitivity Level 3
Number of Functions 1
Number of Terminals 16
Operating Temperature-Max 125 °C
Operating Temperature-Min -40 °C
Package Body Material UNSPECIFIED
Package Code HVQCCN
Package Equivalence Code LCC16,.12SQ,20
Package Shape SQUARE
Package Style CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Cel) 260
Seated Height-Max 0.8 mm
Supply Voltage-Max (Vsup) 5.5 V
Supply Voltage-Min (Vsup) 2.7 V
Supply Voltage-Nom (Vsup) 5 V
Surface Mount YES
Temperature Grade AUTOMOTIVE
Terminal Finish Matte Tin (Sn) - annealed
Terminal Form NO LEAD
Terminal Pitch 0.5 mm
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) 30
Width 3 mm
