REC6-1212SRW/R10/A/CTRL by: RECOM Power GmbH

DC-DC Regulated Power Supply Module, 1 Output, 6W, Hybrid

Part Details for REC6-1212SRW/R10/A/CTRL by RECOM Power GmbH

Results Overview of REC6-1212SRW/R10/A/CTRL by RECOM Power GmbH

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

REC6-1212SRW/R10/A/CTRL Information

REC6-1212SRW/R10/A/CTRL by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Available Datasheets

Part # Manufacturer Description Datasheet
DRV8301DCA Texas Instruments 3-Phase Brushless Motor Pre-Driver with Dual Current Sense Amps and Buck Converter (PWM Ctrl w/ SPI) 56-HTSSOP -40 to 125
DRV8301DCAR Texas Instruments 3-Phase Brushless Motor Pre-Driver with Dual Current Sense Amps and Buck Converter (PWM Ctrl w/ SPI) 56-HTSSOP -40 to 125
10045103-002C-TRLF Amphenol Communications Solutions SATA, Storage and Server Connector, Receptacle, Vertical, Surface Mount, 22 Positions

Price & Stock for REC6-1212SRW/R10/A/CTRL

Part # Distributor Description Stock Price Buy
DISTI # REC6-1212SRW/R10/A/CTRL-ND
DigiKey DC DC CONVERTER 12V 6W Min Qty: 15 Lead time: 17 Weeks Container: Tube Temporarily Out of Stock
  • 15 $51.0140
$51.0140 Buy Now
DISTI # 919-6-1212SRWR10AC
Mouser Electronics DC/DC Converters - Through Hole 6W DC/DC 10kV REG 12Vin 12Vout RoHS: Compliant 0
  • 1 $55.0900
  • 5 $50.8600
  • 10 $49.9300
  • 30 $48.8300
  • 60 $47.8900
  • 105 $47.2100
$47.2100 / $55.0900 Order Now
DISTI # 11001297
RECOM Power 6W DC/DC-Converter 'ECONOLINE' DIP24 10kV reg 2:1 RoHS: Compliant 0
  • 1 $51.0100
$51.0100 RFQ
Onlinecomponents.com Regulated DC-DC Converter - 6W - Input: 9 to 18VDC - Output: 12VDC - 10kVDC Isolation - CTRL Pin - DIP24 COO: Taiwan RoHS: Compliant 0
  • 1 $55.6000
  • 5 $49.6200
  • 15 $48.1300
  • 30 $46.0700
  • 60 $44.1800
  • 105 $43.0000
  • 255 $42.3500
$42.3500 / $55.6000 Buy Now
DISTI # REC61212SRWR10A
Richardson RFPD DC TO DC CONVERTER MODULE RoHS: Compliant Min Qty: 15 0
  • 15 $40.3100
$40.3100 Buy Now
DISTI # 000000000006059219
Sager Isolated DC/DC Converters - Through Hole 6W DC/DC 10kV REG 12Vin 12Vout Min Qty: 1 0
  • 1 $53.7400
  • 5 $52.0000
  • 10 $49.6100
  • 25 $48.1200
  • 50 $47.4000
  • 100 $46.0700
$46.0700 / $53.7400 Buy Now

Part Details for REC6-1212SRW/R10/A/CTRL

REC6-1212SRW/R10/A/CTRL CAD Models

  • 3D Model

    2d presentation

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

REC6-1212SRW/R10/A/CTRL Part Data Attributes

Parametric Data
REC6-1212SRW/R10/A/CTRL RECOM Power GmbH
Buy Now Datasheet
Compare Parts:
REC6-1212SRW/R10/A/CTRL RECOM Power GmbH DC-DC Regulated Power Supply Module, 1 Output, 6W, Hybrid
Rohs Code Yes
Part Life Cycle Code Active
Package Description Dma, Dip7/24,.6
Reach Compliance Code Compliant
ECCN Code EAR99
Additional Feature Seated Hgt Calculated
Analog IC - Other Type Dc-Dc Regulated Power Supply Module
Input Voltage-Max 18 V
Input Voltage-Min 9 V
Input Voltage-Nom 12 V
JESD-30 Code R-PDMA-T7
Length 32 Mm
Load Regulation-Max 0.6%
Number of Functions 1
Number of Outputs 1
Number of Terminals 7
Operating Temperature-Max 75 °C
Operating Temperature-Min -40 °C
Output Current-Max 0.5 A
Output Voltage-Max 12.24 V
Output Voltage-Min 11.76 V
Output Voltage-Nom 12 V
Package Body Material Plastic/Epoxy
Package Code DMA
Package Equivalence Code DIP7/24,.6
Package Shape Rectangular
Package Style Microelectronic Assembly
Peak Reflow Temperature (Cel) Not Specified
Qualification Status Not Qualified
Seated Height-Max 10.45 Mm
Surface Mount No
Technology Hybrid
Temperature Grade Other
Terminal Form Through-Hole
Terminal Pitch 2.54 Mm
Terminal Position Dual
Time@Peak Reflow Temperature-Max (s) Not Specified
Total Power Output-Max 6 W
Trim/Adjustable Output No
Width 20.3 Mm

Alternate Parts for REC6-1212SRW/R10/A/CTRL

This table gives cross-reference parts and alternative options found for REC6-1212SRW/R10/A/CTRL. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of REC6-1212SRW/R10/A/CTRL, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
AM6T-1212SH35Z Aimtec $16.0463 DC/DC Converter; Product Weight (grams): 17; Input voltage min (V): 9; Input voltage max (V): 18; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Single; Output Power (W): 6; Max Output current (A): 0.5; Efficiency (%): 81; Max Capacitive load (µF): 330; Package type: DIP24; Mounting: PCB; W (in): 0.8; L (in): 1.25; H (in): 0.4; W (mm): 20.32; L (mm): 31.75; H (mm): 10.16; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 3500; EMC compliance 2: EN 55032 Class A; Case material: Copper ; Application 4 (building automation/IoT): 1; MTBF (h): 1121000; Derating : 85; Voltage Accuracy (%): ±1; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 60; Switching Frequency typ (KHz): 266; Short circuit protection: Continuous REC6-1212SRW/R10/A/CTRL vs AM6T-1212SH35Z
AM6T-1212S-NZ Aimtec Check for Price DC/DC Converter; Product Weight (grams): 13; Input voltage min (V): 9; Input voltage max (V): 18; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Single; Output Power (W): 6; Max Output current (A): 0.5; Efficiency (%): 84; Package type: DIP24; Mounting: PCB; W (in): 0.79; L (in): 0.42; H (in): 1.26; W (mm): 20; L (mm): 10.8; H (mm): 32; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 1500; EMC compliance 2: EN 55022 Class A; Case material: Aluminum; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 1000000; Derating : 71; Voltage Accuracy (%): ±1; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 300; Short circuit protection: Continuous REC6-1212SRW/R10/A/CTRL vs AM6T-1212S-NZ
AM6T-1212SH35-VZ Aimtec Check for Price DC/DC Converter; Product Weight (grams): 17; Input voltage min (V): 9; Input voltage max (V): 18; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Single; Output Power (W): 6; Max Output current (A): 0.5; Efficiency (%): 74; Max Capacitive load (µF): 470; Package type: DIP24; Mounting: PCB; W (in): 0.8; L (in): 1.25; H (in): 0.4; W (mm): 20.32; L (mm): 31.75; H (mm): 10.16; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 3500; Case material: Copper ; Application 4 (building automation/IoT): 1; MTBF (h): 1000000; Derating : 71; Voltage Accuracy (%): ±1; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 60; Switching Frequency typ (KHz): 400; Short circuit protection: Continuous REC6-1212SRW/R10/A/CTRL vs AM6T-1212SH35-VZ
AM6T-1212S-VZ Aimtec Check for Price DC/DC Converter; Product Weight (grams): 17; Input voltage min (V): 9; Input voltage max (V): 18; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Single; Output Power (W): 6; Max Output current (A): 0.5; Efficiency (%): 74; Max Capacitive load (µF): 470; Package type: DIP24; Mounting: PCB; W (in): 0.8; L (in): 1.25; H (in): 0.4; W (mm): 20.32; L (mm): 31.75; H (mm): 10.16; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 1500; Case material: Copper ; Application 4 (building automation/IoT): 1; MTBF (h): 1000000; Derating : 71; Voltage Accuracy (%): ±1; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 60; Switching Frequency typ (KHz): 400; Short circuit protection: Continuous REC6-1212SRW/R10/A/CTRL vs AM6T-1212S-VZ
REC6-1212SRW/R8 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module, 1 Output, 6W, Hybrid REC6-1212SRW/R10/A/CTRL vs REC6-1212SRW/R8
REC6-1212SRW/R10/X1 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module, 1 Output, 6W, Hybrid REC6-1212SRW/R10/A/CTRL vs REC6-1212SRW/R10/X1
