Datasheets
AT90CAN128-16AUR by: Microchip Technology Inc

IC MCU 8BIT 128KB FLASH 64TQFP

Part Details for AT90CAN128-16AUR by Microchip Technology Inc

Overview of AT90CAN128-16AUR by Microchip Technology Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Industrial Automation Healthcare Renewable Energy Robotics and Drones

Price & Stock for AT90CAN128-16AUR

Part # Distributor Description Stock Price Buy
DISTI # 57AC0566
Newark Mcu, 8Bit, Avr Can, 16Mhz, Tqfp-64, Product Range:Avr Family At90Can Series Microcontrollers, Cpu Speed:16Mhz, Program Memory Size:128Kb, Ram Memory Size:4Kb, No. Of Pins:64Pins, Mcu Case Style:Tqfp, No. Of I/O S:53I/O S, Embedded Rohs Compliant: Yes |Microchip AT90CAN128-16AUR Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 2095
  • 1 $10.2300
  • 10 $9.8100
  • 25 $9.3800
  • 50 $9.1300
$9.1300 / $10.2300 Buy Now
DISTI # 78AH9385
Newark Can Avr Uc 128K Flash Tqfp64 Green T&r Rohs Compliant: Yes |Microchip AT90CAN128-16AUR Min Qty: 1000 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 1 $8.0000
$8.0000 Buy Now
DISTI # 68T5033
Newark Can Avr Uc 128K Flash Tqfp64 Green T&r 64 Tqfp 14X14X1Mm T/R Rohs Compliant: Yes |Microchip AT90CAN128-16AUR Min Qty: 1000 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 1,000 $8.4100
$8.4100 Buy Now
DISTI # AT90CAN128-16AUR
Avnet Americas MCU 8-bit 90C AVR RISC 128KB Flash 3.3V/5V 64-Pin TQFP - Tape and Reel (Alt: AT90CAN128-16AUR) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 7 Weeks, 0 Days Container: Reel 0
  • 1 $9.8400
  • 25 $9.0200
  • 100 $8.1600
$8.1600 / $9.8400 Buy Now
DISTI # AT90CAN128-16AUR
Microchip Technology Inc CAN AVR UC 128K FLASH TQFP64 GREEN T&R, Projected EOL: 2039-02-04 RoHS: Compliant pbFree: Yes 0

Alternates Available
  • 1 $9.8400
  • 25 $9.0200
  • 100 $8.1600
  • 1,000 $7.5100
  • 5,000 $7.1500
$7.1500 / $9.8400 Buy Now
Ameya Holding Limited AT90 Series 128 KB Flash 4 KB SRAM 16 MHz 8-Bit Microcontroller - TQFP-64 212
RFQ
NAC CAN AVR UC 128K FLASH TQFP64 GREEN T&R - Package: 64 TQFP 14x14x1mm T/R RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 0
  • 1 $10.2100
  • 100 $9.2500
  • 500 $8.6800
  • 1,000 $8.4600
$8.4600 / $10.2100 Buy Now
DISTI # AT90CAN128-16AUR
Avnet Silica MCU 8-bit 90C AVR RISC 128KB Flash 3.3V/5V 64-Pin TQFP (Alt: AT90CAN128-16AUR) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 9 Weeks, 0 Days Silica - 0
Buy Now
DISTI # AT90CAN128-16AUR
EBV Elektronik MCU 8-bit 90C AVR RISC 128KB Flash 3.3V/5V 64-Pin TQFP (Alt: AT90CAN128-16AUR) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 8 Weeks, 0 Days EBV - 0
Buy Now
Win Source Electronics IC MCU 8BIT 128KB FLASH 64TQFP 52631
  • 6 $9.8920
  • 13 $8.1160
  • 20 $7.8630
  • 27 $7.6090
  • 34 $7.3560
  • 46 $6.5950
$6.5950 / $9.8920 Buy Now

Part Details for AT90CAN128-16AUR

AT90CAN128-16AUR CAD Models

AT90CAN128-16AUR Part Data Attributes

AT90CAN128-16AUR Microchip Technology Inc
Buy Now Datasheet
Compare Parts:
AT90CAN128-16AUR Microchip Technology Inc IC MCU 8BIT 128KB FLASH 64TQFP
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MICROCHIP TECHNOLOGY INC
Package Description TQFP-64
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.31.00.01
Factory Lead Time 7 Weeks
Samacsys Manufacturer Microchip
Has ADC YES
Additional Feature OPERATES AT 2.7V MINIMUM SUPPLY AT 8 MHZ
Address Bus Width 16
Bit Size 8
Boundary Scan YES
CPU Family AVR RISC
Clock Frequency-Max 16 MHz
DAC Channels NO
DMA Channels NO
External Data Bus Width 8
Format FIXED POINT
Integrated Cache NO
JESD-30 Code S-PQFP-G64
JESD-609 Code e3
Length 14 mm
Low Power Mode YES
Moisture Sensitivity Level 3
Number of External Interrupts 4
Number of I/O Lines 53
Number of Serial I/Os 3
Number of Terminals 64
Number of Timers 4
On Chip Data RAM Width 8
On Chip Program ROM Width 8
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
PWM Channels YES
Package Body Material PLASTIC/EPOXY
Package Code TQFP
Package Equivalence Code TQFP64,.63SQ,32
Package Shape SQUARE
Package Style FLATPACK, THIN PROFILE
Peak Reflow Temperature (Cel) 260
RAM (bytes) 4096
ROM (words) 131072
ROM Programmability FLASH
Seated Height-Max 1.2 mm
Speed 16 MHz
Supply Current-Max 29 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 5 V
Supply Voltage-Nom 5 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 0.8 mm
Terminal Position QUAD
Width 14 mm
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC

Alternate Parts for AT90CAN128-16AUR

This table gives cross-reference parts and alternative options found for AT90CAN128-16AUR. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of AT90CAN128-16AUR, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Description Manufacturer Compare
AT90CAN128-16AN RISC Microcontroller, 8-Bit, FLASH, 16MHz, CMOS, PQFP64 Microchip Technology Inc AT90CAN128-16AUR vs AT90CAN128-16AN
Part Number Description Manufacturer Compare
AT90CAN128-16M RISC Microcontroller, 8-Bit, FLASH, 16MHz, CMOS Microchip Technology Inc AT90CAN128-16AUR vs AT90CAN128-16M
AT90CAN128-16MN RISC Microcontroller, 8-Bit, FLASH, 16MHz, CMOS Microchip Technology Inc AT90CAN128-16AUR vs AT90CAN128-16MN
AT90CAN128-16ME RISC Microcontroller, 8-Bit, FLASH, 16MHz, CMOS, MO-220, QFN-64 Atmel Corporation AT90CAN128-16AUR vs AT90CAN128-16ME
AT90CAN128-16AN RISC Microcontroller, 8-Bit, FLASH, 16MHz, CMOS, PQFP64 Microchip Technology Inc AT90CAN128-16AUR vs AT90CAN128-16AN
