TPS2011APWP Information
TPS2011APWP by Texas Instruments is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| TPS2011APWP | Texas Instruments | 1.2A, 2.7 to 5.5V single high-side MOSFET switch IC, no fault reporting, active-low enable 14-HTSSOP -40 to 85 |
Price & Stock for TPS2011APWP
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
86296695
|
Verical | Power Switch Hi Side 1-OUT 0A 33mOhm 14-Pin HTSSOP EP Tube RoHS: Compliant Min Qty: 242 Package Multiple: 1 | Americas - 6570 |
|
$1.3125 / $1.5500 | Buy Now |
|
DISTI #
86291686
|
Verical | Power Switch Hi Side 1-OUT 0A 33mOhm 14-Pin HTSSOP EP Tube RoHS: Compliant Min Qty: 242 Package Multiple: 1 Date Code: 1401 | Americas - 3570 |
|
$1.3125 / $1.5500 | Buy Now |
|
|
Bristol Electronics | Power Switch Hi Side 1-OUT 0A 33mOhm 14-Pin HTSSOP EP Tube Min Qty: 1 | 180 |
|
$1.4640 / $2.9280 | Buy Now |
|
|
Quest Components | 144 |
|
$1.5776 / $3.1552 | Buy Now | |
|
|
Quest Components | 144 |
|
$1.3664 / $3.9040 | Buy Now | |
|
|
Rochester Electronics | Power Distribution Switch General Purpose N-Channel 1 OUT High Side 14-SOP Tube RoHS: Compliant Status: Active Min Qty: 1 | 10140 |
|
$1.0500 / $1.3100 | Buy Now |
US Tariff Estimator: TPS2011APWP by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
TPS2011APWP CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
TPS2011APWP Part Data Attributes
|
|
TPS2011APWP
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TPS2011APWP
Texas Instruments
Fixed, 1 Channel, PDSO14
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Part Package Code | TSSOP | |
| Pin Count | 14 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.60 | |
| Adjustable Threshold | No | |
| Analog IC - Other Type | Load Switch | |
| Input Voltage-Max | 5.5 V | |
| Input Voltage-Min | 2.7 V | |
| JESD-30 Code | R-PDSO-G14 | |
| JESD-609 Code | e4 | |
| Length | 5 Mm | |
| Moisture Sensitivity Level | 2 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 14 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | HTSSOP | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Heat Sink/Slug, Thin Profile, Shrink Pitch | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.2 Mm | |
| Supply Current-Max (Isup) | 0.1 Ma | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 2.7 V | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | Yes | |
| Temperature Grade | Industrial | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.65 Mm | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4.4 Mm |
