Overview of LTC3859AIFE#TRPBF by Analog Devices Inc
Note: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
- Distributor Offerings: ( 4 listings )
- Number of FFF Equivalents: ( 0 replacements )
- CAD Models: ( Request Part )
- Number of Functional Equivalents: ( 0 options )
- Part Data Attributes ( Available )
- Reference Designs: ( Not Available )
Where used in Applications:
Energy and Power Systems
Transportation and Logistics
Renewable Energy
Automotive
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| LTC3859AIFE#TRPBF | Analog Devices | L IQ, 3x Out, Buck/Buck/Boost | |
| LTC3859AIFE#PBF | Analog Devices | L IQ, 3x Out, Buck/Buck/Boost | |
| LT6654AIS6-1.25#TRPBF | Analog Devices | Prec Wide S Hi Out Drv L N Ref |
Price & Stock for LTC3859AIFE#TRPBF by Analog Devices Inc
| Part # | Manufacturer | Description | Stock | Price | Buy | ||
|---|---|---|---|---|---|---|---|
|
DISTI #
LTC3859AIFE#TRPBF-ND
|
DigiKey | IC REG CTRLR MULT TOP 38TSSOP Min Qty: 2000 Lead time: 10 Weeks Container: Tape & Reel (TR) | Temporarily Out of Stock |
|
$7.5250 | Buy Now | |
|
DISTI #
584-LTC3859AIFETRPBF
|
Mouser Electronics | Switching Voltage Regulators L IQ, 3x Out, Buck/Buck/Boost Sync Cntr RoHS: Compliant | 0 |
|
$7.7800 | Order Now | |
| Analog Devices Inc | L IQ, 3x Out, Buck/Buck/Boost Min Qty: 2000 Package Multiple: 2000 | 0 |
|
$6.0200 / $8.5100 | Buy Now | ||
|
DISTI #
LTC3859AIFETRPB
|
Richardson RFPD | POWER MANAGEMENT IC RoHS: Compliant Min Qty: 2000 | 0 |
|
$7.7700 / $8.0800 | Buy Now |
CAD Models for LTC3859AIFE#TRPBF by Analog Devices Inc
Part Data Attributes for LTC3859AIFE#TRPBF by Analog Devices Inc
|
|
|
|---|---|
|
Pbfree Code
|
No
|
|
Rohs Code
|
Yes
|
|
Part Life Cycle Code
|
Active
|
|
Ihs Manufacturer
|
ANALOG DEVICES INC
|
|
Package Description
|
4.40 MM, LEAD FREE, PLASTIC, TSSOP-38
|
|
Pin Count
|
38
|
|
Manufacturer Package Code
|
05-08-1772
|
|
Reach Compliance Code
|
compliant
|
|
Samacsys Manufacturer
|
Analog Devices
|
|
Additional Feature
|
OPERATES IN ADJUSTABLE MODE FROM 0.8 TO 24V
|
|
Analog IC - Other Type
|
DUAL SWITCHING CONTROLLER
|
|
Control Mode
|
CURRENT-MODE
|
|
Control Technique
|
PULSE WIDTH MODULATION
|
|
Input Voltage-Max
|
38 V
|
|
Input Voltage-Min
|
4.5 V
|
|
Input Voltage-Nom
|
12 V
|
|
JESD-30 Code
|
R-PDSO-G38
|
|
JESD-609 Code
|
e3
|
|
Length
|
9.7 mm
|
|
Moisture Sensitivity Level
|
1
|
|
Number of Functions
|
1
|
|
Number of Terminals
|
38
|
|
Operating Temperature-Max
|
125 °C
|
|
Operating Temperature-Min
|
-40 °C
|
|
Output Voltage-Nom
|
5.4 V
|
|
Package Body Material
|
PLASTIC/EPOXY
|
|
Package Code
|
HTSSOP
|
|
Package Shape
|
RECTANGULAR
|
|
Package Style
|
SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH
|
|
Peak Reflow Temperature (Cel)
|
260
|
|
Seated Height-Max
|
1.2 mm
|
|
Surface Mount
|
YES
|
|
Switcher Configuration
|
PHASE-SHIFT
|
|
Switching Frequency-Max
|
835 kHz
|
|
Technology
|
CMOS
|
|
Temperature Grade
|
AUTOMOTIVE
|
|
Terminal Finish
|
Matte Tin (Sn)
|
|
Terminal Form
|
GULL WING
|
|
Terminal Pitch
|
0.5 mm
|
|
Terminal Position
|
DUAL
|
|
Time@Peak Reflow Temperature-Max (s)
|
30
|
|
Width
|
4.4 mm
|
