MPC564CZP66 by:

32-BIT, FLASH, 66MHz, RISC MICROCONTROLLER, PBGA388

Part Details for MPC564CZP66 by NXP Semiconductors

Results Overview of MPC564CZP66 by NXP Semiconductors

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Automotive

MPC564CZP66 Information

MPC564CZP66 by NXP Semiconductors is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.

Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.

Price & Stock for MPC564CZP66

Part # Distributor Description Stock Price Buy
DISTI # 62H6153
Newark Ic, microcontroller,32-Bit, cmos, bga,388Pin, plastic Rohs Compliant: Yes |Nxp MPC564CZP66 RoHS: Compliant Min Qty: 200 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 100 $119.2600
$119.2600 Buy Now
DISTI # MPC564CZP66
Avnet Americas MCU 32-bit MPC56xx e200 RISC 512KB Flash 2.6V/5V 388-Pin BGA Tray - Trays (Alt: MPC564CZP66) RoHS: Not Compliant Min Qty: 200 Package Multiple: 200 Lead time: 12 Weeks, 0 Days Container: Tray 0
  • 200 $115.5308
  • 400 $114.5991
  • 800 $113.6674
  • 1,200 $112.7357
  • 1,600 $109.6145
$109.6145 / $115.5308 Buy Now
DISTI # MPC564CZP66
Avnet Silica MCU 32-bit MPC56xx e200 RISC 512KB Flash 2.6V/5V 388-Pin BGA Tray (Alt: MPC564CZP66) RoHS: Not Compliant Min Qty: 40 Package Multiple: 40 Lead time: 54 Weeks, 0 Days Silica - 0
Buy Now
DISTI # MPC564CZP66
EBV Elektronik MCU 32-bit MPC56xx e200 RISC 512KB Flash 2.6V/5V 388-Pin BGA Tray (Alt: MPC564CZP66) RoHS: Not Compliant Min Qty: 40 Package Multiple: 40 Lead time: 54 Weeks, 0 Days EBV - 0
Buy Now
Flip Electronics Stock 345
RFQ

Part Details for MPC564CZP66

MPC564CZP66 CAD Models

There are no models available for this part yet.

Sign in to request this CAD model.

Register or Sign In

MPC564CZP66 Part Data Attributes

Parametric Data
MPC564CZP66 NXP Semiconductors
Buy Now Datasheet
Compare Parts:
MPC564CZP66 NXP Semiconductors 32-BIT, FLASH, 66MHz, RISC MICROCONTROLLER, PBGA388
Rohs Code No
Part Life Cycle Code End Of Life
Ihs Manufacturer NXP SEMICONDUCTORS
Package Description 27 X 27 MM, 1 MM PITCH, PLASTIC, MO-151, BGA-388
Reach Compliance Code unknown
ECCN Code 3A991.A.2
HTS Code 8542.31.00.01
Factory Lead Time 12 Weeks
Samacsys Manufacturer NXP
Has ADC NO
Address Bus Width 24
Bit Size 32
Boundary Scan NO
Clock Frequency-Max 20 MHz
DAC Channels NO
DMA Channels NO
External Data Bus Width 32
JESD-30 Code S-PBGA-B388
JESD-609 Code e0
Length 27 mm
Moisture Sensitivity Level 3
Number of I/O Lines 16
Number of Terminals 388
On Chip Program ROM Width 8
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
PWM Channels NO
Package Body Material PLASTIC/EPOXY
Package Code BGA
Package Equivalence Code BGA388,26X26,40
Package Shape SQUARE
Package Style GRID ARRAY
Peak Reflow Temperature (Cel) 240
Qualification Status Not Qualified
RAM (bytes) 32768
ROM (words) 524288
ROM Programmability FLASH
Seated Height-Max 2.55 mm
Speed 66 MHz
Supply Voltage-Max 2.7 V
Supply Voltage-Min 2.6 V
Supply Voltage-Nom 2.6 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form BALL
Terminal Pitch 1 mm
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) 30
Width 27 mm
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
